Troubleshooting Reference
2-33
element
TM
Series
SPC Diag Communications related indicators.
PLD Diag System wide indicators.
Action Info
This display provides indicators that can help to discover why an unexpected action is occur-
ring.
Car Call Canceled Due To: Inputs or states that can cause car calls to be cancelled.
Hall Call Canceled Due To: Inputs or states that can cause hall calls to be cancelled.
Door Open Due To: Inputs or states that can cause doors to open or remain open.
Prohibit Run/Start Due to: Inputs or states that can cause starting or running to be dis-
abled.
Door Close Due To: Inputs or states that can cause doors to close or remain closed.
Status Info
View:
CPU, BUS, COM Status.
Hall Bus Inventory: When all hall calls are installed and functioning properly use the
INVTRY control on this screen to add them to system memory. When troubleshooting hall
calls at a future date, use the TEST control to automatically poll and test all switches and
lamps.
Stats
Collected statistics for maintenance and system activity.
Software version information.
Maintenance Statistics: Collected run-related statistics. Compiled until manually cleared.
Hourly Statistics: Car and hall call statistics per hour for the preceding 24 hours.
Scope
The virtual oscilloscope allows you to select up to four signals from an elevator subsystem and
display them in near real-time.
1. Select the subsystem:
System Inputs
System Outputs
Landing System
Programmed Inputs
Programmed Outputs
2. Use the scroll arrows to move through signals.
3. For each desired signal, tap on one of the four boxes on the right of the screen. The sig-
nal will appear in the box.
4. Tap on OK to return to the selection screen, then on View Scope.
5. Touch the scope arrows to adjust trace speed (amount of time represented by screen
graticules).
6. The selected signals will remain on the scope until you replace them with others.
