Motion Control Engineering Nidec Element Series User Manual

User Interface
1-13
element
TM
Series
• SIMPLEX/DISP ID: nn
• Dispatcher - Duplex installation, assigning hall calls for itself and for the second car of
the Duplex.
• Disp ID: nn - indicates that this car is accepting hall call assignments from the other
car in a Duplex installation.
• Simplex: Single self-dispatching car.
Additional information provided in this screen section includes:
Menu Overview
See Section 2 for details about parameter settings, Screen Descriptions on page 2-5. With the
car on Inspection mode, take some time to go through all the menus to become familiar with
parameter settings and their locations.
Table 1.4 General Status Information
Topic Description
Intended Direction Intended direction of travel (preferred direction)
Actual Direction Actual direction of travel (direction command activated)
Position Logical position, user defined floor label
Destination Next destination, user defined floor label
Door Status Door state display (closed, opening, open, closing, stalled)
Door Lock Status Door locks/Car safety string
Car Speed Commanded car speed
Car Label Label assigned to this car (1A in our example)
Car motion animation Arrows scroll rapidly in high speed operation; slow on Inspection
Date and Time mm/dd/yy and 00.00.00 am/pm
Table 1.5 Config 01, 02, and 03
Topic Description
Config 01
Building Setup, page 2-5 Controller type, floor information, Fire code and recall floors, land-
ing system type.
Job Info and Labels, page 2-5 Job information, car and floor labels
Elevator Features, page 2-6 Capture and recall floors, car behavior, antinuisance
Configure Spare Inputs, page 2-7 Configure spare inputs.
Configure Spare Outputs, page 2-7 Configure spare outputs.
System Timers, page 2-8 Motor delays, door timers, car delay timers
Config 02
Hoistway Setup, page 2-9 Floor heights, offsets, access distances, counterweight position
NTS2 Switches, page 2-9 Normal Terminal Slowdown 2 switch setup
ETS Switches, page 2-10 ETS, ETSL setup
S-Curve, page 2-11 Speed curve setup
NTS1 Switches, page 2-12 Normal Terminal Slowdown 1 switch setup
System Control Parameters,
page 2-13
Dispatcher, speed, overspeed, emergency brake setup.
