Configuration and Troubleshooting
2-34 Manual # 42-02-2P26
Circuit Board Descriptions
Element controller circuit boards:
• MC-CPI-2: COP serialization, landing system interface, added I/O page 1-46, page 2-35
• SC-3HN: Serial Hall Call Node Board, page 1-43
• SCE-BRK: Brake board, page 2-37
• SCE-CON: Cartop Connections Board, page 2-38
•SCE-CPU: Controller processor, page 2-40
• SCE-HVI: High voltage interface, page 2-47
•SCE-UPD: Unregulated power distribution, page 2-50
