Installation
1-64 Manual # 42-02-2P26
7. When testing is complete, make sure that all appropriate data has been properly docu-
mented.
Automated Tests
Automated tests are accessed through the UTILS menu, SAFETY TESTS screen. Once you select
SAFETY TESTS, a COMPLIANCE TESTING button appears. Press this button and you will be
asked to select a Test Type and the speed at which the test will be conducted.
When running automated terminal/slowdown switch tests, be aware that the speed you
have selected must be sufficient to trip the unit under test. Switches not being tested are dis-
armed so, if the unit under test does not trip, the elevator will continue with only the physi-
cal final limit providing protection. Be prepared to remove power if the unit under test does
not trip.
Prepare drive for overspeed test
When instructed to “Prepare drive for overspeed test” do the following:
• Magnetek HPV900
• On the Drive A1 Submenu, verify/set the Overspeed Mult parameter to the percentage
of contract speed required for the test. Default = 125%.
• On the Utility U0 Menu, set OVERSPEED TEST? = YES.
• TORQMAX F5
•On the Home > Prog > Tune Parameters menu, set LL16 to the speed selected on the
controller for the test.
• To activate the drive’s Overspeed Test, set LL15 to “Start without Scaling” on the
drive’s Home > Prog > Tune Parameters menu.
When you have selected Test Type and Speed, and prepared the drive for the overspeed test,
click NEXT and follow on-screen instructions to complete the selected test. If you are running
tests that do not incorporate emergency or terminal slowdowns, stay well away from them.
Once a compliance test has been “armed” you may exit the test screen and go to the home
screen to observe car speed, position, etc. while the test is executing.
