Installation
1-20 Manual # 42-02-2P26
Installation
The job prints provide the information required to wire and set up the controller. This section
provides information in support of the prints.
Installation Checklist
• Verify incoming power
• Install controller, page 1-20
• Connect NEC250, certified ground, page 1-20
• Connect motor control voltages, page 1-21
•Connect motor encoder
• Install safety string components per job prints
• Verify controller is on Inspection operation
• Connect AC power from mains to controller
• Verify controller settings; verify drive settings, page 1-23, page 1-25
• Set up for construction operation, page 1-22
• Install hoistway switches (may be physical or virtual) and landing system, page 1-27
•Learn hoistway, page 1-52
• Install door operator, page 1-50
• Balance car and counterweight
• Set counterweight height at adjacent-to-car position, page 1-51
• Verify brake will hold 125% of load
• Adjust S-Curve in middle of hoistway (accel/decel/speed/jerk; Test mode), page 1-54
• Learn terminal switches (position/speed), page 1-57
• Install car and hall calls, PIs, page 1-43
• Verify accurate landing at all floors
• Perform commissioning tests, page 1-62
Enclosure Installation
Secure the controller enclosure on a wall or use the optional floor mounting kit as required. Use
provided wiring knock-outs to install raceway or conduit to route wires into the cabinet. If you
drill or cut the cabinet, do not allow metal chips or shavings to fall into electronics. Damage
caused by this is not covered by warranty.
Grounding
A professional electrician-certified, NEC 250, earth ground is imperative. Most electrical noise
and/or intermittent continuity problems result from poor grounding.
