Install the Bottom Terminal Magnets Refer to Figure 1.16
1. Place a 30-inch, striped magnet in the left rail angle, just above the bottom door zone
magnet as shown above. The bottom of the 30-inch magnet must be even with the top of
the door zone magnet.
2. For jobs with rear doors only, stack two 5-inch striped magnets below the 30-inch mag-
net. Leave NO GAPS between the striped magnets.
3. For jobs with front or front and rear doors, stack one 5-inch striped magnet directly
below the Front Door Zone magnet. Leave no gaps between the ends of the magnets.
ETS/ETSL magnets and/or switches Refer to Figure 1.16
ETS/ETSL switches may be required where reduced-stroke buffers are used or where full-
stroke buffers are used and the rated speed is greater than 200 fpm/1.0m/s. These options are
described in Terminal Switch Configuration on page 1-56 and the procedure used to determine
the location of the switches is described in Terminal Switch Learn on page 1-57.
The floors must be learned, see “Hoistway Learn (Landing System Learn)” on page 1-52 and it is
recommended to adjust the drive, see “Drive Response” on page 1-53 before performing the
Terminal Switch Learn procedure and installing the ETS/ETSL magnets/switches.
Parameter Settings
Verify the following parameters settings:
• Config 01, Building Setup information is correct.
• Config 02, Hoistway Setup menu is correct per factory settings.
Hoistway Learn
Please refer to “Hoistway Learn (Landing System Learn)” on page 1-52.
Offset
All compatible controllers allow the door zone heights to be individually adjusted in 0.10 inch
increments to compensate for magnet placement irregularity. Please refer to CONFIG02, Hoist-
way Setup.
Landing System Troubleshooting Tools
Touch screen tools will help you isolate any problems with the landing system;
• UTILS > LANDING SYSTEM UTIITIES > LANDING SYSTEM VIEW
Door Zone Verification
Following the hoistway learn process, starting at the top floor, move the car down on inspection
and verify that the door zone indicators (e.g., LEDs, relays, diagnostic status, etc.) activate only
at the appropriate locations at the landings (i.e., +/- 75 mm or 3”) and nowhere else. Be sure to
check rear door zones as well, where applicable.
