Traction Acceptance Tests
1-65
element
TM
Series
Car/cwt safety
1. Electrical governor overspeed switch must be physically bypassed.
2. On Test operation, move car to starting position.
3. Place car on Machine Room inspection.
4. Place Flt Bypass jumper in Bypass position.
5. On Element touch screen select Utils > Construct and Bypass Faults. Select Construc-
tion/Fault Bypass Disabled; enable bypass, press OK. Press EXIT.
6. Select Utils > Safety Tests > Compliance Testing.
7. Select test and speed (Safety Rated + 10 FPM).
8. Prepare drive for overspeed test (see “Prepare drive for overspeed test” on page 1-64).
9. Return to the Element touch screen, press Next, and follow on-screen instructions.
Additional:
• To break traction, jump out the associated final limit switch and continue to run on
Inspection in direction of test.
On Completion:
• Place Flt Bypass jumper in NORM position.
• Use touch screen to exit Compliance testing.
• Use touch screen to disable Construction/Fault Bypass.
• Remove any additional jumpers that have been used.
Car/cwt buffer
1. Final limit switch must be physically bypassed.
2. On Test operation, move car to starting position.
3. Place car on Machine Room inspection.
4. Place Flt Bypass jumper in Bypass position.
5. On the Element touch screen select Utils > Construct and Bypass Faults. Select Con-
struction/Fault Bypass Disabled; enable bypass, press OK. Press EXIT.
6. Select Utils > Safety Tests > Compliance Testing.
7. Select test and speed (Contract or Rated Buffer).
8. Return to the Element touch screen, press Next, and follow on-screen instructions.
Additional:
• To break traction, jump out the associated final limit switch and continue to run on
Inspection in direction of test.
On Completion:
• Place Flt Bypass jumper in NORM position.
• Use touch screen to exit Compliance testing.
• Use touch screen to disable Construction/Fault Bypass.
• Remove any additional jumpers that have been used
