Screen Descriptions
2-21
element
TM
Series
Table 2.3 Spare Outputs
Output Description
NOT USED This output is not currently assigned.
APS DONE TAPS asserts this output when return is complete. Auxiliary power supply recall complete
ARROW DN Turns ON when preferred direction of travel is below car’s present location. Down direction
preference arrow
ARROW UP Turns ON when preferred direction of travel is above car’s present location. Up direction
preference arrow
BACKUP PWR Battery lowering has been activated by the APS ON input (HAPS/TAPS)
CAR DELAY Car has not been able to move, Typically due to doors being held open. Car delayed
CC REGSTRD Car call registered. Activates for 1/2 second when a car call is registered.
CC SECURED Activates for 1/2 second if a secured car call button is pressed.
CAR GONG Car gongs
CAR LANTDN Down car lanterns
CAR LANTUP Up car lanterns
CLOSING The doors are closing or attempting to close. See output DCF
DCF Activates to close the doors. Turns off after door lock is established. Door close function
DHOLD END Door hold function ending warning buzzer
DHOLD ON Door hold function active
DOF Turns ON to open the doors. Turns off after DOL opens. Door open function
EF GONG Egress floor arrival gong
EMSC BUZZR Emergency Medical Service car buzzer output
EMSC LIGHT Emergency Medical Service car light output
EMSH LIGHT Emergency Medical Service hall light output
EP CARDONE Emergency power recall done output
EP LIGHT Emergency power light. Flashes when car is selected to run on emergency power. Solid
when car is selected to recall.
EP LOBBY Intended to drive a light at the designated emergency power return floor after the car is at
the floor with doors open on emergency power.
EP ON Emergency power ON output
EP2 ON Emergency Power Phase 2 run output active
EP SELECT Emergency power car selected to recall or run output
EP1 ON Emergency power lowering phase output
EP1 RECALL Emergency power car selected to recall output
EP2 ON Emergency power running phase output
EP2 RUN Emergency power car selected to run output
EQ BUZZER Turns ON after an earthquake has been detected. Earthquake buzzer
EQ LIGHT Turns ON after an earthquake has been detected. Earthquake light
FAN LIGHT Controlled by FLO Timer (Default 5 minutes) located in System Timers. Fan/light output
FLR GONG Output activates when car passes a floor
FR HAT Illuminates when we are on Fire Phase 1. Fire I hat light
FR ISV In service for fire service light
FR RECALL Fire recall light
FR1 BUZR Fire I buzzer
FR1 DONE Fire recall complete
