Motion Control Engineering Nidec Element Series

Component Identification
1-17
element
TM
Series
Component Identification
Figure 1.3 System Architecture
RST
IO24
IO23
IO22
IO21
IO20
IO19
IO18
IO17
IO16
IO15
IO14
IO13
IO12
IO11
IO10
IO9
IO8
IO7
IO6
IO5
IO4
IO3
IO2
IO1
COM
24V
+V
COM
+V
COM
MACHINE ROOM
CONTROLLER
COP ENCLOSURE
MC-CPI-2 interface board
collects discrete button, switch,
or input signals and converts
them to serial data for efficient
transmission.
Discrete I/O on the CPI
board interfaces to the
selected door operator.
High Voltage Interface
SCE-HVI
Brake Control
SCE-BRK
CPU
Starter
USB
Micro SD Card
Brake
Contactor
Motor
Contactor
Main Fuses
Choke
Hall Call Node
Hall Call Node
Hall Call Node
Hall Call Node
Hall Call Node
Hall Call Node
AC Drive
Expanded I/O
(if required)
LS-EDGE
MC-CPI-2
SCE-CON
Power Distribution
SCE-UPD
Braking Unit
or other
if required
