Installation
1-10 Manual # 42-02-2P26
Learn Modes
Learn modes are special operating modes that allow the elevator to learn landing system and
hoistway switch configurations.
Hoistway Learn (Landing System Learn) After the landing system has been
installed, the Hoistway Learn (Landing System Learn) operation can be accessed through the
UTILS, Landing System Utilities menu. The learn menu will guide you through the required
steps, beginning with running the car to the bottom landing on Inspection mode and ending
when all terminal and floor level magnets have been learned.
Terminal Switch Learn After the car has been adjusted for high speed running and
you are satisfied with performance and accuracy, the Terminal Switch Learn operation can be
accessed through the UTILS, Landing System Utilities menu. The terminal switch learn is per-
formed on Test mode with the car running at contract speed. The operation will learn and set
NTS2 (if used), ETS, NTS1, and directional limit position, speed, and deltas (allowable ranges).
Any changes made to S-Curve or speed parameters after the Terminal Switch Learn operation
has been performed will require that it be repeated.
