Troubleshooting Reference
2-55
element
TM
Series
BRP Failed to Turn On (249) Traction Only. NC auxiliary contact for BR contactor failed to open. When
idle, this input should be activated. Fault-bypassed in Construction.
Correction:
1. Check BRP screw terminal on SCE-CPU board for 24VDC. When BR
contactor is picked, BRP should go low.
Capture Mode (4) Controller in Capture Mode. The elevator will not accept hall calls but will
answer car calls. Intent is to service existing passengers until car is idled
at a floor and available for maintenance or test. Fault bypassed in Con-
struction/Inspection.
System Verifies:
- Mode of operation = Capture
Correction:
1. Check that the Test switch is not in the Pretest position.
Car Calls Disabled (353) Car calls have been disabled. Typically caused by car operation in a mode
or during a fault condition in which car calls are not active.
Correction:
1. If in error, check Home screen to see what mode of operation is dis-
played and if any faults are displayed.
2. Troubleshoot the active mode and/or fault condition.
Car Delayed Door Closed (319) The car has been delayed in answering a registered call while the doors
are closed. Informational. Fault-bypassed in Construction.
Correction -
1. Check the Car Delayed Timer setting. It might be too short.
2. Check for any faults that might be preventing the car from moving in a
timely manner.
Car Delayed Door Open (39) The car has been delayed in answering a registered call while the doors
are open. Informational. Fault-bypassed in Construction.
Correction -
1. Check the Car Delayed Timer setting. It might be too short.
2. Check for any faults that might be preventing the car from moving in a
timely manner.
Car Hold (445) The car is on hold and not allowed to move. Used for the EMS Hold func-
tion initiated when the car is on in-car EMS mode and the in-car EMS
switch is deactivated while the car is away from the EMS floor.
Car Stop Sw Bypassed (310) The car stop switch is being bypassed. Normally due to PH1 Fire.
Car Stop Sw On (2) Car stop switch input active. If moving, the car will perform an emer-
gency stop. Doors will not be allowed to move. The event will end when
the switch is returned to the off position.
Correction:
1. If in error, troubleshoot the SAFC input and the switch.
Car Stop Sw on Re-Level (318) Car stop switch activated during releveling. Car will complete releveling.
Doors remain operational. Informational event. Resets when switch
returned to Off position.
Cartop Construct/Bypass (316) Car Panel inspection is active and one or both of the Car/Hoistway Door
Bypass switches is in the Bypass position. Cannot be bypassed.
System Verifies:
- ModeofOperation = OpModeInspectionBPCP
Correction:
1. Turn off one or both of the Car/Hoistway Door Bypass switches.
Table 2.15 Touch Screen Event Listings
Event Description
