DOL Low - DCL Low (325) Door open and close limits are not made (DOL and DCL = 0). If the
DOOR CONTACT FLT ENABLED option = YES, the car is shut down and the
door close button is rendered inoperative as long as the fault is present
(per applicable elevator safety code). If the option = NO, the fault is
logged but otherwise ignored.
Correction:
1. Check door open and close limit inputs and contacts.
DOL Low - DLAB High (334) Car is at bottom floor with doors open but bottom door lock string is
made (DOL = 0, DLAB = 1). If the DOOR CONTACT FLT ENABLED option
= YES, the car is shut down and the door close button is rendered inoper-
ative as long as the fault is present (per applicable elevator safety code).
If the option = NO, the fault is logged but otherwise ignored.
Correction:
1. Check door open limit and bottom door lock string inputs and contacts.
DOL Low - DLAT High (330) Car is at op floor with doors open but top door lock string is made (DOL =
0, DLAT = 1). If the DOOR CONTACT FLT ENABLED option = YES, the car
is shut down and the door close button is rendered inoperative as long as
the fault is present (per applicable elevator safety code). If the option =
NO, the fault is logged but otherwise ignored.
Correction:
1. Check door open limit and top door lock string inputs and contacts.
DOL Low - DLMS High (332) Car is at a floor other than top or bottom with doors open but door lock
string is made (DOL = 0, DLMS = 1). If the DOOR CONTACT FLT
ENABLED option = YES, the car is shut down and the door close button is
rendered inoperative as long as the fault is present (per applicable eleva-
tor safety code). If the option = NO, the fault is logged but otherwise
ignored.
Correction:
1. Check door open limit and middle door lock string inputs and contacts.
DOL Low - DPM High (287 & 288) Doors are open but DPM limit is made (DOL = 0, DPM = 1). If the DOOR
CONTACT FLT ENABLED option = YES, the car is shut down and the door
close button is rendered inoperative as long as the fault is present (per
applicable elevator safety code). If the option = NO, the fault is logged
but otherwise ignored.
Correction:
1. Check door open and position monitoring limit inputs and contacts.
DOL Low - GS High (285) The door open limit and car gate switch positions are conflicting (DOL =
0, GS = 1). If the DOOR CONTACT FLT ENABLED option = YES, the car is
shut down and the door close button is rendered inoperative as long as
the fault is present (per applicable elevator safety code). If the option =
NO, the fault is logged but otherwise ignored.
Correction:
1. Check the door open limit and car gate switch inputs and contacts.
Door Bypass Construct (315) Machine room inspection and construction operation are active and one
or both of the Car/Hoistway Door Bypass switches is in the Bypass posi-
tion. Cannot be bypassed.
System Verifies:
- ModeOfOperation = OpModeConstructionBP
Correction:
1. Exit construction operation (Construction Operation on page 1-8)
Table 2.15 Touch Screen Event Listings
