Motion Control Engineering Nidec Element Series User Manual

Configuration and Troubleshooting
2-66 Manual # 42-02-2P26
Emergency Dispatch (125) Hall call bus has failed and car is operating on emergency dispatching to
continue service to building. Fault-bypassed in Construction/Inspection.
Check OBD for message:
3HN comm loss or
Emergency dispatch input (EM DISP) activated.
System Verifies:
- Emergency Dispatch Data = Emerg Dispatch
Correction:
1. Verify hall call functionality.
2. Verify EM DISP input; System IO > Programmed Inputs (must be
assigned to a valid input)
EMS In Car (444) Car has completed recall to EMS floor and medical personnel have acti-
vated the EMS switch in the car.
EMS Recall (441) Emergency medical service has been initiated.
Correction:
1. If in error, check EMS input.
2. If EMS service has not been activated, verify that no input has been
programmed for the EMS function.
EP Comm/Config Shutdown (380) Emergency power in effect with dispatching communications lost. Car will
shut down. Cannot be bypassed.
Correction:
1. Check Config 03 > Emergency Power > Emergency Power Type. If set
to None, check that no spare input has been programmed as EPI. If
set to Dispatcher or Overlay, check that there is a spare input pro-
grammed as EPI.
EP Recall (20) Emergency power is available and the recall process has been initiated.
Cannot be bypassed.
System Verifies:
- EP Data Status = EP Recall
- EPI flag = 1 for normal operation (active low logic)
Correction:
1. If in error, check System IO > Programmed Inputs > EPI status.
EP Recall Complete (22) Car has completed recall to designated recall floor. Cannot be bypassed.
System Verifies:
- EP Data Status = EP Recall Done
EP Recall Fail (23) Emergency power recall has been initiated but the car has failed to recall.
Cannot be bypassed.
System Verifies:
- EP Data Status = EP Recall Fail
Correction:
1. Check that car is on automatic operation with no active faults.
EP Recall ISV (21) The car is moving toward the recall floor under emergency power. Cannot
be bypassed.
System Verifies:
- EP Data Status = EP Recall ISV
Correction:
1. Check EPI status on SPA Diag > Emerg Pwr and Earthquake.
2. EPI input terminal must be 0V for normal operation.
EP Recall Next Floor (385) Emergency power is available and a recall to the next floor has been initi-
ated. Cannot be bypassed.
Correction:
1. If in error, check System IO > Programmed Inputs > EPI status.
Table 2.15 Touch Screen Event Listings
Event Description
