Installation
1-48 Manual # 42-02-2P26
Figure 1.4 SCE-CPI-2 Interconnect
OMRON
CC24V
24V
COM
24V
IN
COM
SHLD
CANL
CANH
CAN from Machine Room
CPI #1
Traveler
CPI #2
CPI #3
24V
NEXT BOARD
COM
RST
JP3
JP1
OFF
ON
GND
24
SW1
S1
TERMINATION
JP2
JP2
CAN
IN
CAN
IN
CAN
OUT
MC-CPI-2
OMRON
CC24V
24V
COM
24V
IN
COM
24V
NEXT BOARD
COM
RST
JP3
JP1
OFF
ON
GND
24
SW1
S1
TERMINATION
JP2
MC-CPI-2
JP2
OMRON
CC24V
24V
COM
24V
IN
COM
24V
NEXT BOARD
COM
RST
JP3
JP1
OFF
ON
GND
24
SW1
S1
TERMINATION
JP2
JP2
MC-CPI-2
2 foot CAN Cable
between CPI Boards
C-RJ11-2
15 foot CAN Cable
from SCE-CON
(C-RJ11-2)
Power & Ground
Typical Install - Single CPI Board
STANDARD
MAIN COP
OPTIONAL OPTIONAL
AUXILLIARY COP
Additional I/O, Single COP Auxiliary COP
15 foot CAN Cable
between CPI Boards
C-RJ11-15
Jumper on last
board in chain only
NOTE:
CAN cables provided by MCE as ordered.
24V power wiring provided by customer.
SCE-CON
or
MC-LSI
To LS-EDGE
or LS-RAIL
Landing
System
Connections used
with LS-QUTE-24
Landing System
Connections used
with LS-EDGE or
LS-RAIL
Landing System
Traveler
CAN from Machine Room
24 VDC
CAN
OUT
CAN
OUT
CAN
IN
