Installation

1-68 Manual # 42-02-2P26

• ETS overspeed

• Test should be run at UETS/DETS learned speed + UETS/DETS delta speed + 5FPM

(CONFIG02 > ETS Switches)

• Test will be run in TEST mode

•ETSL overspeed

• Test should be run at ETSL Overspeed +5 FPM (CONFIG 02 > ETS Switches)

• Test will be run in TEST mode

• NTS1 Lower overspeed

• Tests the lower overspeed reaction (emergency slowdown then correction speed)

• Test will be run in TEST mode

• Test should be run at learned speed of U/DNTS1 + Delta Low Speed + 5 FPM (CONFIG

02 > NTS1 Switches)

• NTS1 Upper overspeed

• Tests the upper overspeed reaction (emergency stop then correction speed)

• Test will be run in TEST mode

• Test should be run at learned speed of U/DNTS1 + Delta High Speed + 5 FPM (CON-

FIG 02 > NTS1 Switches)

•NTS2 Lower overspeed

• Tests the lower overspeed reaction (emergency slowdown then correction speed)

• Test will be run in TEST mode

• Test should be run at learned speed of U/DNTS2 + Delta Low Speed + 5 FPM (CON-

FIG 02 > NTS2Switches)

• NTS2 Upper overspeed

• Tests the upper overspeed reaction (emergency stop then correction speed)

• Test will be run in TEST mode

• Test should be run at learned speed of U/DNTS2 + Delta High Speed + 5 FPM (CON-

FIG 02 > NTS2 Switches)

Motion Control Engineering Nidec Element Series User Manual
