7-18 Schematics, Component Location Diagrams, and Parts Lists: Control Head Main Board
June 16, 2005 6815854H01-A
Control Head Main Board Parts Lists
Reference
Designator
Motorola
Part Number
Description
C0001 2311049A78 CAP TANT CHIP 10.0 UF
C1000 2113944A28 CAP CHIP 18pF 5% 50V
COG
C1001 2113944A28 CAP CHIP 18pF 5% 50V
COG
C1002 2113944A28 CAP CHIP 18pF 5% 50V
COG
C1003 2113944A28 CAP CHIP 18pF 5% 50V
COG
C1004 2113944A28 CAP CHIP 18pF 5% 50V
COG
C1005 2113944A40 CAP CHIP 100pF 5% 50V
COG
C1006 2113944A40 CAP CHIP 100pF 5% 50V
COG
C1007 2113944A40 CAP CHIP 100pF 5% 50V
COG
C1008 2113944A40 CAP CHIP 100pF 5% 50V
COG
C1009 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1010 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1011 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1012 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1013 2113944A40 CAP CHIP 100pF 5% 50V
COG
C1014 2113944A40 CAP CHIP 100pF 5% 50V
COG
C1015 2113944A40 CAP CHIP 100pF 5% 50V
COG
C1016 2113944A40 CAP CHIP 100pF 5% 50V
COG
C1017 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1018 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1019 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1020 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1021 2113944A40 CAP CHIP 100pF 5% 50V
COG
C1022 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1023 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1024 2313960B01 CAP TANT 1.0uF 10% 16V
C1025 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1026 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1027 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1028 2113945B02 CAP CHIP 10000pF 10%
25V X7R
C1029 2113944A40 CAP CHIP 100pF 5% 50V
COG
C1030 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1031 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1032 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1033 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1034 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1035 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1036 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1037 2113944A40 CAP CHIP 100pF 5% 50V
COG
C1038 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1039 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1040 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1200 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1201 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1300 2113944A40 CAP CHIP 100pF 5% 50V
COG
C1301 2113945B02 CAP CHIP 10000pF 10%
25V X7R
C1302 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
Reference
Designator
Motorola
Part Number
Description
C1303 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C1304 2113944A40 CAP CHIP 100pF 5% 50V
COG
C1305 2113944A40 CAP CHIP 100pF 5% 50V
COG
C1306 2113945B02 CAP CHIP 10000pF 10%
25V X7R
C1307 2113945B02 CAP CHIP 10000pF 10%
25V X7R
C2100 2113946N03 CAP CHIP 2.2uF +80%/-
20% 16V Y5V
C2101 2313960D07 CAP TANT 10.0uF 10%
16V
C2102 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2103 2113946F05 CAP CHIP 10uF 10% 6.3V
X5R
C2104 2188155V02 CAP CHIP 22uF 10% 10V
C2105 2113946N03 CAP CHIP 2.2uF +80%/-
20% 16V Y5V
C2106 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2107 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2108 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2109 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2110 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2111 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2200 2313960G32 CAP TANT 10.0uF 10%
35V
C2201 2313960G32 CAP TANT 10.0uF 10%
35V
C2202 2311049C49 CAP TANT 100uF 10%
16V
C2204 2113945B04 CAP CHIP 22000pF 10%
25V X7R
C2205 2113945A01 CAP CHIP 220pF 10% 50V
X7R
C2206 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2207 2313960G32 CAP TANT 10.0uF 10%
35V
Reference
Designator
Motorola
Part Number
Description
C2208 2113946N03 CAP CHIP 2.2uF +80%/-
20% 16V Y5V
C2301 2113944A40 CAP CHIP 100pF 5% 50V
COG
C2302 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2303 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2304 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2305 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2306 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2307 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2308 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2309 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2310 2113945A05 CAP CHIP 470pF 10% 50V
X7R
C2311 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2312 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2313 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2314 NOTPLACED GCAM DUMMY PART
NUMBER
C2315 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2316 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2317 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2318 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2319 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C2320 NOTPLACED GCAM DUMMY PART
NUMBER
C2321 NOTPLACED GCAM DUMMY PART
NUMBER
C3100 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C3101 2360567A07 CAP TANT 150uF
Reference
Designator
Motorola
Part Number
Description
