Motorola Astro XTL 1500

Schematics, Component Location Diagrams, and Parts Lists: Control Head Main Board 7-19
6815854H01-A June 16, 2005
C3102 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C3103 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C3104 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C3105 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C3106 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C3107 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C3200 NOTPLACED GCAM DUMMY PART
NUMBER
C3201 2113945A69 CAP CHIP 3900pF 10%
50V X7R
C3202 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C3203 2313960F30 CAP TANT 47.0uF 10%
10V
C3204 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C3205 2113944A40 CAP CHIP 100pF 5% 50V
COG
C3207 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C3208 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C3209 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C3210 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C3211 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C3212 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C3213 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C3214 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C4100 2113944A40 CAP CHIP 100pF 5% 50V
COG
C4101 2113944A40 CAP CHIP 100pF 5% 50V
COG
C4200 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
Reference
Designator
Motorola
Part Number
Description
C4201 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C4202 2113945A09 CAP CHIP 1000pF 10%
50V X7R
C4203 NOTPLACED GCAM DUMMY PART
NUMBER
C4204 NOTPLACED GCAM DUMMY PART
NUMBER
C4205 NOTPLACED GCAM DUMMY PART
NUMBER
C4206 NOTPLACED GCAM DUMMY PART
NUMBER
C4207 NOTPLACED GCAM DUMMY PART
NUMBER
C4208 NOTPLACED GCAM DUMMY PART
NUMBER
C4209 NOTPLACED GCAM DUMMY PART
NUMBER
C4210 NOTPLACED GCAM DUMMY PART
NUMBER
C4211 NOTPLACED GCAM DUMMY PART
NUMBER
C4212 NOTPLACED GCAM DUMMY PART
NUMBER
C5000 2113944A40 CAP CHIP 100pF 5% 50V
COG
C5001 2113945A05 CAP CHIP 470pF 10% 50V
X7R
C5002 2113944A40 CAP CHIP 100pF 5% 50V
COG
C5003 2113944A40 CAP CHIP 100pF 5% 50V
COG
C5004 2113945A01 CAP CHIP 220pF 10% 50V
X7R
C5005 2113945A01 CAP CHIP 220pF 10% 50V
X7R
C5006 2113945A01 CAP CHIP 220pF 10% 50V
X7R
C5007 2113945G91 CAP CHIP 100000pF 10%
50V X7R
C5008 2113945G91 CAP CHIP 100000pF 10%
50V X7R
C5009 2113945G91 CAP CHIP 100000pF 10%
50V X7R
C5010 NOTPLACED GCAM DUMMY PART
NUMBER
Reference
Designator
Motorola
Part Number
Description
C5011 2113944A40 CAP CHIP 100pF 5% 50V
COG
C5012 2113944A40 CAP CHIP 100pF 5% 50V
COG
C5013 2113944A40 CAP CHIP 100pF 5% 50V
COG
C5014 2113944A40 CAP CHIP 100pF 5% 50V
COG
C5015 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C5016 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
C5017 NOTPLACED GCAM DUMMY PART
NUMBER
C5018 2113946K02 CAP CHIP 0.1uF +80%/-
20% 16V Y5V
D1000 4888722V03 DIODE SCHOTTKY
RB715F
D1001 4888722V03 DIODE SCHOTTKY
RB715F
D2200 4813978P07 DIODE DUAL MMBD7000
D2201 4813978B17 DIODE SCHOTTKY 30V
2.0A
D3200 4813978A25 DIODE SCHOTTKY 30V
D3203 4813978A25 DIODE SCHOTTKY 30V
D3204 4813978A25 DIODE SCHOTTKY 30V
D3207 4813978A25 DIODE SCHOTTKY 30V
D3208 4813978A25 DIODE SCHOTTKY 30V
D4100 4815813H01 LED CHIP HT-S91SD
D4101 4815816H01 LED CHIP HT-S91Y
D4102 4815817H01 LED CHIP HT-S91YG
D4103 4815809H01 LED CHIP HT-S91UYG
D4104 4815809H01 LED CHIP HT-S91UYG
D4105 4815809H01 LED CHIP HT-S91UYG
D4106 4815809H01 LED CHIP HT-S91UYG
D4107 4815809H01 LED CHIP HT-S91UYG
D4108 4815814H02 LED CHIP HT-S91D
E2100 2480067M02 CHK RF CHIP BEAD IND
BLM21A
E2101 2480067M02 CHK RF CHIP BEAD IND
BLM21A
E2102 2480067M02 CHK RF CHIP BEAD IND
BLM21A
J5000 0915213H01 CONN 70-PINS REAR
Reference
Designator
Motorola
Part Number
Description
L2100 2416090H01 POWER IND 6.8uH 20%
L2101 2416089H01 POWER IND 10uH 20%
L2200 2416090H01 POWER IND 6.8uH 20%
L2201 2416086H01 POWER IND 22uH 30%
P2300 2815146H01 CONN 16-PINS AVR
P3200 2815159H01 CONN 12-PINS GCAI
P4200 2815146H01 CONN 16-PINS VOL POT
P4201 2815162H01 CONN 2-PINS SPKR
P4202 2815146H01 CONN 16-PINS DISPLAY
PCB 8415212H01 MAIN PCB
Q1000 4813972A17 TSTR MOSFET N-CHAN
MGSF1N02
Q1001 4813972A17 TSTR MOSFET N-CHAN
MGSF1N02
Q1002 4813972A17 TSTR MOSFET N-CHAN
MGSF1N02
Q2100 4813970A62 TSTR MOSFET P-CHAN
NTH5441T1
Q2101 4805921T09 TSTR DUAL ROHM
FMG8A
Q2102 4813973M07 TSTR NPN 40V .2A
MMBT3904
Q2200 4813973M07 TSTR NPN 40V .2A
MMBT3904
Q2201 4813973A81 TSTR DUAL NPN-PNP
MUN5311
Q2202 4815332H01 TSTR MOSFET P-CHAN
NTD2955
Q2300 4813973A42 TSTR NPN DIG 47K/47K
MUN2213
Q2301 4813973M07 TSTR NPN 40V .2A
MMBT3904
Q2302 4813973A42 TSTR NPN DIG 47K/47K
MUN2213
Q2303 4813973A42 TSTR NPN DIG 47K/47K
MUN2213
Q2304 4813973M07 TSTR NPN 40V .2A
MMBT3904
Q2305 4813973M07 TSTR NPN 40V .2A
MMBT3904
Q2306 4813973A81 TSTR DUAL NPN-PNP
MUN5311
Q2309 4813973M07 TSTR NPN 40V .2A
MMBT3904
Q2310 4813973M07 TSTR NPN 40V .2A
MMBT3904
Reference
Designator
Motorola
Part Number
Description
