Motorola Astro XTL 1500

7-20 Schematics, Component Location Diagrams, and Parts Lists: Control Head Main Board
June 16, 2005 6815854H01-A
Q3100 4805921T09 TSTR DUAL ROHM
FMG8A
Q3101 4805921T09 TSTR DUAL ROHM
FMG8A
Q3200 4813973M07 TSTR NPN 40V .2A
MMBT3904
Q4100 4809940E02 DTC114YE TSTR DIG NPN
Q4101 4809940E02 DTC114YE TSTR DIG NPN
Q4102 4809940E02 DTC114YE TSTR DIG NPN
Q4103 4813973M07 TSTR NPN 40V .2A
MMBT3904
Q4104 4813973M07 TSTR NPN 40V .2A
MMBT3904
R1000 NOTPLACED GCAM DUMMY PART
NUMBER
R1001 0613952R01 RES CHIP 10K 5% 0402
R1002 0613952R66 RES CHIP 0 5% 0402
R1003 0613952R66 RES CHIP 0 5% 0402
R1005 0613952R01 RES CHIP 10K 5% 0402
R1006 NOTPLACED GCAM DUMMY PART
NUMBER
R1007 0613952R66 RES CHIP 0 5% 0402
R1008 0613952R01 RES CHIP 10K 5% 0402
R1009 0613952R66 RES CHIP 0 5% 0402
R1010 0613952R66 RES CHIP 0 5% 0402
R1011 0613952R74 RES CHIP 10M 5% 0402
R1012 NOTPLACED GCAM DUMMY PART
NUMBER
R1013 NOTPLACED GCAM DUMMY PART
NUMBER
R1014 0613952R66 RES CHIP 0 5% 0402
R1015 0613952Q89 RES CHIP 4K7 5% 0402
R1016 0613952R66 RES CHIP 0 5% 0402
R1017 0613952R74 RES CHIP 10M 5% 0402
R1018 0613952R74 RES CHIP 10M 5% 0402
R1019 0613952R41 RES CHIP 470K 5% 0402
R1020 NOTPLACED GCAM DUMMY PART
NUMBER
R1021 NOTPLACED GCAM DUMMY PART
NUMBER
R1022 NOTPLACED GCAM DUMMY PART
NUMBER
R1023 NOTPLACED GCAM DUMMY PART
NUMBER
Reference
Designator
Motorola
Part Number
Description
R1024 NOTPLACED GCAM DUMMY PART
NUMBER
R1025 NOTPLACED GCAM DUMMY PART
NUMBER
R1026 NOTPLACED GCAM DUMMY PART
NUMBER
R1027 0613952R66 RES CHIP 0 5% 0402
R1028 0613952R01 RES CHIP 10K 5% 0402
R1029 0613952R01 RES CHIP 10K 5% 0402
R1030 0613952R01 RES CHIP 10K 5% 0402
R1031 0613952R01 RES CHIP 10K 5% 0402
R1034 0613952Q25 RES CHIP 10 5% 0402
R1035 0613952Q25 RES CHIP 10 5% 0402
R1036 0613952R01 RES CHIP 10K 5% 0402
R1037 NOTPLACED GCAM DUMMY PART
NUMBER
R1038 0613952G67 RES CHIP 0 1% 0603
R1040 0613952R25 RES CHIP 100K 5% 0402
R1041 0613952R25 RES CHIP 100K 5% 0402
R1042 0613952R25 RES CHIP 100K 5% 0402
R1043 0613952R01 RES CHIP 10K 5% 0402
R1044 0613952Q47 RES CHIP 82 5% 0402
R1045 NOTPLACED GCAM DUMMY PART
NUMBER
R1046 NOTPLACED GCAM DUMMY PART
NUMBER
R1047 0613952R66 RES CHIP 0 5% 0402
R1048 NOTPLACED GCAM DUMMY PART
NUMBER
R1049 0613952R66 RES CHIP 0 5% 0402
R1050 0613952R01 RES CHIP 10K 5% 0402
R1051 0613952R01 RES CHIP 10K 5% 0402
R1052 NOTPLACED GCAM DUMMY PART
NUMBER
R1053 NOTPLACED GCAM DUMMY PART
NUMBER
R1054 NOTPLACED GCAM DUMMY PART
NUMBER
R1055 NOTPLACED GCAM DUMMY PART
NUMBER
R1056 0613952R01 RES CHIP 10K 5% 0402
R1057 0613952R01 RES CHIP 10K 5% 0402
R1058 0613952R01 RES CHIP 10K 5% 0402
Reference
Designator
Motorola
Part Number
Description
R1059 NOTPLACED GCAM DUMMY PART
NUMBER
R1060 0613952R01 RES CHIP 10K 5% 0402
R1061 0613952R01 RES CHIP 10K 5% 0402
R1062 0613952G67 RES CHIP 0 1% 0603
R1063 0613952R25 RES CHIP 100K 5% 0402
R1064 0613952R01 RES CHIP 10K 5% 0402
R1065 NOTPLACED GCAM DUMMY PART
NUMBER
R1066 0613952R01 RES CHIP 10K 5% 0402
R1067 0613952R01 RES CHIP 10K 5% 0402
R1068 0613952R01 RES CHIP 10K 5% 0402
R1069 0613952R01 RES CHIP 10K 5% 0402
R1070 0613952R01 RES CHIP 10K 5% 0402
R1200 0613952R01 RES CHIP 10K 5% 0402
R1201 0613952R01 RES CHIP 10K 5% 0402
R1202 NOTPLACED GCAM DUMMY PART
NUMBER
R1203 0613952R25 RES CHIP 100K 5% 0402
R1204 0613952R25 RES CHIP 100K 5% 0402
R1205 0613952R25 RES CHIP 100K 5% 0402
R1207 0613952Q37 RES CHIP 33 5% 0402
R1208 0613952Q37 RES CHIP 33 5% 0402
R1210 0613952Q37 RES CHIP 33 5% 0402
R1211 0613952Q37 RES CHIP 33 5% 0402
R1212 0613952Q37 RES CHIP 33 5% 0402
R1213 0613952Q37 RES CHIP 33 5% 0402
R1214 0613952Q89 RES CHIP 4K7 5% 0402
R1215 0613952Q89 RES CHIP 4K7 5% 0402
R1216 0613952Q37 RES CHIP 33 5% 0402
R1217 0613952Q37 RES CHIP 33 5% 0402
R1300 0613952G67 RES CHIP 0 1% 0603
R1301 0613952R01 RES CHIP 10K 5% 0402
R1302 0613952R01 RES CHIP 10K 5% 0402
R1303 0613952R01 RES CHIP 10K 5% 0402
R1304 0613952R01 RES CHIP 10K 5% 0402
R1305 0613952R01 RES CHIP 10K 5% 0402
R1306 0613952R01 RES CHIP 10K 5% 0402
R1308 0613952G67 RES CHIP 0 1% 0603
R1309 0613952G67 RES CHIP 0 1% 0603
R1310 0613952R66 RES CHIP 0 5% 0402
Reference
Designator
Motorola
Part Number
Description
R1311 NOTPLACED GCAM DUMMY PART
NUMBER
R1312 0613952R01 RES CHIP 10K 5% 0402
R1313 0613952R01 RES CHIP 10K 5% 0402
R1314 NOTPLACED GCAM DUMMY PART
NUMBER
R2100 0613952R01 RES CHIP 10K 5% 0402
R2102 0613952Q25 RES CHIP 10 5% 0402
R2103 0613952R01 RES CHIP 10K 5% 0402
R2104 0613952R01 RES CHIP 10K 5% 0402
R2105 0613952R01 RES CHIP 10K 5% 0402
R2107 NOTPLACED GCAM DUMMY PART
NUMBER
R2108 0613952G67 RES CHIP 0 1% 0603
R2109 0613952R66 RES CHIP 0 5% 0402
R2110 0613952R66 RES CHIP 0 5% 0402
R2111 0613952R66 RES CHIP 0 5% 0402
R2112 0613952R66 RES CHIP 0 5% 0402
R2115 0613952R23 RES CHIP 82K 5% 0402
R2116 0613952R07 RES CHIP 18K 5% 0402
R2117 0613952R01 RES CHIP 10K 5% 0402
R2118 0613952R01 RES CHIP 10K 5% 0402
R2119 0613952R01 RES CHIP 10K 5% 0402
R2120 0613952R01 RES CHIP 10K 5% 0402
R2121 0613952R01 RES CHIP 10K 5% 0402
R2122 0613952R01 RES CHIP 10K 5% 0402
R2123 0613952R01 RES CHIP 10K 5% 0402
R2126 0613952R01 RES CHIP 10K 5% 0402
R2128 NOTPLACED GCAM DUMMY PART
NUMBER
R2129 0613952R01 RES CHIP 10K 5% 0402
R2130 NOTPLACED GCAM DUMMY PART
NUMBER
R2131 0613952R66 RES CHIP 0 5% 0402
R2132 0613952R66 RES CHIP 0 5% 0402
R2133 0613952R66 RES CHIP 0 5% 0402
R2134 0613952R66 RES CHIP 0 5% 0402
R2135 0613952R01 RES CHIP 10K 5% 0402
R2136 NOTPLACED GCAM DUMMY PART
NUMBER
R2137 0613952R01 RES CHIP 10K 5% 0402
R2138 0613952R66 RES CHIP 0 5% 0402
Reference
Designator
Motorola
Part Number
Description
