Motorola Astro XTL 1500

Schematics, Component Location Diagrams, and Parts Lists: Control Head Main Board 7-21
6815854H01-A June 16, 2005
R2139 0613952G67 RES CHIP 0 1% 0603
R2140 0613952R01 RES CHIP 10K 5% 0402
R2141 0613952R01 RES CHIP 10K 5% 0402
R2200 NOTPLACED GCAM DUMMY PART
NUMBER
R2201 0613952G67 RES CHIP 0 1% 0603
R2202 0613952G67 RES CHIP 0 1% 0603
R2203 0613952R01 RES CHIP 10K 5% 0402
R2204 0613952J17 RES CHIP 47K 5% 0603
R2205 0613952J08 RES CHIP 20K 5% 0603
R2206 0613952Z44 RES CHIP 3K3 1% 0402
R2207 0613952Q89 RES CHIP 4K7 5% 0402
R2208 0613952J13 RES CHIP 33K 5% 0603
R2209 0613952R66 RES CHIP 0 5% 0402
R2210 0613952R25 RES CHIP 100K 5% 0402
R2211 0613952J17 RES CHIP 47K 5% 0603
R2212 0613952G67 RES CHIP 0 1% 0603
R2213 0613952P14 RES CHIP 137K 1% 0402
R2214 0613952R25 RES CHIP 100K 5% 0402
R2215 0613952H73 RES CHIP 1K 5% 0603
R2216 0613952R25 RES CHIP 100K 5% 0402
R2300 0613952R66 RES CHIP 0 5% 0402
R2301 0613952R01 RES CHIP 10K 5% 0402
R2302 0613952R66 RES CHIP 0 5% 0402
R2303 0613952R01 RES CHIP 10K 5% 0402
R2304 0613952R01 RES CHIP 10K 5% 0402
R2305 0613952R01 RES CHIP 10K 5% 0402
R2306 0613952R66 RES CHIP 0 5% 0402
R2307 0613952R01 RES CHIP 10K 5% 0402
R2308 0613952R01 RES CHIP 10K 5% 0402
R2309 0613952R66 RES CHIP 0 5% 0402
R2310 0613952R01 RES CHIP 10K 5% 0402
R2311 0613952R01 RES CHIP 10K 5% 0402
R2313 0613952R01 RES CHIP 10K 5% 0402
R2314 0613952R01 RES CHIP 10K 5% 0402
R2315 0613952J09 RES CHIP 22K 5% 0603
R2316 NOTPLACED GCAM DUMMY PART
NUMBER
R2318 0613952R01 RES CHIP 10K 5% 0402
R2319 0613952Q89 RES CHIP 4K7 5% 0402
R2320 0613952J17 RES CHIP 47K 5% 0603
Reference
Designator
Motorola
Part Number
Description
R2322 0613952R66 RES CHIP 0 5% 0402
R2323 0613952R01 RES CHIP 10K 5% 0402
R2324 0613952R01 RES CHIP 10K 5% 0402
R2325 0613952R01 RES CHIP 10K 5% 0402
R2326 0613952Q75 RES CHIP 1K2 5% 0402
R3100 0613952R66 RES CHIP 0 5% 0402
R3101 0613952R66 RES CHIP 0 5% 0402
R3102 0613952R66 RES CHIP 0 5% 0402
R3103 0613952R25 RES CHIP 100K 5% 0402
R3104 0613952R01 RES CHIP 10K 5% 0402
R3105 0613952R01 RES CHIP 10K 5% 0402
R3106 NOTPLACED GCAM DUMMY PART
NUMBER
R3107 NOTPLACED GCAM DUMMY PART
NUMBER
R3108 0613952Q77 RES CHIP 1K5 5% 0402
R3109 0613952R66 RES CHIP 0 5% 0402
R3110 0613952R66 RES CHIP 0 5% 0402
R3111 0613952R66 RES CHIP 0 5% 0402
R3112 0613952Q33 RES CHIP 22 5% 0402
R3113 0613952R66 RES CHIP 0 5% 0402
R3114 0613952Q33 RES CHIP 22 5% 0402
R3115 0613952R25 RES CHIP 100K 5% 0402
R3116 0613952R05 RES CHIP 15K 5% 0402
R3117 0613952R05 RES CHIP 15K 5% 0402
R3118 0613952R01 RES CHIP 10K 5% 0402
R3119 NOTPLACED GCAM DUMMY PART
NUMBER
R3120 0613952R66 RES CHIP 0 5% 0402
R3121 0613952R66 RES CHIP 0 5% 0402
R3122 0613952R01 RES CHIP 10K 5% 0402
R3200 0613952R05 RES CHIP 15K 5% 0402
R3201 0613952R05 RES CHIP 15K 5% 0402
R3202 0613952R05 RES CHIP 15K 5% 0402
R3203 0613952Q81 RES CHIP 2K2 5% 0402
R3204 0613952Q81 RES CHIP 2K2 5% 0402
R3205 0613952R01 RES CHIP 10K 5% 0402
R3207 0613952R01 RES CHIP 10K 5% 0402
R3209 0613952R01 RES CHIP 10K 5% 0402
R3211 0613952R01 RES CHIP 10K 5% 0402
R3212 0613952G67 RES CHIP 0 1% 0603
R3213 0613952G67 RES CHIP 0 1% 0603
Reference
Designator
Motorola
Part Number
Description
R3214 0613952R66 RES CHIP 0 5% 0402
R3215 0613952R01 RES CHIP 10K 5% 0402
R3216 0613952R01 RES CHIP 10K 5% 0402
R3217 0613952R01 RES CHIP 10K 5% 0402
R3218 0613952R01 RES CHIP 10K 5% 0402
R3219 0613952G67 RES CHIP 0 1% 0603
R3220 NOTPLACED GCAM DUMMY PART
NUMBER
R3221 0613952R25 RES CHIP 100K 5% 0402
R3222 NOTPLACED GCAM DUMMY PART
NUMBER
R3223 0613952R01 RES CHIP 10K 5% 0402
R4100 0613952R01 RES CHIP 10K 5% 0402
R4101 0613952R01 RES CHIP 10K 5% 0402
R4103 0613952Q73 RES CHIP 1K 5% 0402
R4104 0613952Q75 RES CHIP 1K2 5% 0402
R4105 0613952Q75 RES CHIP 1K2 5% 0402
R4106 0613952Q73 RES CHIP 1K 5% 0402
R4107 0613952G67 RES CHIP 0 1% 0603
R4108 0613952H35 RES CHIP 27 5% 0603
R4109 0613952H47 RES CHIP 82 5% 0603
R4110 0613952Q73 RES CHIP 1K 5% 0402
R4200 0613952R01 RES CHIP 10K 5% 0402
R4201 0613952R01 RES CHIP 10K 5% 0402
R4202 0613952R01 RES CHIP 10K 5% 0402
R4203 0613952R01 RES CHIP 10K 5% 0402
R4204 0613952Q49 RES CHIP 100 5% 0402
R4205 0613952Q49 RES CHIP 100 5% 0402
R4206 0613952R01 RES CHIP 10K 5% 0402
R4207 0613952R66 RES CHIP 0 5% 0402
R4208 0613952R66 RES CHIP 0 5% 0402
R4209 0613952R66 RES CHIP 0 5% 0402
R4210 0613952R66 RES CHIP 0 5% 0402
R4211 0613952R66 RES CHIP 0 5% 0402
R4212 0613952R66 RES CHIP 0 5% 0402
R4213 0613952R66 RES CHIP 0 5% 0402
R4214 0613952R66 RES CHIP 0 5% 0402
R4215 0613952R66 RES CHIP 0 5% 0402
R4216 0613952R66 RES CHIP 0 5% 0402
R4217 0613952R66 RES CHIP 0 5% 0402
R4218 0613952R66 RES CHIP 0 5% 0402
Reference
Designator
Motorola
Part Number
Description
R4219 0613952R66 RES CHIP 0 5% 0402
R5000 0613952R66 RES CHIP 0 5% 0402
R5001 0613952R66 RES CHIP 0 5% 0402
R5002 0613952R66 RES CHIP 0 5% 0402
R5003 0613952R66 RES CHIP 0 5% 0402
S4200 4015133H01 SW ENDLESS ROTARY
SH1000 2615260H01 MICROPROCESSOR
SHIELD
SH2200 2615259H01 SWITCHING REGULATOR
SHIELD
U1000 5185941F53 IC OMAP330 MICROPRO-
CESSOR
U1001 5102836C11 IC ANLG SW FSA4157
U1002 5114007A07 IC QUAD NON-INVTR
BUFFER
U1003 5102836C11 IC ANLG SW FSA4157
U1004 5114000A48 IC SNGL INVTR 1GU04
U1005 5102836C11 IC ANLG SW FSA4157
U1006 5102836C11 IC ANLG SW FSA4157
U1007 5102836C11 IC ANLG SW FSA4157
U1008 5102836C11 IC ANLG SW FSA4157
U1009 5114007A43 IC SCHMITT INVTER
NL17SZ14
U1200 5114007A07 IC QUAD NON-INVTR
BUFFER
U1300 5115004H02 IC 8MB SDRAM
U1301 5115836H01 IC 2MB FLASH
U2100 5115331H01 IC PWR MGT TPS65012
U2101 5114000B34 IC SNGL 2-INPUT NAND
GATE
U2102 5114000B34 IC SNGL 2-INPUT NAND
GATE
U2103 5114000B34 IC SNGL 2-INPUT NAND
GATE
U2104 5114000B34 IC SNGL 2-INPUT NAND
GATE
U2200 5115808H01 IC SWITCHING REGULA-
TOR 2.5A
U2201 5116021H01 IC VOLTAGE REGULATOR
U2302 5114007M28 IC SNGL D FLIP-FLOP
NL17SZ74
U2303 5116018H01 IC ATTINY13 MICROCON-
TROLLER
Reference
Designator
Motorola
Part Number
Description
