Schematics, Component Location Diagrams, and Parts Lists: HUD4022A (VHF) Main Board 7-57
6815854H01-A June 15, 2005
C0518 2185802B01 CAP 10V 4.7UF
C0519 2113743L41 CAP CHIP 10000 PF 10%
C0520 2113743M24 CAP CHIP 100000 PF +80
C0521 2185802B01 CAP 10V 4.7UF
C0522 2185802B01 CAP 10V 4.7UF
C0523 2113743M24 CAP CHIP 100000 PF +80
C0524 2113743M24 CAP CHIP 100000 PF +80
C0525 2113928E01 CAP CER CHIP 1.0 UF 10
C0526 2113743L41 CAP CHIP 10000 PF 10%
C0527 2185802B01 CAP 10V 4.7UF
C0528 2113743M24 CAP CHIP 100000 PF +80
C0529 2185802B01 CAP 10V 4.7UF
C0531 2113741N69 CAP CHIP CL2 X7R 10% 1
C0532 2113741Y32 CAP CER 1,000,000 10%"
C0533 2311049C47 CAP TANT CHIP 22.0UF 1
C0534 2113743M24 CAP CHIP 100000 PF +80
C0535 2113743M24 CAP CHIP 100000 PF +80
C0536 2113743M24 CAP CHIP 100000 PF +80
C0600 2113743M24 CAP CHIP 100000 PF +80
C0601 2113743M24 CAP CHIP 100000 PF +80
C0603 2113743M24 CAP CHIP 100000 PF +80
C0604 2113743M24 CAP CHIP 100000 PF +80
C0605 2113743M24 CAP CHIP 100000 PF +80
C0606 2113743M24 CAP CHIP 100000 PF +80
C0610 2113743M24 CAP CHIP 100000 PF +80
C0611 2113743M24 CAP CHIP 100000 PF +80
C0613 2113743M24 CAP CHIP 100000 PF +80
C0614 2113743M24 CAP CHIP 100000 PF +80
C0616 2113743N50 CAP CHIP 100 PF 5% COG
C0700 2113743N50 CAP CHIP 100 PF 5% COG
C0701 2113743N50 CAP CHIP 100 PF 5% COG
C0702 2113743N50 CAP CHIP 100 PF 5% COG
C0703 2113743N50 CAP CHIP 100 PF 5% COG
C0704 2113743N50 CAP CHIP 100 PF 5% COG
C0705 2113743N50 CAP CHIP 100 PF 5% COG
C0706 2113743N50 CAP CHIP 100 PF 5% COG
C0708 2113743N50 CAP CHIP 100 PF 5% COG
C0709 2113743N50 CAP CHIP 100 PF 5% COG
C0710 2113743N50 CAP CHIP 100 PF 5% COG
C0711 2113743N50 CAP CHIP 100 PF 5% COG
C0712 2113743N50 CAP CHIP 100 PF 5% COG
Reference
Designator
Motorola
Part Number
Description
C0713 2113743L01 CAP CHIP 220 PF 10% X7
C0714 2113743L01 CAP CHIP 220 PF 10% X7
C0901 2113743M24 CAP CHIP 100000 PF +80
C0902 2113743M24 CAP CHIP 100000 PF +80
C0903 2113743M24 CAP CHIP 100000 PF +80
C0904 2113743L01 CAP CHIP 220 PF 10% X7
C0905 2113743M24 CAP CHIP 100000 PF +80
C0906 2113743M24 CAP CHIP 100000 PF +80
C0907 2113743M24 CAP CHIP 100000 PF +80
C0908 2113743M24 CAP CHIP 100000 PF +80
C0909 2113743M24 CAP CHIP 100000 PF +80
C0910 2113743M24 CAP CHIP 100000 PF +80
C0911 2113743N50 CAP CHIP 100 PF 5% COG
C0912 2113743N50 CAP CHIP 100 PF 5% COG
C0913 2113743N50 CAP CHIP 100 PF 5% COG
C0914 2113743N38 CAP CHIP 33.0 PF 5% CO
C0915 2113743N50 CAP CHIP 100 PF 5% COG
C0916 2113743M24 CAP CHIP 100000 PF +80
C0917 2113743N50 CAP CHIP 100 PF 5% COG
C0918 2113743N50 CAP CHIP 100 PF 5% COG
C0919 2113743N50 CAP CHIP 100 PF 5% COG
C0920 2113743M24 CAP CHIP 100000 PF +80
C0922 2113743N50 CAP CHIP 100 PF 5% COG
C0923 2113743N50 CAP CHIP 100 PF 5% COG
C0924 2113743E12 CAP CHIP .047 UF 10% X
C0930 2113743N50 CAP CHIP 100 PF 5% COG
C0933 2113743N50 CAP CHIP 100 PF 5% COG
C0934 2113743N50 CAP CHIP 100 PF 5% COG
C0935 2113743N50 CAP CHIP 100 PF 5% COG
C0936 2113743M24 CAP CHIP 100000 PF +80
C0937 2113743M24 CAP CHIP 100000 PF +80
C0940 2113743M24 CAP CHIP 100000 PF +80
C0941 2113743S01 CAP CER CHIP 1.0 UF 10
C0942 2113743S01 CAP CER CHIP 1.0 UF 10
C0943 2113743L41 CAP CHIP 10000 PF 10%
C0944 2113743M24 CAP CHIP 100000 PF +80
C0945 2185802B01 CAP 10V 4.7UF
C0950 2113741N69 CAP CHIP CL2 X7R 10% 1
C0951 2113741Y32 CAP CER 1,000,000 10%"
C0952 2113743E20 CAP CHIP .10 UF 10%
C0953 2311049C47 CAP TANT CHIP 22.0UF 1
Reference
Designator
Motorola
Part Number
Description
C0954 2113743E20 CAP CHIP .10 UF 10%
C0955 2113741N69 CAP CHIP CL2 X7R 10% 1
C0956 2311049C06 CAP TANT CHIP 22 UF 35
C0957 2113743M24 CAP CHIP 100000 PF +80
C0959 2113743M24 CAP CHIP 100000 PF +80
C0960 2113743M24 CAP CHIP 100000 PF +80
C0961 2113743M24 CAP CHIP 100000 PF +80
C0963 2113743N50 CAP CHIP 100 PF 5% COG
C0964 2113743N50 CAP CHIP 100 PF 5% COG
C0965 2113743N50 CAP CHIP 100 PF 5% COG
C0966 2113743N50 CAP CHIP 100 PF 5% COG
C0968 2113743N50 CAP CHIP 100 PF 5% COG
C0969 2113743N50 CAP CHIP 100 PF 5% COG
C0970 2113743N50 CAP CHIP 100 PF 5% COG
C0972 2113743E07 CER CHIP CAP .022UF
C0973 2113928E01 CAP CER CHIP 1.0 UF 10
C0974 2113743M24 CAP CHIP 100000 PF +80
C0975 2113743N50 CAP CHIP 100 PF 5% COG
C0976 2113743N50 CAP CHIP 100 PF 5% COG
C0978 2113743N50 CAP CHIP 100 PF 5% COG
C0979 2113743M24 CAP CHIP 100000 PF +80
C0980 2113743M24 CAP CHIP 100000 PF +80
C0981 2113743M24 CAP CHIP 100000 PF +80
C0982 2311049C47 CAP TANT CHIP 22.0UF 1
C0983 2113743N50 CAP CHIP 100 PF 5% COG
C0984 2113743M24 CAP CHIP 100000 PF +80
C0985 2113743M24 CAP CHIP 100000 PF +80
C0986 2113743M24 CAP CHIP 100000 PF +80
C0987 2113743M24 CAP CHIP 100000 PF +80
C0997 2113740F47 CAP CHIP REEL CL1 +/-3
C0998 2113741F01 CAP CHIP CL2 X7R REEL
C3000 2113743N28 CAP CHIP 12.0 PF 5% CO
C3001 2113743S01 CAP CER CHIP 1.0 UF 10
C3002 2113743N46 CAP CHIP 68.0 PF 5% CO
C3003 2113743L25 CAP CHIP 2200 PF 10% X
C3004 2113743B27 CAP CHIP .680 UF 10% X
C3005 2113743A27 CAP CHIP .470 UF 10% 1
C3007 2113928N01 CAP CER CHIP 0.1UF 10%
C3008 2113928N01 CAP CER CHIP 0.1UF 10%
C3009 2113928N01 CAP CER CHIP 0.1UF 10%
C3010 2113928N01 CAP CER CHIP 0.1UF 10%
Reference
Designator
Motorola
Part Number
Description
C3011 2113928N01 CAP CER CHIP 0.1UF 10%
C3012 2113928N01 CAP CER CHIP 0.1UF 10%
C3013 2113928N01 CAP CER CHIP 0.1UF 10%
C3014 2113928N01 CAP CER CHIP 0.1UF 10%
C3016 2113928N01 CAP CER CHIP 0.1UF 10%
C3017 2113928N01 CAP CER CHIP 0.1UF 10%
C3018 2113928N01 CAP CER CHIP 0.1UF 10%
C3019 2113928N01 CAP CER CHIP 0.1UF 10%
C3020 2113743N50 CAP CHIP 100 PF 5% COG
C3021 2113743N50 CAP CHIP 100 PF 5% COG
C3022 2113743N50 CAP CHIP 100 PF 5% COG
C3023 2113743N50 CAP CHIP 100 PF 5% COG
C3024 2113743N46 CAP CHIP 68.0 PF 5% CO
C3025 2113743N42 CAP CHIP 47.0 PF 5% CO
C3026 2113743N36 CAP CHIP 27.0 PF 5% CO
C3027 2113743N33 CAP CHIP 20.0 PF 5% CO
C3028 2113743N33 CAP CHIP 20.0 PF 5% CO
C3029 2113743N30 CAP CHIP 15.0 PF 5% CO
C3030 2113743N28 CAP CHIP 12.0 PF 5% CO
C3032 2113740L32 CAP 39.0 PF 50V 2.0 %
C3035 2113743L41 CAP CHIP 10000 PF 10%
C3036 2113743L41 CAP CHIP 10000 PF 10%
C3037 2113743L41 CAP CHIP 10000 PF 10%
C3038 2113743L41 CAP CHIP 10000 PF 10%
C3039 2113743L41 CAP CHIP 10000 PF 10%
C3040 2113743L41 CAP CHIP 10000 PF 10%
C3041 2113743L41 CAP CHIP 10000 PF 10%
C3042 2113743L17 CAP CHIP 1000 PF 10% X
C3043 2113743F18 CAP CHIP 2.2 UF 16V +8
C3044 2113743E20 CAP CHIP .10 UF 10%
C3045 2113743A31 CAP CHIP 1.0 UF 10% X7
C3046 2113743L33 CAP CHIP 4700 PF 10% X
C3047 2113740F58 CAP CHIP REEL CL1 +/-3
C3048 2113743N09 CAP CHIP 2.0 PF +-.25P
C3251 2113740F67 CAP CHIP CL1 +/-30 470
C3252 2113740F67 CAP CHIP CL1 +/-30 470
C3253 2113740F67 CAP CHIP CL1 +/-30 470
C3254 2113740F67 CAP CHIP CL1 +/-30 470
C3255 2113741F25 CAP CHIP CL2 X7R REEL
C3256 2113740F67 CAP CHIP CL1 +/-30 470
C3257 2113740L37 CAP 62.0 PF 50V 2.0 %
Reference
Designator
Motorola
Part Number
Description
