7-58 Schematics, Component Location Diagrams, and Parts Lists: HUD4022A (VHF) Main Board

June 15, 2005 6815854H01-A

C3258 2113740L42 CAP 100.0 PF 50V 2.0 %

C3259 2113740L21 CAP 13.0 PF 50V 2.0 %

C3260 2113741F25 CAP CHIP CL2 X7R REEL

C3261 2113741F25 CAP CHIP CL2 X7R REEL

C3262 2113740F67 CAP CHIP CL1 +/-30 470

C3263 2113741F25 CAP CHIP CL2 X7R REEL

C3264 2113740L32 CAP 39.0 PF 50V 2.0 %

C3265 2113741F25 CAP CHIP CL2 X7R REEL

C3266 2113741F25 CAP CHIP CL2 X7R REEL

C3267 2113743K15 CER CHIP CAP .100UF

C3268 2113743K15 CER CHIP CAP .100UF

C3269 2113741F25 CAP CHIP CL2 X7R REEL

C3270 2113740F67 CAP CHIP CL1 +/-30 470

C3271 2113741F49 CAP CHIP CL2 X7R REEL

C3272 2113740F67 CAP CHIP CL1 +/-30 470

C3273 2113741F25 CAP CHIP CL2 X7R REEL

C3274 2113743K15 CER CHIP CAP .100UF

C3275 2113743K15 CER CHIP CAP .100UF

C3277 2113740L41 CAP 91.0 PF 50V 2.0 %

C3278 2113740L39 CAP 75.0 PF 50V 2.0 %

C3279 2113740L24 CAP 18.0 PF 50V 2.0 %

C3280 2113741F25 CAP CHIP CL2 X7R REEL

C3282 2113740F67 CAP CHIP CL1 +/-30 470

C3283 2113741F25 CAP CHIP CL2 X7R REEL

C3284 2113741F25 CAP CHIP CL2 X7R REEL

C3286 2113741F25 CAP CHIP CL2 X7R REEL

C3287 2113740L31 CAP 36.0 PF 50V 2.0 %

C3288 2113740F67 CAP CHIP CL1 +/-30 470

C3289 2113743K15 CER CHIP CAP .100UF

C3290 2113740L35 CAP 51.0 PF 50V 2.0 %

C3291 2113740F41 CAP CHIP REEL CL1 +/-3

C3292 2113741F25 CAP CHIP CL2 X7R REEL

C3293 2113741F25 CAP CHIP CL2 X7R REEL

C3294 2113741F25 CAP CHIP CL2 X7R REEL

C3295 2113740L37 CAP 62.0 PF 50V 2.0 %

C3296 2113740L26 CAP 22.0 PF 50V 2.0 %

C3297 2113740L15 CAP CER CHIP 7.5 PF +-

C3298 2113740L37 CAP 62.0 PF 50V 2.0 %

C3299 2113740L32 CAP 39.0 PF 50V 2.0 %

C3300 2113740L37 CAP 62.0 PF 50V 2.0 %

C3301 2113740F67 CAP CHIP CL1 +/-30 470

Reference

Designator

Motorola

Part Number

Description

C3302 2113740F67 CAP CHIP CL1 +/-30 470

C3303 2113741F49 CAP CHIP CL2 X7R REEL

C3304 2113741F49 CAP CHIP CL2 X7R REEL

C3305 2113740F67 CAP CHIP CL1 +/-30 470

C3306 2113740F67 CAP CHIP CL1 +/-30 470

C3307 2113741F49 CAP CHIP CL2 X7R REEL

C3308 2113741F49 CAP CHIP CL2 X7R REEL

C3309 2113741F49 CAP CHIP CL2 X7R REEL

C3310 2113740L27 CAP 24.0 PF 50V 2.0 %

C3311 2113740L18 CAP CER CHIP 10.0 PF +

C3312 2113743K15 CER CHIP CAP .100UF

C3400 2113740F67 CAP CHIP CL1 +/-30 470

C3401 2113741F49 CAP CHIP CL2 X7R REEL

C3402 2113741F49 CAP CHIP CL2 X7R REEL

C3403 2113741F49 CAP CHIP CL2 X7R REEL

C3404 2113741F49 CAP CHIP CL2 X7R REEL

C3405 2113741F49 CAP CHIP CL2 X7R REEL

C3406 2113741F49 CAP CHIP CL2 X7R REEL

C3409 2113740L31 CAP 36.0 PF 50V 2.0 %

C3410 2113740F67 CAP CHIP CL1 +/-30 470

C3411 2113740F67 CAP CHIP CL1 +/-30 470

C3412 2113740F67 CAP CHIP CL1 +/-30 470

C3414 2113740L31 CAP 36.0 PF 50V 2.0 %

C3415 2113740F19 CAP CHIP REEL CL1 +/-3

C3416 2113740L09 CAP CER CHIP 4.3 PF +-

C3417 2113740L09 CAP CER CHIP 4.3 PF +-

C3418 2113741F25 CAP CHIP CL2 X7R REEL

C3420 2113741F25 CAP CHIP CL2 X7R REEL

C3421 2113740L09 CAP CER CHIP 4.3 PF +-

C3424 2113741F49 CAP CHIP CL2 X7R REEL

C3500 2113743L09 CAP CHIP 470 PF 10% X7

C3501 2113743L41 CAP CHIP 10000 PF 10%

C3503 2113743N38 CAP CHIP 33.0 PF 5% CO

C3504 2113743N38 CAP CHIP 33.0 PF 5% CO

C3505 2113743L41 CAP CHIP 10000 PF 10%

C3506 2113743L41 CAP CHIP 10000 PF 10%

C3508 2113743L17 CAP CHIP 1000 PF 10% X

C3511 2113743L17 CAP CHIP 1000 PF 10% X

C3517 2113743L09 CAP CHIP 470 PF 10% X7

C3520 2113743N26 CAP CHIP 10.0 PF 5% CO

C3521 2113743N34 CAP CHIP 22.0 PF 5% CO

Reference

Designator

Motorola

Part Number

Description

C3522 2113743L09 CAP CHIP 470 PF 10% X7

C3530 2113741N69 CAP CHIP CL2 X7R 10% 1

C3531 2111078B59 CAP CHIP RF 470 5 NPO

C3532 2111078B37 CAP CHIP RF 62 5 NPO 1

C3533 2111078B37 CAP CHIP RF 62 5 NPO 1

C3534 2111078B59 CAP CHIP RF 470 5 NPO

C3535 2113743L09 CAP CHIP 470 PF 10% X7

C3536 2113740G50 CAP CERAMIC CHIP 62

C3537 2111078B36 CAP CHIP RF 56 5 NPO 1

C3548 2113740G50 CAP CERAMIC CHIP 62

C3549 2111078B36 CAP CHIP RF 56 5 NPO 1

C3550 2113741N69 CAP CHIP CL2 X7R 10% 1

C3551 2111078B59 CAP CHIP RF 470 5 NPO

C3552 2111078B40 CAP CHIP RF 82 5 NPO 1

C3553 2111078B40 CAP CHIP RF 82 5 NPO 1

C3554 2111078B40 CAP CHIP RF 82 5 NPO 1

C3555 2111078B40 CAP CHIP RF 82 5 NPO 1

C3556 2111078B01 CAP CHIP RF 3.3 .25 NP

C3557 2111078B01 CAP CHIP RF 3.3 .25 NP

C3558 2111078B34 CAP CHIP RF 47 5 NPO 1

C3559 2111078B59 CAP CHIP RF 470 5 NPO

C3560 2311049C06 CAP TANT CHIP 22 UF 35

C3561 2113932E20 CAP CER CHP .10 UF 10%

C3562 2113932E20 CAP CER CHP .10 UF 10%

C3563 2113743L17 CAP CHIP 1000 PF 10% X

C3564 2113743L17 CAP CHIP 1000 PF 10% X

C3700 2113743L09 CAP CHIP 470 PF 10% X7

C3701 2111078B27 CAP CHIP RF 30 5 NPO 1

C3702 2113743N38 CAP CHIP 33.0 PF 5% CO

C3703 2113743L09 CAP CHIP 470 PF 10% X7

C3704 2113743N28 CAP CHIP 12.0 PF 5% CO

C3720 2111078B03 CAP CHIP RF 3.9 .25 NP

C3721 2111078B32 CAP CHIP RF 39 5 NPO 1

C3722 2111078B32 CAP CHIP RF 39 5 NPO 1

C3723 2111078B14 CAP CHIP RF 11 5 NPO 1

C3730 2113743L09 CAP CHIP 470 PF 10% X7

C3731 2113743N24 CAP CHIP 8.2 PF + -.5P

C3732 2113743N24 CAP CHIP 8.2 PF + -.5P

C3733 2113743L09 CAP CHIP 470 PF 10% X7

Reference

Designator

Motorola

Part Number

Description

C3734 2111078B59 CAP CHIP RF 470 5 NPO

C3735 2113743L09 CAP CHIP 470 PF 10% X7

C3736 2113743L09 CAP CHIP 470 PF 10% X7

C3750 2113743E20 CAP CHIP .10 UF 10%

C3751 2113743E20 CAP CHIP .10 UF 10%

C3752 2113743E20 CAP CHIP .10 UF 10%

C3753 2113743E20 CAP CHIP .10 UF 10%

C3754 2113743E20 CAP CHIP .10 UF 10%

C3755 2113743E20 CAP CHIP .10 UF 10%

C3757 2113740F67 CAP CHIP CL1 +/-30 470

C3758 2113740F67 CAP CHIP CL1 +/-30 470

C3759 2113740F67 CAP CHIP CL1 +/-30 470

C3761 2113740F67 CAP CHIP CL1 +/-30 470

C3762 2113743E20 CAP CHIP .10 UF 10%

C3763 2113743E20 CAP CHIP .10 UF 10%

C3764 2113743E20 CAP CHIP .10 UF 10%

C3765 2113743E20 CAP CHIP .10 UF 10%

C3766 2113743E20 CAP CHIP .10 UF 10%

C3767 2113743E20 CAP CHIP .10 UF 10%

C3768 2113743E20 CAP CHIP .10 UF 10%

C3769 2113743E20 CAP CHIP .10 UF 10%

C3770 2113740F67 CAP CHIP CL1 +/-30 470

C3771 2113740F67 CAP CHIP CL1 +/-30 470

C3772 2113740F67 CAP CHIP CL1 +/-30 470

C3773 2113740F67 CAP CHIP CL1 +/-30 470

C3774 2113740F67 CAP CHIP CL1 +/-30 470

C3775 2113740F67 CAP CHIP CL1 +/-30 470

C3776 2113740F67 CAP CHIP CL1 +/-30 470

C3777 2113740F67 CAP CHIP CL1 +/-30 470

C3778 2113740F67 CAP CHIP CL1 +/-30 470

C3779 2113740F67 CAP CHIP CL1 +/-30 470

C3780 2113740F67 CAP CHIP CL1 +/-30 470

C3781 2113740F67 CAP CHIP CL1 +/-30 470

C3782 2113740F67 CAP CHIP CL1 +/-30 470

C3783 2113740F67 CAP CHIP CL1 +/-30 470

C3784 2113740F67 CAP CHIP CL1 +/-30 470

C3785 2113740F67 CAP CHIP CL1 +/-30 470

C3786 2113743N32 CAP CHIP 18.0 PF 5% CO

C3787 2113740F32 CAP CHIP REEL CL1 +/-3

C3788 2113740F31 CAP CHIP REEL CL1 +/-3

C3790 2113740F67 CAP CHIP CL1 +/-30 470
