Schematics, Component Location Diagrams, and Parts Lists: HUD4022A (VHF) Main Board 7-59
6815854H01-A June 15, 2005
C3791 2113740F29 CAP CHIP REEL CL1 +/-3
C3792 2113740F29 CAP CHIP REEL CL1 +/-3
C3793 2113740F29 CAP CHIP REEL CL1 +/-3
C3794 2113740F29 CAP CHIP REEL CL1 +/-3
C3796 2113740F25 CAP CHIP REEL CL1 +/-3
C3797 2113740F25 CAP CHIP REEL CL1 +/-3
C3798 2113740L15 CAP CER CHIP 7.5 PF +-
C3799 2113740L15 CAP CER CHIP 7.5 PF +-
C3800 2113740F67 CAP CHIP CL1 +/-30 470
C3802 2113740F67 CAP CHIP CL1 +/-30 470
C3803 2113740F67 CAP CHIP CL1 +/-30 470
C3804 2113743N30 CAP CHIP 15.0 PF 5% CO
C3806 2113743S01 CAP CER CHIP 1.0 UF 10
C3807 2113743S01 CAP CER CHIP 1.0 UF 10
C3808 2113928N01 CAP CER CHIP 0.1UF 10%
C3809 2113740B88 CAP CHIP 5600PF 5%
C3810 2113743E20 CAP CHIP .10 UF 10%
C3811 2113932E07 CAP CER CHP .022 UF 10
C3813 2113740F67 CAP CHIP CL1 +/-30 470
C3814 2113740F67 CAP CHIP CL1 +/-30 470
C3815 2113740F67 CAP CHIP CL1 +/-30 470
C3816 2113741F49 CAP CHIP CL2 X7R REEL
C3817 2113740F67 CAP CHIP CL1 +/-30 470
C3818 2113740L09 CAP CER CHIP 4.3 PF +-
C3820 2113743T19 CAP 10UF 16V CER 3225
C3821 2113743T19 CAP 10UF 16V CER 3225
C3822 2113743T19 CAP 10UF 16V CER 3225
C3823 2113743T19 CAP 10UF 16V CER 3225
C3824 2113743N50 CAP CHIP 100 PF 5% COG
C3825 2113928N01 CAP CER CHIP 0.1UF 10%
C3826 2113743L41 CAP CHIP 10000 PF 10%
C3827 2113740F67 CAP CHIP CL1 +/-30 470
C3828 2113743L41 CAP CHIP 10000 PF 10%
C3829 2113740F67 CAP CHIP CL1 +/-30 470
C3830 2113743L17 CAP CHIP 1000 PF 10% X
C3831 2113743L17 CAP CHIP 1000 PF 10% X
C3832 2113740F67 CAP CHIP CL1 +/-30 470
C3833 2113743E20 CAP CHIP .10 UF 10%
C3834 2113743E12 CAP CHIP .047 UF 10% X
C3835 2113740L15 CAP CER CHIP 7.5 PF +-
C3836 2113740L15 CAP CER CHIP 7.5 PF +-
Reference
Designator
Motorola
Part Number
Description
C3837 2113740L13 CAP CER CHIP 6.2 PF +-
C3838 2113740L13 CAP CER CHIP 6.2 PF +-
C3839 2113740F33 CAP CHIP REEL CL1 +/-3
C3840 2113740F33 CAP CHIP REEL CL1 +/-3
C3841 2113740L26 CAP 22.0 PF 50V 2.0 %
C3842 2113740L26 CAP 22.0 PF 50V 2.0 %
C3843 2113740F33 CAP CHIP REEL CL1 +/-3
C3844 2113740F33 CAP CHIP REEL CL1 +/-3
C3845 2113740L13 CAP CER CHIP 6.2 PF +-
C3846 2113740L13 CAP CER CHIP 6.2 PF +-
C3847 2113740L13 CAP CER CHIP 6.2 PF +-
C3848 2113740L13 CAP CER CHIP 6.2 PF +-
C3849 2113740L13 CAP CER CHIP 6.2 PF +-
C3850 2113740L14 CAP CER CHIP 6.8 PF +-
C3854 2113740F19 CAP CHIP REEL CL1 +/-3
C3855 2104263L01 CAPACITOR 0.1UF FILM
C3856 2104263L01 CAPACITOR 0.1UF FILM
C3857 2104263L01 CAPACITOR 0.1UF FILM
C3858 2104263L01 CAPACITOR 0.1UF FILM
C3859 2104263L01 CAPACITOR 0.1UF FILM
C3860 2104263L01 CAPACITOR 0.1UF FILM
C3861 2104263L01 CAPACITOR 0.1UF FILM
C3862 2113740F67 CAP CHIP CL1 +/-30 470
C3863 2113740F33 CAP CHIP REEL CL1 +/-3
C3864 2113740F67 CAP CHIP CL1 +/-30 470
C3865 2113740F67 CAP CHIP CL1 +/-30 470
C3868 2113743E20 CAP CHIP .10 UF 10%
C3869 2113740F67 CAP CHIP CL1 +/-30 470
C3870 2113740F67 CAP CHIP CL1 +/-30 470
C3871 2113741F49 CAP CHIP CL2 X7R REEL
C3872 2113743E20 CAP CHIP .10 UF 10%
C3873 2113740F67 CAP CHIP CL1 +/-30 470
C3876 2113741F49 CAP CHIP CL2 X7R REEL
C3878 2113741F49 CAP CHIP CL2 X7R REEL
C3879 2113743T19 CAP 10UF 16V CER 3225
C3881 2104263L01 CAPACITOR 0.1UF FILM
C3882 2104263L01 CAPACITOR 0.1UF FILM
C3883 2104263L01 CAPACITOR 0.1UF FILM
C3910 2113743E20 CAP CHIP .10 UF 10%
C3911 2113741F49 CAP CHIP CL2 X7R REEL
C3912 2113741F49 CAP CHIP CL2 X7R REEL
Reference
Designator
Motorola
Part Number
Description
C3913 2113740F67 CAP CHIP CL1 +/-30 470
C3914 2113740F67 CAP CHIP CL1 +/-30 470
C3915 2113740F67 CAP CHIP CL1 +/-30 470
C3916 2113740F67 CAP CHIP CL1 +/-30 470
C3917 2113740F32 CAP CHIP REEL CL1 +/-3
C3918 2113740L18 CAP CER CHIP 10.0 PF +
C3919 2113740L15 CAP CER CHIP 7.5 PF +-
C3920 2113740F14 CAP CHIP REEL CL1 +/-3
C3921 2113740F14 CAP CHIP REEL CL1 +/-3
C3924 2113741F49 CAP CHIP CL2 X7R REEL
C3925 2113743A19 CAP CHIP .100 UF 10% X
C3926 2113743A19 CAP CHIP .100 UF 10% X
C3930 2113740F67 CAP CHIP CL1 +/-30 470
C3931 2113741F49 CAP CHIP CL2 X7R REEL
C3932 2113741F49 CAP CHIP CL2 X7R REEL
C3933 2113740F67 CAP CHIP CL1 +/-30 470
C3934 2113741F49 CAP CHIP CL2 X7R REEL
C3935 2113741F49 CAP CHIP CL2 X7R REEL
C3936 2113741F25 CAP CHIP CL2 X7R REEL
D0501 4805218N57 DIODE DUAL
D0950 4813833C02 DIODE DUAL 70V ’5B’ CO
D0951 4813833C02 DIODE DUAL 70V ’5B’ CO
D0952 4813833C02 DIODE DUAL 70V ’5B’ CO
D0954 4813833C02 DIODE DUAL 70V ’5B’ CO
D3000 4809877C13 DIODE VARACTOR
ISV305
D3001 4805656W28 DIODE VARACTOR
18PF@1V
D3251 4808115L23 DIODE,PIN,SMP1322,,,,1"
D3252 4808115L23 DIODE,PIN,SMP1322,,,,1"
D3253 4808115L23 DIODE,PIN,SMP1322,,,,1"
D3254 4808115L23 DIODE,PIN,SMP1322,,,,1"
D3255 4808115L17 PIN DIODE
D3256 4813825A19 DIODE SCHOTTKY BAR-
RIER
D3258 4802245J92 QUAD CROSSOVER RING
MI
D3400 4813833B24 DIODE SCHOTTKY DL
SERI
D3701 4802482J02 PIN DIODE SMD
D3702 4802482J02 PIN DIODE SMD
D3703 4880154K06 DIODE PIN SCHOTTKY
Reference
Designator
Motorola
Part Number
Description
D3704 4802482J02 PIN DIODE SMD
D3705 4802482J02 PIN DIODE SMD
D3730 4813825A05 DIODE 30V HOT CARRIER
D3731 4813825A05 DIODE 30V HOT CARRIER
D3750 4813833C02 DIODE DUAL 70V ’5B’ CO
D3751 4813833C02 DIODE DUAL 70V ’5B’ CO
D3752 4805649Q13 DIODE VCTR ISV 228
D3753 4805649Q13 DIODE VCTR ISV 228
D3754 4805649Q13 DIODE VCTR ISV 228
D3755 4813825A08 DIODE 70V HOT CARRIER
D3756 4813825A08 DIODE 70V HOT CARRIER
D3757 4802233J09 DIODE TRIPLE SOT25-RH
D3758 4802233J09 DIODE TRIPLE SOT25-RH
D3767 4813825A08 DIODE 70V HOT CARRIER
D3768 4813825A08 DIODE 70V HOT CARRIER
D3769 4805649Q13 DIODE VCTR ISV 228
D3770 4805649Q13 DIODE VCTR ISV 228
D3771 4805649Q13 DIODE VCTR ISV 228
D3772 4805649Q13 DIODE VCTR ISV 228
D3773 4805649Q13 DIODE VCTR ISV 228
E3000 2480640Z01 SURFACE MOUNT FER-
RITE
E3001 2480640Z01 SURFACE MOUNT FER-
RITE
E3002 2480640Z01 SURFACE MOUNT FER-
RITE
E3003 2480640Z01 SURFACE MOUNT FER-
RITE
E3004 2480640Z01 SURFACE MOUNT FER-
RITE
E3005 2480640Z01 SURFACE MOUNT FER-
RITE
E3006 2480640Z01 SURFACE MOUNT FER-
RITE
E3007 2480640Z01 SURFACE MOUNT FER-
RITE
E3008 2480640Z01 SURFACE MOUNT FER-
RITE
F0400 6583049X16 FUSE 5A FAST ACT
FL0900 9185130D01 FLTR SW CAP 3 POLE
BUT
J0401 0985722E01 CONN 50 POS FM SMT
RTA
Reference
Designator
Motorola
Part Number
Description
