7-60 Schematics, Component Location Diagrams, and Parts Lists: HUD4022A (VHF) Main Board
June 15, 2005 6815854H01-A
J0402 0985631E01 CONNECTOR FEMALE 32
PI
J0501 0985473E01 CONN SECURE 20 POS
FM
J0950 0905902V07 CONNECTOR DC
J3700 0905901V11 RF CONNECTOR,RF,,F,,,,"
L3000 2405769X05 COIL INDUCTOR
L3002 2462587N56 CHIP IND 180 NH 5%
L3003 2462587N76 CHIP IND 4700 NH 5%
L3004 2462587N76 CHIP IND 4700 NH 5%
L3005 2405769X05 COIL INDUCTOR
L3006 2413923A05 IND CHIP 120 NH 2%
L3007 2413926N24 IND CER CHIP 100.0 NH
L3008 2462587L50 CHIP IND 100000 NH 10%
L3251 2413923A32 IND CHIP 18 NH 2%
L3252 2413923A24 IND CHIP 47 NH 2%
L3253 2413923A04 IND CHIP 100 NH 2%
L3254 2413923A36 IND CHIP 10 NH 2%
L3255 2413923A20 IND CHIP 22 NH 2%
L3256 2413923A01 IND CHIP 56 NH 2%
L3257 2413923A35 IND CHIP 15 NH 2%
L3258 2413923A06 IND CHIP 150 NH 2%
L3259 2462587N69 CHIP IND 1200 NH 5%
L3260 2460591M77 COIL AIR WOUND INDUC
3
L3261 2462587N69 CHIP IND 1200 NH 5%
L3262 2462587Q40 IND CHIP 270 NH 10%
L3263 2460591M77 COIL AIR WOUND INDUC
3
L3264 2460591M77 COIL AIR WOUND INDUC
3
L3265 2413923A21 IND CHIP 27 NH 2%
L3266 2462587N69 CHIP IND 1200 NH 5%
L3268 2462587N69 CHIP IND 1200 NH 5%
L3269 2462587N69 CHIP IND 1200 NH 5%
L3270 2462587N69 CHIP IND 1200 NH 5%
L3271 2460591M77 COIL AIR WOUND INDUC
3
L3272 2460591P75 COIL AIR WOUND INDUC
7
L3273 2460591P75 COIL AIR WOUND INDUC
7
L3275 2462587Q40 IND CHIP 270 NH 10%
Reference
Designator
Motorola
Part Number
Description
L3276 2462587T30 IND CHIP 1000NH 5%
LOW
L3277 2462587T03 IND CHIP 10NH 10% LOW
L3400 2462587Q40 IND CHIP 270 NH 10%
L3401 2462587T59 IND CHIP 330NH 2% LOW
L3403 2462587T59 IND CHIP 330NH 2% LOW
L3404 2462587T59 IND CHIP 330NH 2% LOW
L3405 2462587T59 IND CHIP 330NH 2% LOW
L3406 2462587T30 IND CHIP 1000NH 5%
LOW
L3408 2462587T13 IND CHIP 68NH 5% LOW P
L3501 2462587T13 IND CHIP 68NH 5% LOW P
L3502 2460591A01 COIL AIR WOUND INDUC
4
L3503 2462587T13 IND CHIP 68NH 5% LOW P
L3520 2484562T05 COIL SURFACE MOUNT
AIR
L3530 7686135U02 FLTR,EMI"
L3531 2484562T04 COIL SURFACE MOUNT
AIR
L3549 7686135U02 FLTR,EMI"
L3550 7686135U02 FLTR,EMI"
L3551 2460592A01 COIL AW 2 TURN 17 NH
L3552 2460592A01 COIL AW 2 TURN 17 NH
L3700 2462587N69 CHIP IND 1200 NH 5%
L3701 2485873L02 ENCAPSULATED AIR
WOUND
L3702 2408384A05 47NH 5% COILCRAFT
1812
L3703 2462587N69 CHIP IND 1200 NH 5%
L3704 2462587N69 CHIP IND 1200 NH 5%
L3720 2484562T17 COIL SURFACE MNT AIR
W
L3721 2485873L02 ENCAPSULATED AIR
WOUND
L3722 2485873L02 ENCAPSULATED AIR
WOUND
L3723 2485873L02 ENCAPSULATED AIR
WOUND
L3724 2484562T16 COIL SURFACE MNT AIR
W
L3725 2485873L02 ENCAPSULATED AIR
WOUND
Reference
Designator
Motorola
Part Number
Description
L3726 2485873L02 ENCAPSULATED AIR
WOUND
L3727 2485873L02 ENCAPSULATED AIR
WOUND
L3730 2488428L09 IDCTR,CHIP,18NH,5%,1.9"
L3731 2488428L09 IDCTR,CHIP,18NH,5%,1.9"
L3732 2485873L02 ENCAPSULATED AIR
WOUND
L3737 2462587N69 CHIP IND 1200 NH 5%
L3750 2462587T30 IND CHIP 1000NH 5%
LOW
L3751 2462587Q44 IND CHIP 560 NH 10%
L3752 2462587Q44 IND CHIP 560 NH 10%
L3753 2462587Q20 IND CHIP 2,200 NH 20%"
L3754 2462587Q47 IND CHIP 1,000 NH 10%"
L3755 2462587Q20 IND CHIP 2,200 NH 20%"
L3756 2462587Q20 IND CHIP 2,200 NH 20%"
L3757 2462587Q20 IND CHIP 2,200 NH 20%"
L3758 2462587T30 IND CHIP 1000NH 5%
LOW
L3759 2462587T30 IND CHIP 1000NH 5%
LOW
L3760 2462587T30 IND CHIP 1000NH 5%
LOW
L3761 2462587T30 IND CHIP 1000NH 5%
LOW
L3762 2462587T30 IND CHIP 1000NH 5%
LOW
L3763 2462587T30 IND CHIP 1000NH 5%
LOW
L3764 2462587T30 IND CHIP 1000NH 5%
LOW
L3765 2462587T30 IND CHIP 1000NH 5%
LOW
L3766 2462587T30 IND CHIP 1000NH 5%
LOW
L3767 2462587T30 IND CHIP 1000NH 5%
LOW
L3768 2462587T30 IND CHIP 1000NH 5%
LOW
L3769 2462587T30 IND CHIP 1000NH 5%
LOW
L3770 2462587T30 IND CHIP 1000NH 5%
LOW
L3771 2462587T30 IND CHIP 1000NH 5%
LOW
Reference
Designator
Motorola
Part Number
Description
L3772 2462587T30 IND CHIP 1000NH 5%
LOW
L3773 2462587T30 IND CHIP 1000NH 5%
LOW
L3774 2409377M13 IDCTR,CHIP,56NH,5%,600
"
L3775 2462587Q40 IND CHIP 270 NH 10%
L3776 2462587T30 IND CHIP 1000NH 5%
LOW
L3778 2409377M13 IDCTR,CHIP,56NH,5%,600
"
L3779 2409377M19 IDCTR,CHIP,120NH,5%,30
"
L3781 2409377M10 IDCTR,CHIP,33NH,5%,600
"
L3782 2409377M08 IDCTR,CHIP,22NH,5%,700
"
L3783 2462587T30 IND CHIP 1000NH 5%
LOW
L3784 2409377M19 IDCTR,CHIP,120NH,5%,30
"
L3785 2409377M12 IDCTR,CHIP,47NH,5%,600
"
L3787 2409377M09 IDCTR,CHIP,27NH,5%,600
"
L400 2485821C07 IDCTR,CHIP"
M3520 2685838C01 HEATSINK PLD1.5
TRANSI
M3542 2685837C04 HEATSINK TRANSISTOR
CA
Q0200 4880048M01 TSTR NPN DIG 47K/47K
Q0402 4880048M01 TSTR NPN DIG 47K/47K
Q0403 4805723X03 TRANS DUAL NPN-PNP
UMD
Q0404 4880048M01 TSTR NPN DIG 47K/47K
Q0500 4880048M01 TSTR NPN DIG 47K/47K
Q0501 4880048M01 TSTR NPN DIG 47K/47K
Q0502 4880048M01 TSTR NPN DIG 47K/47K
Q0503 4813821A09 TSTR P-CH 60V 12A _295
Q0504 4880048M01 TSTR NPN DIG 47K/47K
Q0505 4880048M01 TSTR NPN DIG 47K/47K
Q0610 4805723X03 TRANS DUAL NPN-PNP
UMD
Q0611 4805723X03 TRANS DUAL NPN-PNP
UMD
Reference
Designator
Motorola
Part Number
Description
