Motorola Astro XTL 1500 - Page 300

Schematics, Component Location Diagrams, and Parts Lists: HUD4022A (VHF) Main Board 7-61
6815854H01-A June 15, 2005
Q0612 4805723X03 TRANS DUAL NPN-PNP
UMD
Q0613 4805723X03 TRANS DUAL NPN-PNP
UMD
Q0951 4880048M01 TSTR NPN DIG 47K/47K
Q0952 4885844C01 XSTR FET
Q0954 4809579E16 TSTR MOSFET N-CHAN
TN0
Q0955 4809579E16 TSTR MOSFET N-CHAN
TN0
Q0960 4805723X03 TRANS DUAL NPN-PNP
UMD
Q3000 4805218N63 RF TRANS SOT 323
BFQ67
Q3001 4805128M19 TSTR SOT23 MMBTA13
RH
Q3250 4880048M01 TSTR NPN DIG 47K/47K
Q3252 4804188K01 TSTR NPN RF NE85634
Q3253 4805921T11 XSTR DUAL PNP
Q3254 4805921T11 XSTR DUAL PNP
Q3255 4804188K01 TSTR NPN RF NE85634
Q3256 4813824A10 TSTR NPN 40V .2A GEN P
Q3257 4813824A10 TSTR NPN 40V .2A GEN P
Q3258 4813824A10 TSTR NPN 40V .2A GEN P
Q3400 4805921T11 XSTR DUAL PNP
Q3401 4804188K01 TSTR NPN RF NE85634
Q3530 4886212B01 LDMOS PWR TSTR
MRF1518
Q3550 4813828C45 TSTR VHF 50W 12.5 VOLT
Q3750 4813824A10 TSTR NPN 40V .2A GEN P
Q3751 4880141L06 TSTR NC MOS FET
SOT23
Q3752 4880141L06 TSTR NC MOS FET
SOT23
Q3753 4880141L06 TSTR NC MOS FET
SOT23
Q3754 4880141L06 TSTR NC MOS FET
SOT23
Q3755 4813824A10 TSTR NPN 40V .2A GEN P
Q3756 4813824A17 XSTR PNP40V .2A GENP
B
Q3757 4809527E41 TRANSISTOR UHF
PRF949
Q3758 4809527E41 TRANSISTOR UHF
PRF949
Reference
Designator
Motorola
Part Number
Description
Q3759 4809527E41 TRANSISTOR UHF
PRF949
Q3760 4809527E41 TRANSISTOR UHF
PRF949
Q3761 4809527E41 TRANSISTOR UHF
PRF949
Q3762 4804188K14 TSTR,RF
POWER,SLCN,NPN"
Q3763 4805921T04 XISTOR FMC1 RH
REELED
Q3764 4805921T04 XISTOR FMC1 RH
REELED
Q3765 4805921T04 XISTOR FMC1 RH
REELED
Q3766 4805921T04 XISTOR FMC1 RH
REELED
Q3767 4805921T11 XSTR DUAL PNP
Q3768 4880048M03 TRST NPN DIG 47K/47K
Q3769 4809527E41 TRANSISTOR UHF
PRF949
R0101 0662057M98 RES. CHIP 10K 5% 20X40
R0105 0662057M98 RES. CHIP 10K 5% 20X40
R0106 0662057M98 RES. CHIP 10K 5% 20X40
R0107 0662057M01 RES. CHIP 0 5% 20X40
R0109 0662057M98 RES. CHIP 10K 5% 20X40
R0111 0662057M86 RES. CHIP 3300 5% 20X4
R0114 0662057M01 RES. CHIP 0 5% 20X40
R0116 0662057B46 CHIP RES 10.0 MEG
OHMS
R0117 0662057B46 CHIP RES 10.0 MEG
OHMS
R0119 0662057N39 RES. CHIP 470K 5% 20X4
R0120 0662057M98 RES. CHIP 10K 5% 20X40
R0121 0662057M98 RES. CHIP 10K 5% 20X40
R0122 0662057M86 RES. CHIP 3300 5% 20X4
R0123 0662057M86 RES. CHIP 3300 5% 20X4
R0125 0662057M98 RES. CHIP 10K 5% 20X40
R0126 0662057M01 RES. CHIP 0 5% 20X40
R0200 0662057M74 RES. CHIP 1000 5% 20X4
R0201 0662057M01 RES. CHIP 0 5% 20X40
R0202 0662057M86 RES. CHIP 3300 5% 20X4
R0203 0662057M74 RES. CHIP 1000 5% 20X4
R0204 0662057M68 RES. CHIP 560 5% 20X40
R0205 0662057N15 RES. CHIP 47K 5% 20X40
Reference
Designator
Motorola
Part Number
Description
R0207 0662057M95 RES. CHIP 7500 5% 20X4
R0208 0662057N23 RES. CHIP 100K 5% 20X4
R0209 0662057M98 RES. CHIP 10K 5% 20X40
R0210 0662057N23 RES. CHIP 100K 5% 20X4
R0212 0662057N23 RES. CHIP 100K 5% 20X4
R0216 0662057N23 RES. CHIP 100K 5% 20X4
R0218 0662057M74 RES. CHIP 1000 5% 20X4
R0219 0662057M74 RES. CHIP 1000 5% 20X4
R0220 0662057N05 RES. CHIP 18K 5% 20X40
R0221 0662057M98 RES. CHIP 10K 5% 20X40
R0222 0662057M98 RES. CHIP 10K 5% 20X40
R0224 0662057M01 RES. CHIP 0 5% 20X40
R0225 0662057M98 RES. CHIP 10K 5% 20X40
R0226 0662057N12 RES. CHIP 36K 5% 20X40
R0227 0662057N19 RES. CHIP 68K 5% 20X40
R0228 0662057N11 RES. CHIP 33K 5% 20X40
R0229 0662057N19 RES. CHIP 68K 5% 20X40
R0230 0662057N11 RES. CHIP 33K 5% 20X40
R0231 0662057C13 CHIP RES 2.7 OHMS 5%
R0235 0662057M98 RES. CHIP 10K 5% 20X40
R0236 0662057M97 RES. CHIP 9100 5% 20X4
R0300 0662057M50 RES. CHIP 100 5% 20X40
R0301 0662057M50 RES. CHIP 100 5% 20X40
R0303 0662057M78 RES. CHIP 1500 5% 20X4
R0304 0662057M34 RES. CHIP 22 5% 20X40
R0305 0662057M34 RES. CHIP 22 5% 20X40
R0307 0662057M98 RES. CHIP 10K 5% 20X40
R0403 0662057M98 RES. CHIP 10K 5% 20X40
R0404 0662057M74 RES. CHIP 1000 5% 20X4
R0405 0662057M74 RES. CHIP 1000 5% 20X4
R0406 0662057M68 RES. CHIP 560 5% 20X40
R0407 0662057M50 RES. CHIP 100 5% 20X40
R0408 0662057M50 RES. CHIP 100 5% 20X40
R0409 0662057M98 RES. CHIP 10K 5% 20X40
R0410 0662057M50 RES. CHIP 100 5% 20X40
R0411 0662057M98 RES. CHIP 10K 5% 20X40
R0412 0662057M50 RES. CHIP 100 5% 20X40
R0415 0662057M50 RES. CHIP 100 5% 20X40
R0416 0662057M50 RES. CHIP 100 5% 20X40
R0417 0662057M50 RES. CHIP 100 5% 20X40
R0418 0662057M50 RES. CHIP 100 5% 20X40
Reference
Designator
Motorola
Part Number
Description
R0419 0662057M90 RES. CHIP 4700 5% 20X4
R0420 0662057M98 RES. CHIP 10K 5% 20X40
R0421 0662057M01 RES. CHIP 0 5% 20X40
R0422 0662057V15 RES CHIP 33K 1% 1/16W
R0425 0662057M98 RES. CHIP 10K 5% 20X40
R0430 0662057M01 RES. CHIP 0 5% 20X40
R0431 0662057M98 RES. CHIP 10K 5% 20X40
R0432 0662057M50 RES. CHIP 100 5% 20X40
R0435 0662057M74 RES. CHIP 1000 5% 20X4
R0500 0662057N23 RES. CHIP 100K 5% 20X4
R0502 0662057N37 RES. CHIP 390K 5% 20X4
R0503 0662057N23 RES. CHIP 100K 5% 20X4
R0504 0662057N23 RES. CHIP 100K 5% 20X4
R0505 0662057M98 RES. CHIP 10K 5% 20X40
R0506 0662057M98 RES. CHIP 10K 5% 20X40
R0507 0662057M98 RES. CHIP 10K 5% 20X40
R0508 0662057M98 RES. CHIP 10K 5% 20X40
R0509 0662057M81 RES. CHIP 2000 5% 20X4
R0510 0662057V18 RES CHIP 43K 1% 1/16W
R0511 0662057V15 RES CHIP 33K 1% 1/16W
R0512 0662057V02 RES CHIP 10K 1% 1/16W
R0513 0662057V17 RES CHIP 39K 1% 1/16W
R0514 0662057M01 RES. CHIP 0 5% 20X40
R0515 0662057M74 RES. CHIP 1000 5% 20X4
R0516 0662057N23 RES. CHIP 100K 5% 20X4
R0517 0662057M90 RES. CHIP 4700 5% 20X4
R0518 0662057M98 RES. CHIP 10K 5% 20X40
R0519 0662057C27 CHIP RES 10 OHMS 5%
R0520 0662057N15 RES. CHIP 47K 5% 20X40
R0521 0662057V17 RES CHIP 39K 1% 1/16W
R0522 0662057V10 RES CHIP 20K 1% 1/16W
R0523 0662057N23 RES. CHIP 100K 5% 20X4
R0525 0662057M50 RES. CHIP 100 5% 20X40
R0526 0662057M50 RES. CHIP 100 5% 20X40
R0528 0662057M95 RES. CHIP 7500 5% 20X4
R0529 0662057M76 RES. CHIP 1200 5% 20X4
R0531 0662057N23 RES. CHIP 100K 5% 20X4
R0620 0662057M50 RES. CHIP 100 5% 20X40
R0621 0662057M50 RES. CHIP 100 5% 20X40
R0622 0662057M50 RES. CHIP 100 5% 20X40
R0623 0662057M50 RES. CHIP 100 5% 20X40
Reference
Designator
Motorola
Part Number
Description
