Motorola Astro XTL 1500 - Page 301

7-62 Schematics, Component Location Diagrams, and Parts Lists: HUD4022A (VHF) Main Board
June 15, 2005 6815854H01-A
R0624 0662057M50 RES. CHIP 100 5% 20X40
R0625 0662057M98 RES. CHIP 10K 5% 20X40
R0626 0662057N23 RES. CHIP 100K 5% 20X4
R0627 0662057N23 RES. CHIP 100K 5% 20X4
R0628 0662057N23 RES. CHIP 100K 5% 20X4
R0629 0662057M98 RES. CHIP 10K 5% 20X40
R0630 0662057N23 RES. CHIP 100K 5% 20X4
R0631 0662057M01 RES. CHIP 0 5% 20X40
R0634 0662057N23 RES. CHIP 100K 5% 20X4
R0635 0662057N23 RES. CHIP 100K 5% 20X4
R0636 0662057M98 RES. CHIP 10K 5% 20X40
R0638 0662057M98 RES. CHIP 10K 5% 20X40
R0639 0662057M98 RES. CHIP 10K 5% 20X40
R0901 0662057M96 RES. CHIP 8200 5% 20X4
R0902 0662057N23 RES. CHIP 100K 5% 20X4
R0903 0662057N23 RES. CHIP 100K 5% 20X4
R0904 0662057N23 RES. CHIP 100K 5% 20X4
R0905 0662057N23 RES. CHIP 100K 5% 20X4
R0906 0662057M50 RES. CHIP 100 5% 20X40
R0907 0662057M50 RES. CHIP 100 5% 20X40
R0908 0662057C13 CHIP RES 2.7 OHMS 5%
R0910 0662057V25 RES CHIP 82K 1% 1/16W
R0911 0662057V04 RES CHIP 12K 1% 1/16W
R0912 0662057V04 RES CHIP 12K 1% 1/16W
R0913 0662057V30 RES CHIP 130K 1% 1/16W
R0914 0662057V04 RES CHIP 12K 1% 1/16W
R0915 0662057M74 RES. CHIP 1000 5% 20X4
R0916 0662057M66 RES. CHIP 470 5% 20X40
R0917 0662057M21 RES. CHIP 6.2 5% 20X40
R0923 0662057M50 RES. CHIP 100 5% 20X40
R0924 0662057M50 RES. CHIP 100 5% 20X40
R0930 0662057N06 RES. CHIP 20K 5% 20X40
R0931 0662057M98 RES. CHIP 10K 5% 20X40
R0932 0662057M86 RES. CHIP 3300 5% 20X4
R0933 0662057M90 RES. CHIP 4700 5% 20X4
R0934 0662057M74 RES. CHIP 1000 5% 20X4
R0936 0662057M01 RES. CHIP 0 5% 20X40
R0938 0662057M01 RES. CHIP 0 5% 20X40
R0940 0662057M01 RES. CHIP 0 5% 20X40
R0942 0662057N05 RES. CHIP 18K 5% 20X40
R0943 0662057N06 RES. CHIP 20K 5% 20X40
Reference
Designator
Motorola
Part Number
Description
R0944 0662057M98 RES. CHIP 10K 5% 20X40
R0945 0662057N37 RES. CHIP 390K 5% 20X4
R0947 0662057M87 RES. CHIP 3600 5% 20X4
R0948 0662057M74 RES. CHIP 1000 5% 20X4
R0950 0662057M01 RES. CHIP 0 5% 20X40
R0951 0662057U98 RES CHIP 7.5K 1% 1/16W
R0952 0662057U78 RES CHIP 1.2K 1% 1/16W
R0953 0662057M01 RES. CHIP 0 5% 20X40
R0954 0662057U98 RES CHIP 7.5K 1% 1/16W
R0955 0662057N23 RES. CHIP 100K 5% 20X4
R0960 0662057N06 RES. CHIP 20K 5% 20X40
R0961 0662057N23 RES. CHIP 100K 5% 20X4
R0962 0662057N23 RES. CHIP 100K 5% 20X4
R0963 0662057N05 RES. CHIP 18K 5% 20X40
R0964 0662057M86 RES. CHIP 3300 5% 20X4
R0965 0662057M01 RES. CHIP 0 5% 20X40
R0966 0662057M01 RES. CHIP 0 5% 20X40
R0967 0662057V27 RES CHIP 100K 1% 1/16W
R0968 0662057V02 RES CHIP 10K 1% 1/16W
R0971 0662057N03 RES. CHIP 15K 5% 20X40
R0972 0662057U93 RES CHIP 4.7K 1% 1/16W
R0973 0662057N05 RES. CHIP 18K 5% 20X40
R0974 0662057V02 RES CHIP 10K 1% 1/16W
R0975 0662057V02 RES CHIP 10K 1% 1/16W
R0976 0662057M78 RES. CHIP 1500 5% 20X4
R0977 0662057M54 RES. CHIP 150 5% 20X40
R0978 0662057M98 RES. CHIP 10K 5% 20X40
R0979 0662057M01 RES. CHIP 0 5% 20X40
R0981 0662057M84 RES. CHIP 2700 5% 20X4
R0982 0662057N23 RES. CHIP 100K 5% 20X4
R0983 0662057M74 RES. CHIP 1000 5% 20X4
R0984 0662057M01 RES. CHIP 0 5% 20X40
R0985 0662057M01 RES. CHIP 0 5% 20X40
R0987 0662057M01 RES. CHIP 0 5% 20X40
R0988 0662057M98 RES. CHIP 10K 5% 20X40
R0989 0662057N17 RES. CHIP 56K 5% 20X40
R0990 0662057M91 RES. CHIP 5100 5% 20X4
R0991 0662057M98 RES. CHIP 10K 5% 20X40
R0992 0662057N23 RES. CHIP 100K 5% 20X4
R0993 0662057U78 RES CHIP 1.2K 1% 1/16W
R0994 0662057M91 RES. CHIP 5100 5% 20X4
Reference
Designator
Motorola
Part Number
Description
R0995 0662057U78 RES CHIP 1.2K 1% 1/16W
R0996 0662057M98 RES. CHIP 10K 5% 20X40
R0997 0662057U78 RES CHIP 1.2K 1% 1/16W
R0998 0662057V02 RES CHIP 10K 1% 1/16W
R0999 0662057V02 RES CHIP 10K 1% 1/16W
R3000 0662057M43 RES. CHIP 51 5% 20X40
R3001 0662057N47 RES. CHIP 1.0 MEG 5% 2
R3002 0662057N23 RES. CHIP 100K 5% 20X4
R3003 0662057N03 RES. CHIP 15K 5% 20X40
R3004 0662057N05 RES. CHIP 18K 5% 20X40
R3005 0662057M98 RES. CHIP 10K 5% 20X40
R3006 0662057M98 RES. CHIP 10K 5% 20X40
R3007 0662057M98 RES. CHIP 10K 5% 20X40
R3008 0662057M98 RES. CHIP 10K 5% 20X40
R3009 0662057M74 RES. CHIP 1000 5% 20X4
R3010 0662057M64 RES. CHIP 390 5% 20X40
R3011 0662057M64 RES. CHIP 390 5% 20X40
R3012 0662057M01 RES. CHIP 0 5% 20X40
R3014 0662057M01 RES. CHIP 0 5% 20X40
R3015 0662057M01 RES. CHIP 0 5% 20X40
R3016 0662057M01 RES. CHIP 0 5% 20X40
R3017 0662057M01 RES. CHIP 0 5% 20X40
R3018 0662057M01 RES. CHIP 0 5% 20X40
R3019 0662057M01 RES. CHIP 0 5% 20X40
R3020 0662057M43 RES. CHIP 51 5% 20X40
R3021 0662057M66 RES. CHIP 470 5% 20X40
R3022 0662057M01 RES. CHIP 0 5% 20X40
R3251 0662057A01 CHIP RES 10 OHMS 5%
R3252 0662057R04 RES CHIP 12.1 .1W 1%
R3253 0662057M98 RES. CHIP 10K 5% 20X40
R3254 0662057A57 CHIP RES 2200 OHMS 5%
R3255 0662057A20 CHIP RES 62 OHMS 5%
R3256 0662057A49 CHIP RES 1000 OHMS 5%
R3257 0662057A44 CHIP RES 620 OHMS 5%
R3258 0662057A20 CHIP RES 62 OHMS 5%
R3259 0662057M90 RES. CHIP 4700 5% 20X4
R3260 0662057A18 CHIP RES 51 OHMS 5%
R3261 0662057M90 RES. CHIP 4700 5% 20X4
R3262 0662057M86 RES. CHIP 3300 5% 20X4
R3263 0662057M78 RES. CHIP 1500 5% 20X4
R3264 0662057M74 RES. CHIP 1000 5% 20X4
Reference
Designator
Motorola
Part Number
Description
R3265 0662057M98 RES. CHIP 10K 5% 20X40
R3266 0662057M98 RES. CHIP 10K 5% 20X40
R3268 0662057A20 CHIP RES 62 OHMS 5%
R3269 0662057N17 RES. CHIP 56K 5% 20X40
R3270 0662057A18 CHIP RES 51 OHMS 5%
R3271 0662057A22 CHIP RES 75 OHMS 5%
R3272 0662057A13 CHIP RES 33 OHMS 5%
R3273 0662057M88 RES. CHIP 3900 5% 20X4
R3274 0662057M64 RES. CHIP 390 5% 20X40
R3275 0662057M64 RES. CHIP 390 5% 20X40
R3277 0662057M86 RES. CHIP 3300 5% 20X4
R3278 0662057N17 RES. CHIP 56K 5% 20X40
R3279 0662057M95 RES. CHIP 7500 5% 20X4
R3280 0662057M86 RES. CHIP 3300 5% 20X4
R3281 0662057M87 RES. CHIP 3600 5% 20X4
R3288 0662057A20 CHIP RES 62 OHMS 5%
R3400 0662057A44 CHIP RES 620 OHMS 5%
R3401 0662057M90 RES. CHIP 4700 5% 20X4
R3402 0662057M86 RES. CHIP 3300 5% 20X4
R3405 0662057M78 RES. CHIP 1500 5% 20X4
R3407 0662057A01 CHIP RES 10 OHMS 5%
R3409 0662057A22 CHIP RES 75 OHMS 5%
R3413 0662057A25 CHIP RES 100 OHMS 5%
R3501 0662057M50 RES. CHIP 100 5% 20X40
R3502 0662057M92 RES. CHIP 5600 5% 20X4
R3507 0662057C13 CHIP RES 2.7 OHMS 5%
R3520 0662057M44 RES. CHIP 56 5% 20X40
R3521 0662057M44 RES. CHIP 56 5% 20X40
R3522 0662057M44 RES. CHIP 56 5% 20X40
R3523 0662057M44 RES. CHIP 56 5% 20X40
R3524 0662057C75 CHIP RES 1000 OHMS 5%
R3530 0611077A01 RES CHIP JUMPER
R3531 0680195M01 RES CHIP 10 OHMS 5% .5
R3532 0655087A24 3.9 OHM 5% 1/16W
R3533 0655087A24 3.9 OHM 5% 1/16W
R3534 0655087A24 3.9 OHM 5% 1/16W
R3535 0655087A24 3.9 OHM 5% 1/16W
R3536 0655087A24 3.9 OHM 5% 1/16W
R3537 0655087A24 3.9 OHM 5% 1/16W
R3538 0655087A24 3.9 OHM 5% 1/16W
R3540 0662057C75 CHIP RES 1000 OHMS 5%
Reference
Designator
Motorola
Part Number
Description
