Schematics, Component Location Diagrams, and Parts Lists: HUD4022A (VHF) Main Board 7-63
6815854H01-A June 15, 2005
R3550 0685934D01 RES FIXED CHIP (CUR-
REN
R3551 0680195M01 RES CHIP 10 OHMS 5% .5
R3560 0662057V27 RES CHIP 100K 1% 1/16W
R3561 0662057M61 RES. CHIP 300 5% 20X40
R3700 0680194M13 RES 33 OHMS 5% 1W
R3701 0662057M32 RES. CHIP 18 5% 20X40
R3702 0662057M74 RES. CHIP 1000 5% 20X4
R3703 0662057M32 RES. CHIP 18 5% 20X40
R3704 0662057M32 RES. CHIP 18 5% 20X40
R3730 0680149M02 THERMISTOR CHIP 100K
O
R3731 0662057N10 RES. CHIP 30K 5% 20X40
R3732 0662057M78 RES. CHIP 1500 5% 20X4
R3733 0662057M59 RES. CHIP 240 5% 20X40
R3734 0662057M59 RES. CHIP 240 5% 20X40
R3735 0662057M59 RES. CHIP 240 5% 20X40
R3736 0662057M59 RES. CHIP 240 5% 20X40
R3737 0662057M78 RES. CHIP 1500 5% 20X4
R3738 0662057N10 RES. CHIP 30K 5% 20X40
R3739 0680149M02 THERMISTOR CHIP 100K
O
R3750 0662057M74 RES. CHIP 1000 5% 20X4
R3751 0662057M34 RES. CHIP 22 5% 20X40
R3752 0662057M50 RES. CHIP 100 5% 20X40
R3753 0662057N23 RES. CHIP 100K 5% 20X4
R3754 0662057N23 RES. CHIP 100K 5% 20X4
R3755 0662057N23 RES. CHIP 100K 5% 20X4
R3756 0662057N03 RES. CHIP 15K 5% 20X40
R3757 0662057M81 RES. CHIP 2000 5% 20X4
R3758 0662057N17 RES. CHIP 56K 5% 20X40
R3759 0662057N15 RES. CHIP 47K 5% 20X40
R3761 0662057M98 RES. CHIP 10K 5% 20X40
R3762 0662057M92 RES. CHIP 5600 5% 20X4
R3763 0662057M74 RES. CHIP 1000 5% 20X4
R3793 0662057M92 RES. CHIP 5600 5% 20X4
R3794 0662057M21 RES. CHIP 6.2 5% 20X40
R3795 0662057M98 RES. CHIP 10K 5% 20X40
R3797 0662057M90 RES. CHIP 4700 5% 20X4
R3798 0662057M74 RES. CHIP 1000 5% 20X4
R3799 0662057M90 RES. CHIP 4700 5% 20X4
R3800 0662057A23 CHIP RES 82 OHMS 5%
Reference
Designator
Motorola
Part Number
Description
R3801 0662057A23 CHIP RES 82 OHMS 5%
R3802 0662057M72 RES. CHIP 820 5% 20X40
R3803 0662057M61 RES. CHIP 300 5% 20X40
R3804 0662057M61 RES. CHIP 300 5% 20X40
R3807 0662057A44 CHIP RES 620 OHMS 5%
R3808 0662057A44 CHIP RES 620 OHMS 5%
R3809 0662057M32 RES. CHIP 18 5% 20X40
R3811 0662057A21 CHIP RES 68 OHMS 5%
R3812 0662057A21 CHIP RES 68 OHMS 5%
R3813 0662057A23 CHIP RES 82 OHMS 5%
R3814 0662057A23 CHIP RES 82 OHMS 5%
R3815 0662057A23 CHIP RES 82 OHMS 5%
R3816 0662057A23 CHIP RES 82 OHMS 5%
R3817 0662057M34 RES. CHIP 22 5% 20X40
R3818 0662057M56 RES. CHIP 180 5% 20X40
R3819 0662057M56 RES. CHIP 180 5% 20X40
R3820 0662057M34 RES. CHIP 22 5% 20X40
R3821 0662057M72 RES. CHIP 820 5% 20X40
R3823 0662057M37 RES. CHIP 30 5% 20X40
R3824 0662057M56 RES. CHIP 180 5% 20X40
R3825 0662057M32 RES. CHIP 18 5% 20X40
R3826 0662057M61 RES. CHIP 300 5% 20X40
R3827 0662057M61 RES. CHIP 300 5% 20X40
R3828 0662057M50 RES. CHIP 100 5% 20X40
R3829 0662057M46 RES. CHIP 68 5% 20X40
R3831 0662057M21 RES. CHIP 6.2 5% 20X40
R3832 0662057M74 RES. CHIP 1000 5% 20X4
R3833 0662057M32 RES. CHIP 18 5% 20X40
R3834 0662057M32 RES. CHIP 18 5% 20X40
R3835 0662057M01 RES. CHIP 0 5% 20X40
R3836 0662057M43 RES. CHIP 51 5% 20X40
R3838 0662057M81 RES. CHIP 2000 5% 20X4
R3839 0662057M61 RES. CHIP 300 5% 20X40
R3840 0662057M61 RES. CHIP 300 5% 20X40
R3841 0662057M61 RES. CHIP 300 5% 20X40
R3842 0662057M61 RES. CHIP 300 5% 20X40
R3845 0662057M86 RES. CHIP 3300 5% 20X4
R3846 0662057M90 RES. CHIP 4700 5% 20X4
R3851 0662057A11 CHIP RES 27 OHMS 5%
R3852 0662057A11 CHIP RES 27 OHMS 5%
R3854 0662057M50 RES. CHIP 100 5% 20X40
Reference
Designator
Motorola
Part Number
Description
R3855 0662057M50 RES. CHIP 100 5% 20X40
R3856 0662057M61 RES. CHIP 300 5% 20X40
R3857 0662057M61 RES. CHIP 300 5% 20X40
R3858 0662057M56 RES. CHIP 180 5% 20X40
R3859 0662057M56 RES. CHIP 180 5% 20X40
R3860 0662057M72 RES. CHIP 820 5% 20X40
R3861 0662057M72 RES. CHIP 820 5% 20X40
R3862 0662057M21 RES. CHIP 6.2 5% 20X40
R3863 0662057M37 RES. CHIP 30 5% 20X40
R3864 0662057M32 RES. CHIP 18 5% 20X40
R3865 0662057M46 RES. CHIP 68 5% 20X40
R3868 0662057M92 RES. CHIP 5600 5% 20X4
R3869 0662057M90 RES. CHIP 4700 5% 20X4
R3870 0662057M62 RES. CHIP 330 5% 20X40
R3871 0662057A33 CHIP RES 220 OHMS 5%
R3872 0662057A25 CHIP RES 100 OHMS 5%
R3873 0662057A09 CHIP RES 22 OHMS 5%
R3880 0662057A49 CHIP RES 1000 OHMS 5%
R3881 0662057A49 CHIP RES 1000 OHMS 5%
R3882 0662057A44 CHIP RES 620 OHMS 5%
R3884 0662057A44 CHIP RES 620 OHMS 5%
SH3750 2602641Y02 SHIELD,ARIANE VCO"
SH3751 2602660J02 SHLD 18.13 X 11.14
SH3752 2602660J02 SHLD 18.13 X 11.14
SH3753 2602660J02 SHLD 18.13 X 11.14
SH3754 2602641Y02 "SHIELD,ARIANE VCO"
SH3759 2602660J02 SHLD 18.13 X 11.14
SH3760 2689589U01 VCO SHIELD
SH3762 2605782V04 SHLD
SH3763 2605782V04 SHLD
T3301 2580541Z02 BALUN TRANSFORMER
(NEW
T3302 2580541Z02 BALUN TRANSFORMER
(NEW
U0001 5185633C34 MODULE RAM/MEMORY
U0102 5185623B01 HIGH SPEED CMOS
INVERT
U0103 5113837A15 IC 3.3V QUAD BUFFER
U0104 5113837A15 IC 3.3V QUAD BUFFER
U0105 5109522E17 IC SNGL NAND TC7S00FU
U0200 5105109Z38 3 VOLT LINEAR PCM
CODE
Reference
Designator
Motorola
Part Number
Description
U0201 5113819A14 IC QD OP AMP _33204_
U0202 5185353D35 IC DUAL EEPOT 256 TAP
U0203 5162852A79 IC MOS TTL SPDT ANA-
LOG
U0204 5185794L01 AUDIO AMP TAPE AND
REE
U0206 5185143E67 INTEGRATED CIRCUITS
U0208 5162852A79 IC MOS TTL SPDT ANA-
LOG
U0209 5162852A79 IC MOS TTL SPDT ANA-
LOG
U0210 5162852A79 IC MOS TTL SPDT ANA-
LOG
U0300 5113837A15 IC 3.3V QUAD BUFFER
U0303 5113837A15 IC 3.3V QUAD BUFFER
U0304 5187970L15 IC USB TRANS FULL-
SPEE
U0305 5185353D94 IC RS232 TRANSCEIVER
U0307 5113805B65 IC 2 INPUT NAND
U0308 5109522E74 IC 2INPUT AND GATE
U0400 4880048M01 TSTR NPN DIG 47K/47K
U0401 5162852A79 IC MOS TTL SPDT ANA-
LOG
U0402 5109522E53 IC,BFR,1BITS,NC7SZ125P
"
U0500 5183308X01 IC, LM2941, TO DRPOUT"
U0501 5185353D55 IC VOLTAGE REGULA-
TOR 1
U0502 5185353D55 IC VOLTAGE REGULA-
TOR 1
U0503 5113816A07 REG 5V POS 500MA
MC78M
U0504 5185353D46 IF 4.3V VOLTAGE DETECT
U0505 5113816A07 REG 5V POS 500MA
MC78M
U0506 5185143E57 CMOS TIMER-LMC555CM
U0507 5185353D55 IC VOLTAGE REGULA-
TOR 1
U0508 5109522E53 IC,BFR,1BITS,NC7SZ125P
"
U0601 5109522E17 IC SNGL NAND TC7S00FU
U0602 5113837A15 IC 3.3V QUAD BUFFER
U0603 5113837A15 IC 3.3V QUAD BUFFER
U0604 5113818A14 IC DL OP AMP RAIL TO R
Reference
Designator
Motorola
Part Number
Description
