Motorola Astro XTL 1500 - Page 303

7-64 Schematics, Component Location Diagrams, and Parts Lists: HUD4022A (VHF) Main Board
June 15, 2005 6815854H01-A
U0605 5109522E17 IC SNGL NAND TC7S00FU
U0606 5105109Z31 IC QUAD 2:1 MUX/DEMUX
U0607 5109522E74 IC 2INPUT AND GATE
U0608 5109522E74 IC 2INPUT AND GATE
U0609 5109522E17 IC SNGL NAND TC7S00FU
U0610 5109522E17 IC SNGL NAND TC7S00FU
U0900 5185368C83 IC 12 BIT DAC
U0901 5185143E43 IC 23 MACROCELL CPLD
U0902 5113805B39 IC MUX/DEMUX, TRIP 2-
C"
U0903 5185143E68 INTEGRATED CIRCUITS
U0950 5105625U25 IC 9.3V REG 2941
U0951 5105625U25 IC 9.3V REG 2941
U0952 5185353D35 IC DUAL EEPOT 256 TAP
U0953 5185143E16 IC ANALOG TO DIGITAL C
U0954 5109522E17 IC SNGL NAND TC7S00FU
U0955 5113819A14 IC QD OP AMP _33204_
U0956 5185956E24 IC,OP AMP,2PER
PKG,RAI"
U0957 5113819A14 IC QD OP AMP _33204_
U0958 5109522E17 IC SNGL NAND TC7S00FU
U0959 5185143E05 IC DAC OCTAL 8 BIT
U0960 5113819A14 IC QD OP AMP _33204_
U0962 5185353D14 IC SOT23-5 HI PRECISIO
U0963 5109522E53 IC,BFR,1BITS,NC7SZ125P
"
U0965 5185143E68 INTEGRATED CIRCUITS
U3000 5185963A85 IC-ABACUS III-LP
U3001 5185353D14 IC SOT23-5 HI PRECISIO
U3250 5185130C83 IC 15DB DIGITAL ATTEUA
U3550 5185130C65 IC VHF/UHF/800 MHZ LDM
U3560 5185963A15 IC TEMPERTURE SEN-
SOR 1
U3561 5185353D92 IC CURRENT SHUNT
MONIT
U3750 5185353D14 IC SOT23-5 HI PRECISIO
U3751 5185963A27 IC TESTED AT25016 48 P
U3752 5105492X03 IC SNG HI SPD L-MOS NO
VR0400 4805656W09 DIODE QUAD 20 VOLT
ZEN
VR0402 4805656W09 DIODE QUAD 20 VOLT
ZEN
Reference
Designator
Motorola
Part Number
Description
VR0404 4805656W10 DIODE DUAL 15 VOLT
ZEN
VR0405 4805656W10 DIODE DUAL 15 VOLT
ZEN
VR0406 4805656W10 DIODE DUAL 15 VOLT
ZEN
VR0407 4805656W10 DIODE DUAL 15 VOLT
ZEN
VR0408 4813832C75 TRANS SUP QUAD 6.8 V
VR0410 4813832C75 TRANS SUP QUAD 6.8 V
VR0411 4805656W39 QUAD ESD SUPPRES-
SOR AR
VR0412 4805656W09 DIODE QUAD 20 VOLT
ZEN
VR0414 4813832C75 TRANS SUP QUAD 6.8 V
VR0417 4813832C75 TRANS SUP QUAD 6.8 V
VR0418 4813832C75 TRANS SUP QUAD 6.8 V
VR0420 4813830A24 DIODE 11V 5% 225MW
MMB
VR0421 4813830A24 DIODE 11V 5% 225MW
MMB
VR0422 4805656W10 DIODE DUAL 15 VOLT
ZEN
VR0423 4805656W10 DIODE DUAL 15 VOLT
ZEN
VR0424 4805656W10 DIODE DUAL 15 VOLT
ZEN
VR0425 4805656W10 DIODE DUAL 15 VOLT
ZEN
VR0500 4813830A14 DIODE 5.1V 5% 225MW
MM
VR0501 4813830A24 DIODE 11V 5% 225MW
MMB
VR0950 4813832C77 TRANS SUP. 24V HIGH
PW
Y0100 4809995L05 XTAL QUARTZ 32.768KHZ
Y3400 4885230C01 109.65MHZ FILTER 3RD O
Y3401 4885230C01 109.65MHZ FILTER 3RD O
Y3750 5185143E07 IC 16.8 MHZ REF OSC .8
Y3751 2484562T11 COIL SURF MNT AIR
WOUN
Y3752 2484562T11 COIL SURF MNT AIR
WOUN
Y3753 2413923A24 IND CHIP 47 NH 2%
Y3754 2413923A01 IND CHIP 56 NH 2%
Reference
Designator
Motorola
Part Number
Description
