7-98 Schematics, Component Location Diagrams, and Parts Lists: HUE4039A (UHF Range 1) Main Board
June 15, 2005 6815854H01-A
C5351 2113743L50 CAP CHIP 33000 PF 10%
C5352 2113743L01 CAP CHIP 220 PF 10% X7R
C5353 2113743L01 CAP CHIP 220 PF 10% X7R
C5354 2113743N42 CAP CHIP 47.0 PF 5% COG
C5355 2113743N26 CAP CHIP 10.0 PF 5% COG
C5356 2113743L50 CAP CHIP 33000 PF 10%
C5357 2113743L01 CAP CHIP 220 PF 10% X7R
C5358 2113743N27 CAP CHIP 11.0 PF 5% COG
C5360 2113743L50 CAP CHIP 33000 PF 10%
C5361 2113743L01 CAP CHIP 220 PF 10% X7R
C5362 2113743L01 CAP CHIP 220 PF 10% X7R
C5363 2113743L01 CAP CHIP 220 PF 10% X7R
C5364 2113743L17 CAP CHIP 1000 PF 10% X7R
C5365 2113743L01 CAP CHIP 220 PF 10% X7R
C5366 2113743L17 CAP CHIP 1000 PF 10% X7R
C5367 2113743L01 CAP CHIP 220 PF 10% X7R
C5368 2113743L17 CAP CHIP 1000 PF 10% X7R
C5374 2113743N11 CAP CHIP 2.4 PF +-.25PF
COG
C5375 2113743N16 CAP CHIP 3.9 PF +-.25PF
COG
C5377 2113743N30 CAP CHIP 15.0 PF 5% COG
C5379 2113743N25 CAP CHIP 9.1 PF + -.5PF
COG
C5380 2113743N22 CAP CHIP 6.8 PF + -.5PF
COG
C5382 2113743L41 CAP CHIP 10000 PF 10% X7R
C5383 2113743L41 CAP CHIP 10000 PF 10% X7R
C5385 2113743L41 CAP CHIP 10000 PF 10% X7R
C5386 2113743N38 CAP CHIP 33.0 PF 5% COG
C5388 2113743L41 CAP CHIP 10000 PF 10% X7R
C5389 2113743N28 CAP CHIP 12.0 PF 5% COG
C5390 2113743N22 CAP CHIP 6.8 PF + -.5PF
COG
C5391 2113743N38 CAP CHIP 33.0 PF 5% COG
C5400 2113743L01 CAP CHIP 220 PF 10% X7R
C5401 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C5402 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C5403 2113743N29 CAP 13PF 20X40
C5404 2113743N30 CAP CHIP 15.0 PF 5% COG
Reference
Designator
Motorola
Part Number
Description
C5405 2113743N12 CAP CHIP 2.7 PF +-.25PF
COG
C5406 2113743N31 CAP 16PF 20X40
C5407 2113743N30 CAP CHIP 15.0 PF 5% COG
C5408 2113743N13 CAP CHIP 3.0 PF +-.25PF
COG
C5409 2113743N69 CAP CHIP 1.8PF 16V +/-.25PF
C5410 2113743N69 CAP CHIP 1.8PF 16V +/-.25PF
C5412 2113743N12 CAP CHIP 2.7 PF +-.25PF
COG
C5413 2113743N69 CAP CHIP 1.8PF 16V +/-.25PF
C5414 2113743N24 CAP CHIP 8.2 PF + -.5PF
COG
C5415 2113743N12 CAP CHIP 2.7 PF +-.25PF
COG
C5418 2113743N69 CAP CHIP 1.8PF 16V +/-.25PF
C5419 2113743L01 CAP CHIP 220 PF 10% X7R
C5420 2113743L41 CAP CHIP 10000 PF 10% X7R
C5423 2113743L41 CAP CHIP 10000 PF 10% X7R
C5424 2113743L41 CAP CHIP 10000 PF 10% X7R
C5425 2113743L01 CAP CHIP 220 PF 10% X7R
C5426 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C5427 2113743M24 CAP CHIP 100000 PF +80-
20% Y5V
C5428 2113743L01 CAP CHIP 220 PF 10% X7R
C5431 2113743L01 CAP CHIP 220 PF 10% X7R
C5433 2113743L41 CAP CHIP 10000 PF 10% X7R
C5501 2311049A78 CAP TANT CHIP 10.0 UF 10%
50V
C5502 2113743N12 CAP CHIP 2.7 PF +-.25PF
COG
C5503 2113743L50 CAP CHIP 33000 PF 10%
C5504 2113743L01 CAP CHIP 220 PF 10% X7R
C5505 2113743E20 CAP CHIP .10 UF 10%
C5506 2113743N26 CAP CHIP 10.0 PF 5% COG
C5507 2113743N18 CAP CHIP 4.7 PF +-.25PF
COG
C5508 2113743L01 CAP CHIP 220 PF 10% X7R
C5509 2113743N50 CAP CHIP 100 PF 5% COG
C5510 2113743E20 CAP CHIP .10 UF 10%
C5512 2113743N44 CAP CHIP 56.0 PF 5% COG
C5513 2113743L48 CAP CHIP 22,000 PF 10%
Reference
Designator
Motorola
Part Number
Description
C5515 2113743L48 CAP CHIP 22,000 PF 10%
C5516 2113743L01 CAP CHIP 220 PF 10% X7R
C5517 2113743E20 CAP CHIP .10 UF 10%
C5518 2113743N38 CAP CHIP 33.0 PF 5% COG
C5520 2113743N62 CAP CHIP 6.0PF 16V .5PF
COG
C5523 2113743N28 CAP CHIP 12.0 PF 5% COG
C5524 2113743N62 CAP CHIP 6.0PF 16V .5PF
COG
C5525 2113743L01 CAP CHIP 220 PF 10% X7R
C5526 2113741N69 CAP CHIP CL2 X7R 10%
100000
C5527 2113740A55 CAP CHIP REEL CL1 +/-30
100
C5535 2111078B38 CAP CHIP RF 68 5 NPO 100V
C5538 2111078B38 CAP CHIP RF 68 5 NPO 100V
C5539 2113740A55 CAP CHIP REEL CL1 +/-30
100
C5540 2113740A55 CAP CHIP REEL CL1 +/-30
100
C5541 2113932E20 CAP CER CHP .10 UF 10%
16V
C5542 2111078B27 CAP CHIP RF 30 5 NPO 100V
C5543 2111078B27 CAP CHIP RF 30 5 NPO 100V
C5544 2113932E20 CAP CER CHP .10 UF 10%
16V
C5545 2111078B27 CAP CHIP RF 30 5 NPO 100V
C5546 2111078B27 CAP CHIP RF 30 5 NPO 100V
C5547 2111078B15 CAP CHIP RF 12 5 NPO 100V
C5548 2111078B15 CAP CHIP RF 12 5 NPO 100V
C5549 2111078B42 CAP CHIP RF 100 5 NPO
100V
C5550 2113741N69 CAP CHIP CL2 X7R 10%
100000
C5551 2111078B10 CAP CHIP RF 7.5 .25 NPO
100V
C5552 2111078B16 CAP CHIP RF 13 5 NPO 100V
C5553 2111078B42 CAP CHIP RF 100 5 NPO
100V
C5554 2113743L41 CAP CHIP 10000 PF 10% X7R
C5555 2113743L01 CAP CHIP 220 PF 10% X7R
C5556 2113743L41 CAP CHIP 10000 PF 10% X7R
C5557 2113743L41 CAP CHIP 10000 PF 10% X7R
C5558 2113743L41 CAP CHIP 10000 PF 10% X7R
Reference
Designator
Motorola
Part Number
Description
C5559 2111078B42 CAP CHIP RF 100 5 NPO
100V
C5560 2111078B42 CAP CHIP RF 100 5 NPO
100V
C5565 2113743L50 CAP CHIP 33000 PF 10%
C5566 2113743N23 CAP CHIP 7.5 PF + -.5PF
COG
C5570 2113741N69 CAP CHIP CL2 X7R 10%
100000
C5571 2311049A78 CAP TANT CHIP 10.0 UF 10%
50V
C5572 2311049C47 CAP TANT CHIP 22.0UF 10%
16V
C5573 2113741N69 CAP CHIP CL2 X7R 10%
100000
C5575 2113743L41 CAP CHIP 10000 PF 10% X7R
C5576 2113743L01 CAP CHIP 220 PF 10% X7R
C5577 2113743L41 CAP CHIP 10000 PF 10% X7R
C5578 2113743L01 CAP CHIP 220 PF 10% X7R
C5579 2113743L01 CAP CHIP 220 PF 10% X7R
C5701 2113743L01 CAP CHIP 220 PF 10% X7R
C5702 2113743L01 CAP CHIP 220 PF 10% X7R
C5703 2113743L01 CAP CHIP 220 PF 10% X7R
C5704 2113743L01 CAP CHIP 220 PF 10% X7R
C5705 2111078A06 CAP CHIP RF 1.5 .25 NPO
100V
C5706 2111078B09 CAP CHIP RF 6.8 .25 NPO
100V
C5707 2111078A01 CAP CHIP RF 1 .25 NPO 100V
C5708 2111078B42 CAP CHIP RF 100 5 NPO
100V
C5709 2111078B34 CAP CHIP RF 47 5 NPO 100V
C5710 2113743N46 QAP CHIP 68.0 PF 5% COG
C5711 2111078B03 CAP CHIP RF 3.9 .25 NPO
100V
C5712 2111078B03 CAP CHIP RF 3.9 .25 NPO
100V
C5713 2111078B14 CAP CHIP RF 11 5 NPO 100V
C5714 2111078B03 CAP CHIP RF 3.9 .25 NPO
100V
C5715 2113743L01 CAP CHIP 220 PF 10% X7R
C5716 2113743N23 CAP CHIP 7.5 PF + -.5PF
COG
C5717 2113743N23 CAP CHIP 7.5 PF + -.5PF
COG
Reference
Designator
Motorola
Part Number
Description
