Schematics, Component Location Diagrams, and Parts Lists: HUE4039A (UHF Range 1) Main Board 7-99
6815854H01-A June 15, 2005
C5718 2113743L01 CAP CHIP 220 PF 10% X7R
C5719 2111078A09 CAP CHIP RF 1.8 .25 NPO
100V
C5720 2111078B10 CAP CHIP RF 7.5 .25 NPO
100V
C5750 2113932E20 CAP CER CHP .10 UF 10%
16V
C5751 2113932E07 CAP CER CHP .022 UF 10%
16V
C5752 2113743S01 CAP CER CHIP 1.0 UF 10%
16V
C5753 2113743K15 CER CHIP CAP .100UF
C5754 2113743L41 CAP CHIP 10000 PF 10% X7R
C5755 2311049A57 CAP TANT CHIP A/P 10UF
10% 16V
C5756 2113743N40 CAP CHIP 39.0 PF 5% COG
C5757 2113743S01 CAP CER CHIP 1.0 UF 10%
16V
C5758 2113932E20 CAP CER CHP .10 UF 10%
16V
C5759 2113743E20 CAP CHIP .10 UF 10%
C5760 2113743L17 CAP CHIP 1000 PF 10% X7R
C5761 2113743L41 CAP CHIP 10000 PF 10% X7R
C5762 2113743E20 CAP CHIP .10 UF 10%
C5763 2113743N38 CAP CHIP 33.0 PF 5% COG
C5764 2113743N40 CAP CHIP 39.0 PF 5% COG
C5765 2113932E20 CAP CER CHP .10 UF 10%
16V
C5766 2113743T19 CAP 10UF 16V CER 3225 X5R
C5767 2113743L17 CAP CHIP 1000 PF 10% X7R
C5768 2113743N50 CAP CHIP 100 PF 5% COG
C5769 2113743K15 CER CHIP CAP .100UF
C5770 2113743T19 CAP 10UF 16V CER 3225 X5R
C5771 2113932E20 CAP CER CHP .10 UF 10%
16V
C5772 2113743K15 CER CHIP CAP .100UF
C5773 2113932E20 CAP CER CHP .10 UF 10%
16V
C5774 2113743N34 CAP CHIP 22.0 PF 5% COG
C5775 2113932E20 CAP CER CHP .10 UF 10%
16V
C5776 2113932E20 CAP CER CHP .10 UF 10%
16V
Reference
Designator
Motorola
Part Number
Description
C5777 2113932E20 CAP CER CHP .10 UF 10%
16V
C5778 2113932E20 CAP CER CHP .10 UF 10%
16V
C5779 2185419D10 CAP CER SUPER L/D
0.0015UF
C5780 2185419D10 CAP CER SUPER L/D
0.0015UF
C5781 2113743E12 CAP CHIP .047 UF 10% X7R
C5782 2185419D06 CAP CER SUPER L/D 0.1UF
C5783 2113743E20 CAP CHIP .10 UF 10%
C5784 2185419D06 CAP CER SUPER L/D 0.1UF
C5785 2185419D06 CAP CER SUPER L/D 0.1UF
C5786 2113743E20 CAP CHIP .10 UF 10%
C5787 2185419D06 CAP CER SUPER L/D 0.1UF
C5788 2311049J11 CAP TANT CHIP 4.7 10 16
C5789 2311049J11 CAP TANT CHIP 4.7 10 16
C5790 2113932E07 CAP CER CHP .022 UF 10%
16V
C5791 2185419D06 CAP CER SUPER L/D 0.1UF
C5792 2185419D06 CAP CER SUPER L/D 0.1UF
C5793 2113928N01 CAP CER CHIP 0.1UF 10%
6.3
C5794 2113743N26 CAP CHIP 10.0 PF 5% COG
C5795 2113743N26 CAP CHIP 10.0 PF 5% COG
C5796 2113743L01 CAP CHIP 220 PF 10% X7R
C5797 2113743T19 CAP 10UF 16V CER 3225 X5R
C5798 2113743N50 CAP CHIP 100 PF 5% COG
C5799 2113743L01 CAP CHIP 220 PF 10% X7R
C5800 2113743N26 CAP CHIP 10.0 PF 5% COG
C5801 2113743N26 CAP CHIP 10.0 PF 5% COG
C5802 2113743L01 CAP CHIP 220 PF 10% X7R
C5803 2113743L05 CAP CHIP 330 PF 10% X7R
C5804 2113743L05 CAP CHIP 330 PF 10% X7R
C5805 2113743L05 CAP CHIP 330 PF 10% X7R
C5806 2113743L05 CAP CHIP 330 PF 10% X7R
C5807 2113743L05 CAP CHIP 330 PF 10% X7R
C5809 2185419D06 CAP CER SUPER L/D 0.1UF
C5810 2185419D06 CAP CER SUPER L/D 0.1UF
C5811 2185419D06 CAP CER SUPER L/D 0.1UF
C5812 2185419D06 CAP CER SUPER L/D 0.1UF
C5813 2113741F17 CAP CHIP CL2 X7R REEL 470
Reference
Designator
Motorola
Part Number
Description
C5816 2113743L01 CAP CHIP 220 PF 10% X7R
C5817 2113743L01 CAP CHIP 220 PF 10% X7R
C5825 2113743L05 CAP CHIP 330 PF 10% X7R
C5826 2113743L05 CAP CHIP 330 PF 10% X7R
C5827 2113743N30 CAP CHIP 15.0 PF 5% COG
C5828 2113743N30 CAP CHIP 15.0 PF 5% COG
C5829 2113743N28 CAP CHIP 12.0 PF 5% COG
C5830 2113743N28 CAP CHIP 12.0 PF 5% COG
C5831 2113928S04 CAP CER CHIP 0.100UF 10V
0402
C5832 2113928S04 CAP CER CHIP 0.100UF 10V
0402
C5833 2113743N10 CAP CHIP 2.2 PF +-.25PF
COG
C5834 2113743L05 CAP CHIP 330 PF 10% X7R
C5835 2113743N19 CAP CHIP 5.1 PF + -.5PF
COG
C5836 2113743L05 CAP CHIP 330 PF 10% X7R
C5837 2113928S04 CAP CER CHIP 0.100UF 10V
0402
C5838 2113928S04 CAP CER CHIP 0.100UF 10V
0402
C5839 2113743N32 CAP CHIP 18.0 PF 5% COG
C5840 2113743N27 CAP CHIP 11.0 PF 5% COG
C5841 2113743L01 CAP CHIP 220 PF 10% X7R
C5842 2113743L01 CAP CHIP 220 PF 10% X7R
C5843 2113928S04 CAP CER CHIP 0.100UF 10V
0402
C5844 2113928S04 CAP CER CHIP 0.100UF 10V
0402
C5845 2113743N25 CAP CHIP 9.1 PF + -.5PF
COG
C5846 2113743N50 CAP CHIP 100 PF 5% COG
C5847 2113743L05 CAP CHIP 330 PF 10% X7R
C5848 2113743L05 CAP CHIP 330 PF 10% X7R
C5849 2113743N22 CAP CHIP 6.8 PF + -.5PF
COG
C5850 2113743N32 CAP CHIP 18.0 PF 5% COG
C5851 2113743N33 CAP CHIP 20.0 PF 5% COG
C5852 2113743N28 CAP CHIP 12.0 PF 5% COG
C5853 2113743L05 CAP CHIP 330 PF 10% X7R
C5854 2113743N33 CAP CHIP 20.0 PF 5% COG
C5855 2113743N32 CAP CHIP 18.0 PF 5% COG
Reference
Designator
Motorola
Part Number
Description
C5856 2113928S04 CAP CER CHIP 0.100UF 10V
0402
C5857 2113743N28 CAP CHIP 12.0 PF 5% COG
C5858 2113743N32 CAP CHIP 18.0 PF 5% COG
C5859 2113743N50 CAP CHIP 100 PF 5% COG
C5860 2113743L05 CAP CHIP 330 PF 10% X7R
C5861 2113928S04 CAP CER CHIP 0.100UF 10V
0402
C5862 2113743L05 CAP CHIP 330 PF 10% X7R
C5863 2113743N13 CAP CHIP 3.0 PF +-.25PF
COG
C5900 2113928S04 CAP CER CHIP 0.100UF 10V
0402
C5901 2113743L01 CAP CHIP 220 PF 10% X7R
C5904 2113928S04 CAP CER CHIP 0.100UF 10V
0402
C5905 2113743N19 CAP CHIP 5.1 PF + -.5PF
COG
C5906 2113743N08 CAP CHIP 1.6 PF +-.25PF
COG
C5907 2113743N19 CAP CHIP 5.1 PF + -.5PF
COG
C5908 2113743N50 CAP CHIP 100 PF 5% COG
C5909 2113743N50 CAP CHIP 100 PF 5% COG
C5910 2113743N20 CAP CHIP 5.6 PF + -.5PF
COG
C5911 2113743N25 CAP CHIP 9.1 PF + -.5PF
COG
C5912 2113743N24 CAP CHIP 8.2 PF + -.5PF
COG
C5913 2113743L01 CAP CHIP 220 PF 10% X7R
C5914 2113743L01 CAP CHIP 220 PF 10% X7R
C5915 2113743N22 CAP CHIP 6.8 PF + -.5PF
COG
C5916 2113928S04 CAP CER CHIP 0.100UF 10V
0402
C5917 2113743L01 CAP CHIP 220 PF 10% X7R
C5919 2113743L01 CAP CHIP 220 PF 10% X7R
C5920 2113928S04 CAP CER CHIP 0.100UF 10V
0402
C5921 2113743N12 CAP CHIP 2.7 PF +-.25PF
COG
C5922 2113743N18 CAP CHIP 4.7 PF +-.25PF
COG
Reference
Designator
Motorola
Part Number
Description
To Next Page
