Motorola Astro XTL 1500 - Page 382

Schematics, Component Location Diagrams, and Parts Lists: HUE4040A (UHF Range 2) Main Board 7-143
6815854H01-A June 15, 2005
Q5253 4813824A17 XSTR PNP40V .2A GENP
B=100-300
Q5255 4813824A10 TSTR NPN 40V .2A GEN
PURP
Q5256 4813824A17 XSTR PNP40V .2A GENP
B=100-300
Q5257 4880048M01 TSTR NPN DIG 47K/47K
Q5258 4813824A17 XSTR PNP40V .2A GENP
B=100-300
Q5401 4805218N55 TRANSISTOR 3 LEAD BFQ67
Q5402 4880048M01 TSTR NPN DIG 47K/47K
Q5501 4805218N63 RF TRANS SOT 323 BFQ67W
Q5502 4813976A03 TSTR, 450 MHZ, 8W, 7.5V,
PLD 1.5
Q5503 4813976A06 TSTR, UHF 70 W, 12.5 V
LDMOS
Q5570 4880048M01 TSTR NPN DIG 47K/47K
Q5706 4805921T04 XISTOR FMC1 RH REELED
Q5707 4805921T04 XISTOR FMC1 RH REELED
Q5708 4805921T04 XISTOR FMC1 RH REELED
Q5709 4805921T04 XISTOR FMC1 RH REELED
Q5710 4805921T04 XISTOR FMC1 RH REELED
Q5750 4813824A10 TSTR NPN 40V .2A GEN
PURP
Q5751 4813824A10 TSTR NPN 40V .2A GEN
PURP
Q5752 4813824A17 XSTR PNP40V .2A GENP
B=100-300
Q5755 4805218N63 RF TRANS SOT 323 BFQ67W
Q5825 4805218N63 RF TRANS SOT 323 BFQ67W
Q5826 4805218N63 RF TRANS SOT 323 BFQ67W
Q5828 4805218N63 RF TRANS SOT 323 BFQ67W
Q5829 4805218N63 RF TRANS SOT 323 BFQ67W
Q5901 4805793Y10 XSTR,BIP RF SMALL
SIGNAL,SLCN,NPN,N
Q5902 4805218N63 RF TRANS SOT 323 BFQ67W
Q5903 4805793Y10 XSTR,BIP RF SMALL
SIGNAL,SLCN,NPN,N
Q5904 4805218N63 RF TRANS SOT 323 BFQ67W
Q5905 4805793Y10 XSTR,BIP RF SMALL
SIGNAL,SLCN,NPN,N
Q5906 4805218N63 RF TRANS SOT 323 BFQ67W
R0101 0662057M98 RES. CHIP 10K 5% 20X40
R0102 0662057M98 RES. CHIP 10K 5% 20X40
Reference
Designator
Motorola
Part Number
Description
R0104 0662057M98 RES. CHIP 10K 5% 20X40
R0105 0662057M98 RES. CHIP 10K 5% 20X40
R0106 0662057M98 RES. CHIP 10K 5% 20X40
R0107 0662057M01 RES. CHIP 0 5% 20X40
R0109 0662057M98 RES. CHIP 10K 5% 20X40
R0110 0662057M98 RES. CHIP 10K 5% 20X40
R0111 0662057M86 RES. CHIP 3300 5% 20X40
R0114 0662057M01 RES. CHIP 0 5% 20X40
R0116 0662057B46 CHIP RES 10.0 MEG OHMS
5%
R0117 0662057B46 CHIP RES 10.0 MEG OHMS
5%
R0119 0662057N39 RES. CHIP 470K 5% 20X40
R0120 0662057M98 RES. CHIP 10K 5% 20X40
R0121 0662057M98 RES. CHIP 10K 5% 20X40
R0122 0662057M82 RES. CHIP 2200 5% 20X40
R0125 0662057M98 RES. CHIP 10K 5% 20X40
R0126 0662057M01 RES. CHIP 0 5% 20X40
R0128 0662057M50 RES. CHIP 100 5% 20X40
R0129 0662057M98 RES. CHIP 10K 5% 20X40
R0130 0662057M98 RES. CHIP 10K 5% 20X40
R0200 0662057M74 RES. CHIP 1000 5% 20X40
R0201 0662057M01 RES. CHIP 0 5% 20X40
R0204 0662057M68 RES. CHIP 560 5% 20X40
R0205 0662057N09 RES. CHIP 27K 5% 20X40
R0208 0662057N23 RES. CHIP 100K 5% 20X40
R0209 0662057N07 RES. CHIP 22K 5% 20X40
R0210 0662057N23 RES. CHIP 100K 5% 20X40
R0212 0662057N23 RES. CHIP 100K 5% 20X40
R0213 0662057M50 RES. CHIP 100 5% 20X40
R0215 0662057M98 RES. CHIP 10K 5% 20X40
R0216 0662057N23 RES. CHIP 100K 5% 20X40
R0218 0662057M74 RES. CHIP 1000 5% 20X40
R0219 0662057M74 RES. CHIP 1000 5% 20X40
R0220 0662057N05 RES. CHIP 18K 5% 20X40
R0221 0662057M98 RES. CHIP 10K 5% 20X40
R0222 0662057M98 RES. CHIP 10K 5% 20X40
R0224 0662057M01 RES. CHIP 0 5% 20X40
R0225 0662057M98 RES. CHIP 10K 5% 20X40
R0227 0662057N19 RES. CHIP 68K 5% 20X40
R0228 0662057N11 RES. CHIP 33K 5% 20X40
Reference
Designator
Motorola
Part Number
Description
R0229 0662057N19 RES. CHIP 68K 5% 20X40
R0230 0662057N11 RES. CHIP 33K 5% 20X40
R0231 0662057C13 CHIP RES 2.7 OHMS 5%
R0235 0662057M74 RES. CHIP 1000 5% 20X40
R0236 0662057M97 RES. CHIP 9100 5% 20X40
R0300 0662057M50 RES. CHIP 100 5% 20X40
R0301 0662057M50 RES. CHIP 100 5% 20X40
R0303 0662057M78 RES. CHIP 1500 5% 20X40
R0304 0662057M34 RES. CHIP 22 5% 20X40
R0305 0662057M34 RES. CHIP 22 5% 20X40
R0307 0662057M98 RES. CHIP 10K 5% 20X40
R0310 0662057M34 RES. CHIP 22 5% 20X40
R0403 0662057M98 RES. CHIP 10K 5% 20X40
R0404 0662057M74 RES. CHIP 1000 5% 20X40
R0405 0662057M74 RES. CHIP 1000 5% 20X40
R0406 0662057M68 RES. CHIP 560 5% 20X40
R0407 0662057M50 RES. CHIP 100 5% 20X40
R0408 0662057M50 RES. CHIP 100 5% 20X40
R0409 0662057M98 RES. CHIP 10K 5% 20X40
R0410 0662057M50 RES. CHIP 100 5% 20X40
R0411 0662057M98 RES. CHIP 10K 5% 20X40
R0412 0662057M50 RES. CHIP 100 5% 20X40
R0415 0662057M50 RES. CHIP 100 5% 20X40
R0416 0662057M50 RES. CHIP 100 5% 20X40
R0417 0662057M50 RES. CHIP 100 5% 20X40
R0418 0662057M50 RES. CHIP 100 5% 20X40
R0419 0662057M90 RES. CHIP 4700 5% 20X40
R0420 0662057M98 RES. CHIP 10K 5% 20X40
R0421 0662057M01 RES. CHIP 0 5% 20X40
R0422 0662057V15 RES CHIP 33K 1% 1/16W
R0425 0662057M98 RES. CHIP 10K 5% 20X40
R0430 0662057M01 RES. CHIP 0 5% 20X40
R0431 0662057M98 RES. CHIP 10K 5% 20X40
R0432 0662057M50 RES. CHIP 100 5% 20X40
R0435 0662057M74 RES. CHIP 1000 5% 20X40
R0500 0662057N23 RES. CHIP 100K 5% 20X40
R0502 0662057N37 RES. CHIP 390K 5% 20X40
R0503 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R0504 0662057N23 RES. CHIP 100K 5% 20X40
R0505 0662057M98 RES. CHIP 10K 5% 20X40
Reference
Designator
Motorola
Part Number
Description
R0506 0662057M98 RES. CHIP 10K 5% 20X40
R0507 0662057M98 RES. CHIP 10K 5% 20X40
R0508 0662057M86 RES. CHIP 3300 5% 20X40
R0509 0662057M74 RES. CHIP 1000 5% 20X40
R0510 0662057V18 RES CHIP 43K 1% 1/16W
R0511 0662057V15 RES CHIP 33K 1% 1/16W
R0512 0662057V02 RES CHIP 10K 1% 1/16W
R0513 0662057V17 RES CHIP 39K 1% 1/16W
R0514 0662057M01 RES. CHIP 0 5% 20X40
R0515 0662057M74 RES. CHIP 1000 5% 20X40
R0516 0662057N23 RES. CHIP 100K 5% 20X40
R0517 0662057M90 RES. CHIP 4700 5% 20X40
R0518 0662057M98 RES. CHIP 10K 5% 20X40
R0519 0662057C27 CHIP RES 10 OHMS 5%
R0520 0662057N15 RES. CHIP 47K 5% 20X40
R0521 0662057V17 RES CHIP 39K 1% 1/16W
R0522 0662057V10 RES CHIP 20K 1% 1/16W
R0523 0662057N23 RES. CHIP 100K 5% 20X40
R0525 0662057M50 RES. CHIP 100 5% 20X40
R0526 0662057M50 RES. CHIP 100 5% 20X40
R0528 0662057M95 RES. CHIP 7500 5% 20X40
R0529 0662057M76 RES. CHIP 1200 5% 20X40
R0530 0662057N35 RES. CHIP 330K 5% 20X40
R0531 0662057N23 RES. CHIP 100K 5% 20X40
R0532 0662057M86 RES. CHIP 3300 5% 20X40
R0620 0662057M50 RES. CHIP 100 5% 20X40
R0621 0662057M50 RES. CHIP 100 5% 20X40
R0622 0662057M50 RES. CHIP 100 5% 20X40
R0623 0662057M50 RES. CHIP 100 5% 20X40
R0624 0662057M50 RES. CHIP 100 5% 20X40
R0625 0662057M98 RES. CHIP 10K 5% 20X40
R0626 0662057N23 RES. CHIP 100K 5% 20X40
R0627 0662057N23 RES. CHIP 100K 5% 20X40
R0628 0662057N23 RES. CHIP 100K 5% 20X40
R0629 0662057M98 RES. CHIP 10K 5% 20X40
R0630 0662057N23 RES. CHIP 100K 5% 20X40
R0631 0662057M01 RES. CHIP 0 5% 20X40
R0634 0662057N23 RES. CHIP 100K 5% 20X40
R0635 0662057N23 RES. CHIP 100K 5% 20X40
R0636 0662057M98 RES. CHIP 10K 5% 20X40
R0639 0662057M98 RES. CHIP 10K 5% 20X40
Reference
Designator
Motorola
Part Number
Description
