Motorola Astro XTL 1500 - Page 383

7-144 Schematics, Component Location Diagrams, and Parts Lists: HUE4040A (UHF Range 2) Main Board
June 15, 2005 6815854H01-A
R0739 0662057M50 RES. CHIP 100 5% 20X40
R0901 0662057M96 RES. CHIP 8200 5% 20X40
R0902 0662057N23 RES. CHIP 100K 5% 20X40
R0903 0662057N23 RES. CHIP 100K 5% 20X40
R0904 0662057N23 RES. CHIP 100K 5% 20X40
R0905 0662057N23 RES. CHIP 100K 5% 20X40
R0906 0662057M50 RES. CHIP 100 5% 20X40
R0908 0662057C13 CHIP RES 2.7 OHMS 5%
R0910 0662057V25 RES CHIP 82K 1% 1/16W
R0911 0662057V04 RES CHIP 12K 1% 1/16W
R0912 0662057V04 RES CHIP 12K 1% 1/16W
R0913 0662057V30 RES CHIP 130K 1% 1/16W
R0914 0662057V04 RES CHIP 12K 1% 1/16W
R0915 0662057M74 RES. CHIP 1000 5% 20X40
R0917 0662057M01 RES. CHIP 0 5% 20X40
R0923 0662057M50 RES. CHIP 100 5% 20X40
R0924 0662057M50 RES. CHIP 100 5% 20X40
R0930 0662057N06 RES. CHIP 20K 5% 20X40
R0931 0662057M98 RES. CHIP 10K 5% 20X40
R0932 0662057M01 RES. CHIP 0 5% 20X40
R0934 0662057M74 RES. CHIP 1000 5% 20X40
R0935 0662057M01 RES. CHIP 0 5% 20X40
R0936 0662057M01 RES. CHIP 0 5% 20X40
R0938 0662057M01 RES. CHIP 0 5% 20X40
R0940 0662057M01 RES. CHIP 0 5% 20X40
R0942 0662057M96 RES. CHIP 8200 5% 20X40
R0943 0662057N03 RES. CHIP 15K 5% 20X40
R0944 0662057M98 RES. CHIP 10K 5% 20X40
R0945 0662057N11 RES. CHIP 33K 5% 20X40
R0947 0662057V02 RES CHIP 10K 1% 1/16W
R0949 0662057V02 RES CHIP 10K 1% 1/16W
R0950 0662057M01 RES. CHIP 0 5% 20X40
R0951 0662057U98 RES CHIP 7.5K 1% 1/16W
R0952 0662057U78 RES CHIP 1.2K 1% 1/16W
R0953 0662057M01 RES. CHIP 0 5% 20X40
R0954 0662057U98 RES CHIP 7.5K 1% 1/16W
R0955 0662057N23 RES. CHIP 100K 5% 20X40
R0956 0662057V04 RES CHIP 12K 1% 1/16W
R0957 0662057V02 RES CHIP 10K 1% 1/16W
R0959 0662057V02 RES CHIP 10K 1% 1/16W
R0960 0662057N06 RES. CHIP 20K 5% 20X40
Reference
Designator
Motorola
Part Number
Description
R0961 0662057N23 RES. CHIP 100K 5% 20X40
R0962 0662057N23 RES. CHIP 100K 5% 20X40
R0963 0662057N08 RES. CHIP 24K 5% 20X40
R0964 0662057N08 RES. CHIP 24K 5% 20X40
R0965 0662057M01 RES. CHIP 0 5% 20X40
R0966 0662057M01 RES. CHIP 0 5% 20X40
R0967 0662057V27 RES CHIP 100K 1% 1/16W
R0968 0662057V02 RES CHIP 10K 1% 1/16W
R0971 0662057V07 RES CHIP 15K 1% 1/16W
R0972 0662057U93 RES CHIP 4.7K 1% 1/16W
R0973 0662057N17 RES. CHIP 56K 5% 20X40
R0974 0662057V02 RES CHIP 10K 1% 1/16W
R0975 0662057V02 RES CHIP 10K 1% 1/16W
R0976 0662057M74 RES. CHIP 1000 5% 20X40
R0977 0662057M50 RES. CHIP 100 5% 20X40
R0978 0662057M98 RES. CHIP 10K 5% 20X40
R0979 0662057M01 RES. CHIP 0 5% 20X40
R0981 0662057M84 RES. CHIP 2700 5% 20X40
R0982 0662057N23 RES. CHIP 100K 5% 20X40
R0983 0662057M74 RES. CHIP 1000 5% 20X40
R0984 0662057M01 RES. CHIP 0 5% 20X40
R0985 0662057M01 RES. CHIP 0 5% 20X40
R0987 0662057M01 RES. CHIP 0 5% 20X40
R0988 0662057M98 RES. CHIP 10K 5% 20X40
R0989 0662057N17 RES. CHIP 56K 5% 20X40
R0990 0662057M91 RES. CHIP 5100 5% 20X40
R0991 0662057M98 RES. CHIP 10K 5% 20X40
R0992 0662057V27 RES CHIP 100K 1% 1/16W
R0993 0662057U78 RES CHIP 1.2K 1% 1/16W
R0994 0662057M88 RES. CHIP 3900 5% 20X40
R0995 0662057U78 RES CHIP 1.2K 1% 1/16W
R0996 0662057M98 RES. CHIP 10K 5% 20X40
R0997 0662057U78 RES CHIP 1.2K 1% 1/16W
R0998 0662057V02 RES CHIP 10K 1% 1/16W
R0999 0662057V02 RES CHIP 10K 1% 1/16W
R5000 0662057M43 RES CHIP 51 5 20X40
R5001 0662057M01 RES. CHIP 0 5% 20X40
R5002 0662057M66 RES. CHIP 470 5% 20X40
R5003 0662057N23 RES. CHIP 100K 5% 20X40
R5005 0662057M98 RES. CHIP 10K 5% 20X40
R5006 0662057M62 RES. CHIP 330 5% 20X40
Reference
Designator
Motorola
Part Number
Description
R5010 0662057N05 RES. CHIP 18K 5% 20X40
R5011 0662057N03 RES. CHIP 15K 5% 20X40
R5013 0662057M70 RES. CHIP 680 5% 20X40
R5014 0662057M01 RES. CHIP 0 5% 20X40
R5015 0662057M01 RES. CHIP 0 5% 20X40
R5016 0662057M01 RES. CHIP 0 5% 20X40
R5017 0662057M01 RES. CHIP 0 5% 20X40
R5018 0662057M01 RES. CHIP 0 5% 20X40
R5019 0662057M01 RES. CHIP 0 5% 20X40
R5020 0662057M98 RES. CHIP 10K 5% 20X40
R5022 0662057M60 RES. CHIP 270 5% 20X40
R5023 0662057N30 RES. CHIP 200K 5% 20X40
R5025 0662057M74 RES. CHIP 1000 5% 20X40
R5026 0662057M34 RES. CHIP 22 5% 20X40
R5027 0662057M50 RES. CHIP 100 5% 20X40
R5028 0662057M94 RES. CHIP 6800 5% 20X40
R5029 0662057N06 RES. CHIP 20K 5% 20X40
R5030 0662057N11 RES. CHIP 33K 5% 20X40
R5031 0662057M66 RES. CHIP 470 5% 20X40
R5032 0662057M76 RES. CHIP 1200 5% 20X40
R5034 0662057M01 RES. CHIP 0 5% 20X40
R5050 0662057M36 RES. CHIP 27 5% 20X40
R5051 0662057M49 RES. CHIP 91 5% 20X40
R5250 0662057N15 RES. CHIP 47K 5% 20X40
R5251 0662057N15 RES. CHIP 47K 5% 20X40
R5252 0662057M74 RES. CHIP 1000 5% 20X40
R5253 0662057N15 RES. CHIP 47K 5% 20X40
R5254 0662057N15 RES. CHIP 47K 5% 20X40
R5255 0662057M74 RES. CHIP 1000 5% 20X40
R5256 0662057M90 RES. CHIP 4700 5% 20X40
R5300 0662057M90 RES. CHIP 4700 5% 20X40
R5301 0662057M98 RES. CHIP 10K 5% 20X40
R5302 0662057C75 CHIP RES 1000 OHMS 5%
R5303 0662057M90 RES. CHIP 4700 5% 20X40
R5304 0662057M74 RES. CHIP 1000 5% 20X40
R5305 0662057M90 RES. CHIP 4700 5% 20X40
R5306 0662057N01 RES CHIP 12K 5% 20X40
R5308 0662057M46 RES. CHIP 68 5% 20X40
R5309 0662057M36 RES. CHIP 27 5% 20X40
R5310 0662057C75 CHIP RES 1000 OHMS 5%
R5311 0662057M98 RES. CHIP 10K 5% 20X40
Reference
Designator
Motorola
Part Number
Description
R5313 0662057M90 RES. CHIP 4700 5% 20X40
R5315 0662057M74 RES. CHIP 1000 5% 20X40
R5317 0662057M74 RES. CHIP 1000 5% 20X40
R5319 0662057M66 RES. CHIP 470 5% 20X40
R5322 0662057M83 RES. CHIP 2400 5% 20X40
R5323 0662057N03 RES. CHIP 15K 5% 20X40
R5324 0662057C31 CHIP RES 15 OHMS 5%
R5325 0662057C31 CHIP RES 15 OHMS 5%
R5326 0662057C31 CHIP RES 15 OHMS 5%
R5327 0662057M56 RES. CHIP 180 5% 20X40
R5330 0662057M42 RES. CHIP 47 5% 20X40
R5332 0662057M78 RES. CHIP 1500 5% 20X40
R5333 0662057M42 RES. CHIP 47 5% 20X40
R5334 0662057M78 RES. CHIP 1500 5% 20X40
R5337 0662057N07 RES. CHIP 22K 5% 20X40
R5381 0662057M01 RES. CHIP 0 5% 20X40
R5383 0662057M56 RES. CHIP 180 5% 20X40
R5384 0662057M56 RES. CHIP 180 5% 20X40
R5385 0662057M56 RES. CHIP 180 5% 20X40
R5386 0662057M56 RES. CHIP 180 5% 20X40
R5387 0662057M42 RES. CHIP 47 5% 20X40
R5389 0662057M01 RES. CHIP 0 5% 20X40
R5400 0662057M70 RES. CHIP 680 5% 20X40
R5401 0662057N09 RES. CHIP 27K 5% 20X40
R5402 0662057M94 RES. CHIP 6800 5% 20X40
R5403 0662057M62 RES. CHIP 330 5% 20X40
R5404 0662057M01 RES. CHIP 0 5% 20X40
R5405 0662057M98 RES. CHIP 10K 5% 20X40
R5406 0662057M74 RES. CHIP 1000 5% 20X40
R5408 0662057M96 RES. CHIP 8200 5% 20X40
R5412 0662057M01 RES. CHIP 0 5% 20X40
R5414 0662057M01 RES. CHIP 0 5% 20X40
R5415 0662057M01 RES. CHIP 0 5% 20X40
R5501 0662057A29 CHIP RES 150 OHMS 5%
R5502 0662057M94 RES. CHIP 6800 5% 20X40
R5503 0662057M90 RES. CHIP 4700 5% 20X40
R5505 0662057A29 CHIP RES 150 OHMS 5%
R5506 0662057M48 RES. CHIP 82 5% 20X40
R5507 0662057M50 RES. CHIP 100 5% 20X40
R5510 0662057M48 RES. CHIP 82 5% 20X40
R5511 0662057M10 RES. CHIP 2.2 5% 20X40
Reference
Designator
Motorola
Part Number
Description
