Schematics, Component Location Diagrams, and Parts Lists: HUE4040A (UHF Range 2) Main Board 7-145
6815854H01-A June 15, 2005
R5512 0662057M10 RES. CHIP 2.2 5% 20X40
R5513 0662057M10 RES. CHIP 2.2 5% 20X40
R5514 0662057M10 RES. CHIP 2.2 5% 20X40
R5515 0662057M10 RES. CHIP 2.2 5% 20X40
R5516 0662057C44 CHIP RES 51 OHMS 5%
R5517 0680195M01 RES CHIP 10 OHMS 5% .5W
R5519 0662057N23 RES. CHIP 100K 5% 20X40
R5520 0662057C75 CHIP RES 1000 OHMS 5%
R5521 0662057C75 CHIP RES 1000 OHMS 5%
R5522 0685934D01 RES FIXED CHIP (CURRENT
SENOR)
R5523 0680195M01 RES CHIP 10 OHMS 5% .5W
R5524 0680194M13 RES 33 OHMS 5% 1W
R5525 0662057C75 CHIP RES 1000 OHMS 5%
R5526 0662057C75 CHIP RES 1000 OHMS 5%
R5527 0662057C75 CHIP RES 1000 OHMS 5%
R5528 0662057M54 RES. CHIP 150 5% 20X40
R5529 0662057M56 RES. CHIP 180 5% 20X40
R5530 0611077A30 RES CHIP 15 5 1/8W
R5532 0662057C13 CHIP RES 2.7 OHMS 5%
R5533 0611077A30 RES CHIP 15 5 1/8W
R5534 0611077A30 RES CHIP 15 5 1/8W
R5535 0680195M01 RES CHIP 10 OHMS 5% .5W
R5536 0611077A30 RES CHIP 15 5 1/8W
R5538 0611077A30 RES CHIP 15 5 1/8W
R5539 0611077A30 RES CHIP 15 5 1/8W
R5540 0611077A30 RES CHIP 15 5 1/8W
R5541 0611077A30 RES CHIP 15 5 1/8W
R5542 0611077A30 RES CHIP 15 5 1/8W
R5543 0611077A30 RES CHIP 15 5 1/8W
R5544 0611077A30 RES CHIP 15 5 1/8W
R5545 0611077A30 RES CHIP 15 5 1/8W
R5546 0662057N03 RES. CHIP 15K 5% 20X40
R5547 0662057N03 RES. CHIP 15K 5% 20X40
R5548 0662057M81 RES. CHIP 2000 5% 20X40
R5549 0662057N14 RES. CHIP 43K 5% 20X40
R5550 0662057N03 RES. CHIP 15K 5% 20X40
R5551 0662057M81 RES. CHIP 2000 5% 20X40
R5552 0662057N03 RES. CHIP 15K 5% 20X40
R5553 0662057N03 RES. CHIP 15K 5% 20X40
R5554 0662057N14 RES. CHIP 43K 5% 20X40
Reference
Designator
Motorola
Part Number
Description
R5555 0662057N03 RES. CHIP 15K 5% 20X40
R5556 0662057V18 RES CHIP 43K 1% 1/16W
R5557 0662057M94 RES. CHIP 6800 5% 20X40
R5570 0662057C13 CHIP RES 2.7 OHMS 5%
R5571 0662057N11 RES. CHIP 33K 5% 20X40
R5572 0662057U98 RES CHIP 7.5K 1% 1/16W
R5573 0662057U78 RES CHIP 1.2K 1% 1/16W
R5701 0680194M13 RES 33 OHMS 5% 1W
R5702 0662057A53 CHIP RES 1500 OHMS 5%
R5703 0662057A84 CHIP RES 30K OHMS 5%
R5704 0680149M02 THERMISTOR CHIP 100K
OHM
R5705 0662057A35 CHIP RES 270 OHMS 5%
R5706 0662057A35 CHIP RES 270 OHMS 5%
R5707 0662057A35 CHIP RES 270 OHMS 5%
R5708 0662057A35 CHIP RES 270 OHMS 5%
R5709 0662057A53 CHIP RES 1500 OHMS 5%
R5710 0662057A94 CHIP RES 75K OHMS 5%
R5711 0662057A84 CHIP RES 30K OHMS 5%
R5712 0680149M02 THERMISTOR CHIP 100K
OHM
R5750 0662057M74 RES. CHIP 1000 5% 20X40
R5751 0662057M98 RES. CHIP 10K 5% 20X40
R5752 0662057N15 RES. CHIP 47K 5% 20X40
R5753 0662057M91 RES. CHIP 5100 5% 20X40
R5754 0662057N15 RES. CHIP 47K 5% 20X40
R5755 0662057M01 RES. CHIP 0 5% 20X40
R5758 0662057M86 RES. CHIP 3300 5% 20X40
R5759 0662057M81 RES. CHIP 2000 5% 20X40
R5761 0662057N23 RES. CHIP 100K 5% 20X40
R5762 0662057N23 RES. CHIP 100K 5% 20X40
R5763 0662057M74 RES. CHIP 1000 5% 20X40
R5764 0662057N15 RES. CHIP 47K 5% 20X40
R5765 0662057M91 RES. CHIP 5100 5% 20X40
R5766 0662057N23 RES. CHIP 100K 5% 20X40
R5767 0662057N15 RES. CHIP 47K 5% 20X40
R5768 0662057M50 RES. CHIP 100 5% 20X40
R5769 0662057M01 RES. CHIP 0 5% 20X40
R5771 0662057M54 RES. CHIP 150 5% 20X40
R5772 0662057M71 RES. CHIP 750 5% 20X40
R5773 0662057M54 RES. CHIP 150 5% 20X40
Reference
Designator
Motorola
Part Number
Description
R5774 0662057M48 RES. CHIP 82 5% 20X40
R5775 0662057M50 RES. CHIP 100 5% 20X40
R5776 0662057M74 RES. CHIP 1000 5% 20X40
R5777 0662057M74 RES. CHIP 1000 5% 20X40
R5778 0662057M72 RES. CHIP 820 5% 20X40
R5779 0662057N01 RES CHIP 12K 5% 20X40
R5780 0662057M84 RES. CHIP 2700 5% 20X40
R5782 0662057N15 RES. CHIP 47K 5% 20X40
R5783 0662057N15 RES. CHIP 47K 5% 20X40
R5784 0662057N15 RES. CHIP 47K 5% 20X40
R5785 0662057N15 RES. CHIP 47K 5% 20X40
R5786 0662057N15 RES. CHIP 47K 5% 20X40
R5787 0662057N31 RES. CHIP 220K 5% 20X40
R5788 0662057M43 RES CHIP 51 5 20X40
R5825 0662057M84 RES. CHIP 2700 5% 20X40
R5826 0662057M84 RES. CHIP 2700 5% 20X40
R5827 0662057C61 CHIP RES 270 OHMS 5%
R5828 0662057C61 CHIP RES 270 OHMS 5%
R5829 0662057M79 RES. CHIP 1600 5% 20X40
R5830 0662057M81 RES. CHIP 2000 5% 20X40
R5831 0662057M38 RES. CHIP 33 5% 20X40
R5832 0662057M38 RES. CHIP 33 5% 20X40
R5833 0662057M60 RES. CHIP 270 5% 20X40
R5834 0662057M60 RES. CHIP 270 5% 20X40
R5837 0662057M50 RES. CHIP 100 5% 20X40
R5838 0662057M50 RES. CHIP 100 5% 20X40
R5839 0662057M43 RES CHIP 51 5 20X40
R5840 0662057M43 RES CHIP 51 5 20X40
R5841 0662057M50 RES. CHIP 100 5% 20X40
R5842 0662057M50 RES. CHIP 100 5% 20X40
R5843 0662057M58 RES. CHIP 220 5% 20X40
R5845 0662057M84 RES. CHIP 2700 5% 20X40
R5846 0662057N01 RES CHIP 12K 5% 20X40
R5848 0662057M72 RES. CHIP 820 5% 20X40
R5849 0662057M30 RES. CHIP 15 5% 20X40
R5850 0662057M58 RES. CHIP 220 5% 20X40
R5851 0662057M90 RES. CHIP 4700 5% 20X40
R5852 0662057M90 RES. CHIP 4700 5% 20X40
R5853 0662057M66 RES. CHIP 470 5% 20X40
R5854 0662057M63 RES. CHIP 360 5% 20X40
R5900 0662057M81 RES. CHIP 2000 5% 20X40
Reference
Designator
Motorola
Part Number
Description
R5902 0662057M58 RES. CHIP 220 5% 20X40
R5903 0662057M79 RES. CHIP 1600 5% 20X40
R5904 0662057M60 RES. CHIP 270 5% 20X40
R5905 0662057M50 RES. CHIP 100 5% 20X40
R5909 0662057M47 RES. CHIP 75 5% 20X40
R5910 0662057M38 RES. CHIP 33 5% 20X40
R5911 0662057C67 CHIP RES 470 OHMS 5%
R5912 0662057M79 RES. CHIP 1600 5% 20X40
R5914 0662057M72 RES. CHIP 820 5% 20X40
R5915 0662057M60 RES. CHIP 270 5% 20X40
R5916 0662057M81 RES. CHIP 2000 5% 20X40
R5917 0662057N01 RES CHIP 12K 5% 20X40
R5918 0662057M50 RES. CHIP 100 5% 20X40
R5919 0662057M47 RES. CHIP 75 5% 20X40
R5921 0662057M84 RES. CHIP 2700 5% 20X40
R5922 0662057M38 RES. CHIP 33 5% 20X40
R5923 0662057C67 CHIP RES 470 OHMS 5%
R5924 0662057M79 RES. CHIP 1600 5% 20X40
R5926 0662057M72 RES. CHIP 820 5% 20X40
R5927 0662057M81 RES. CHIP 2000 5% 20X40
R5928 0662057M60 RES. CHIP 270 5% 20X40
R5929 0662057N01 RES CHIP 12K 5% 20X40
R5930 0662057M43 RES CHIP 51 5 20X40
R5931 0662057M47 RES. CHIP 75 5% 20X40
R5932 0662057M47 RES. CHIP 75 5% 20X40
R5933 0662057M84 RES. CHIP 2700 5% 20X40
R5934 0662057M38 RES. CHIP 33 5% 20X40
R5935 0662057C67 CHIP RES 470 OHMS 5%
R5937 0662057M62 RES. CHIP 330 5% 20X40
R5938 0662057M90 RES. CHIP 4700 5% 20X40
R5939 0662057M90 RES. CHIP 4700 5% 20X40
R5940 0662057M63 RES. CHIP 360 5% 20X40
R5941 0662057M58 RES. CHIP 220 5% 20X40
R5942 0662057M50 RES. CHIP 100 5% 20X40
R5948 0662057M47 RES. CHIP 75 5% 20X40
R5949 0662057M30 RES. CHIP 15 5% 20X40
R5950 0662057M58 RES. CHIP 220 5% 20X40
SH5400 2685882A01 SHIELD VCO TANK
T5380 2584600T01 BALUN RF
T5381 2584600T01 BALUN RF
Reference
Designator
Motorola
Part Number
Description
