7-146 Schematics, Component Location Diagrams, and Parts Lists: HUE4040A (UHF Range 2) Main Board
June 15, 2005 6815854H01-A
Note: For optimum performance, diodes, transistors and
integrated circuits must be ordered by MOTOROLA part
numbers.
U0001 0105958T50 XTL5000 DAUGHTER BD W/
BRAVO
U0102 5185623B01 HIGH SPEED CMOS
INVERTER
U0103 5113837A15 IC 3.3V QUAD BUFFER
U0104 5113837A15 IC 3.3V QUAD BUFFER
U0105 5113805B78 IC 1 GATE 2 INPUT NAND
U0200 5105109Z38 3 VOLT LINEAR PCM CODEC
FILTER
U0201 5113819A14 IC QD OP AMP _33204_
U0202 5185143E67 INTEGRATED CIRCUITS
U0203 5162852A79 IC MOS TTL SPDT ANALOG
SC70
U0204 5185794L01 AUDIO AMP TAPE AND REEL
U0206 5185143E67 INTEGRATED CIRCUITS
U0208 5162852A79 IC MOS TTL SPDT ANALOG
SC70
U0209 5162852A79 IC MOS TTL SPDT ANALOG
SC70
U0210 5162852A79 IC MOS TTL SPDT ANALOG
SC70
U0300 5113837A15 IC 3.3V QUAD BUFFER
U0303 5113837A15 IC 3.3V QUAD BUFFER
U0304 5187970L15 IC USB TRANS FULL-SPEED
U0305 5185353D94 IC RS232 TRANSCEIVER
U0307 5113805B78 IC 1 GATE 2 INPUT NAND
U0308 5109522E74 IC 2INPUT AND GATE
U0309 5113805B78 IC 1 GATE 2 INPUT NAND
U0401 5162852A79 IC MOS TTL SPDT ANALOG
SC70
U0500 5183308X01 IC, LM2941, TO DRPOUT
RGTR
U0501 5185353D55 IC VOLTAGE REGULATOR
100MZ ADJ
U0502 5185353D55 IC VOLTAGE REGULATOR
100MZ ADJ
U0503 5113816A07 REG 5V POS 500MA
MC78M05BDTRK
U0504 5185353D46 IF 4.3V VOLTAGE DETECTOR
U0505 5113816A07 REG 5V POS 500MA
MC78M05BDTRK
U0506 5185143E57 CMOS TIMER-LMC555CM
U0507 5185353D55 IC VOLTAGE REGULATOR
100MZ ADJ
Reference
Designator
Motorola
Part Number
Description
U0601 5113805B78 IC 1 GATE 2 INPUT NAND
U0602 5113837A15 IC 3.3V QUAD BUFFER
U0603 5109522E53 IC,BFR,1BITS,NC7SZ125P5X,
,3 STATE O
U0604 5113818A14 IC DL OP AMP RAIL TO RAIL
U0605 5113805B78 IC 1 GATE 2 INPUT NAND
U0606 5105109Z31 IC QUAD 2:1 MUX/DEMUX
U0607 5109522E74 IC 2INPUT AND GATE
U0608 5109522E74 IC 2INPUT AND GATE
U0609 5113805B78 IC 1 GATE 2 INPUT NAND
U0610 5113805B78 IC 1 GATE 2 INPUT NAND
U0611 5113805B78 IC 1 GATE 2 INPUT NAND
U0900 5185368C83 IC 12 BIT DAC
U0901 5164015H66 IC,CPLD,EEPROM,,,SM,BGA
48,64MC,1500
U0902 5162852A79 IC MOS TTL SPDT ANALOG
SC70
U0903 5185143E68 INTEGRATED CIRCUITS
U0904 5162852A79 IC MOS TTL SPDT ANALOG
SC70
U0905 5162852A79 IC MOS TTL SPDT ANALOG
SC70
U0950 5105625U25 IC 9.3V REG 2941
U0951 5105625U25 IC 9.3V REG 2941
U0952 5185956E99 IC,POT,DUAL 256 TAP
DIGITAL 50K SP
U0953 5185143E16 IC ANALOG TO DIGITAL
CONVERTER
U0954 5113805B78 IC 1 GATE 2 INPUT NAND
U0955 5113819A14 IC QD OP AMP _33204_
U0956 5185956E24 IC,OP AMP,2PER PKG,RAIL-
RAIL,DIFF,,
U0957 5113819A14 IC QD OP AMP _33204_
U0958 5113805B78 IC 1 GATE 2 INPUT NAND
U0959 5185143E05 IC DAC OCTAL 8 BIT
U0960 5113819A14 IC QD OP AMP _33204_
U0962 5185353D14 IC SOT23-5 HI PRECISION
REG 3V
U0963 5109522E53 IC,BFR,1BITS,NC7SZ125P5X,
,3 STATE O
U0965 5185143E68 INTEGRATED CIRCUITS
U0967 5185143E68 INTEGRATED CIRCUITS
Reference
Designator
Motorola
Part Number
Description
U5001 5185353D14 IC SOT23-5 HI PRECISION
REG 3V
U5002 5185963A85 IC-ABACUS III-LP
U5300 5185130C83 IC 15DB DIGITAL
ATTEUATOR SOT25 PKG
U5301 5113816A07 REG 5V POS 500MA
MC78M05BDTRK
U5302 5186258W01 IC GAAS RF GAIN STAGE
U5303 5185130C65 IC VHF/UHF/800 MHZ LDMOS
DRIVER
Reference
Designator
Motorola
Part Number
Description
