A - 8 MC9500-K Mobile Computer Integrator Guide
MC9500-K Accessory Specifications
Single Bay USB Cradle
Table A-4
Headset Connector Pin-outs
Pin Description
1 Mic_Gnd
2Ring
3Tip
4GND
Table A-5
Single Bay USB Cradle Technical Specifications
Feature Description
Dimensions Height: 15.45 cm (6.08 in.)
Width: 12.00 cm (4.72 in.)
Depth: 18.90 cm (7.44 in.)
Weight 430 g (15.2 oz)
Input Power 12 VDC
Power Consumption 22 watts
Interface USB
Operating Temperature 0°C to 50°C (32°F to 122°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Charging Temperature 0°C to 40°C (32°F to 104°F)
Humidity 5% to 95% non-condensing
Drop 76.2 cm (30.0 in.) drops to vinyl tiled concrete at room temperature
Electrostatic Discharge (ESD) +/- 15 kV air
+/- 8 kV contact
