ioThinx 4510 Series Appendix
A-3
04: INPUT REGISTER
Parameter Description Length Type
modbusRtuMasterDeviceStatus Modbus/RTU Master - device status 4 WORD
modbusRtuMasterprofileErrorCode Modbus/RTU Master - profile error code 8 WORD
deviceName device name 8 BYTE
deviceDate device date
e.g. 2016/06/28 -> 20160628
2 DWORD
deviceTime device local time
e.g. 15:48:25 -> 154825
2 DWORD
deviceUpTime unit: sec(s) 2 DWORD
firmwareVersion Each byte represents ASCII code. e.g. 1.2.3 --
> V1.2.3 , 11.13.12 -->V11.13.12
4 BYTE
firmwareBuildDate Each byte represents ASCII code. E.g.
16051718 --> Build16051718
4 BYTE
serialNumber Each byte represents ASCII code of serial
number English character : e.g.
TAGCB1100001
6 BYTE
lanMac MAC address 4 BYTE
lanIp IP address 2 BYTE
systemError System Error 1 WORD
45MR-1600 (-T), 16 DIs Registers
01: COIL STATUS
Parameter Description Length Type
diCounterStatus DI - Counter mode - status (0: Pause, 1: Run) 4 BOOL
diCounterOverflowFlagClear DI - Counter mode - clear overflow flag (1: Clear) 4 BOOL
02: INPUT STATUS
Parameter Description Length Type
diStatus DI - DI mode - status (0: OFF, 1: ON) 16 BOOL
diMode DI - mode (0: DI, 1: Counter) 16 BOOL
diCounterOverflowFlag DI - Counter mode - overflow flag (0: Normal, 1:
Overflow)
4 BOOL
03: HOLDING REGISTER
Parameter Description Length Type
diCounterValue DI - Counter mode - value 8 DWORD
diCounterStatusAll DI - Counter mode - status (0: Pause, 1: Run) 1 WORD
diCounterOverflowFlagClearAll DI - Counter mode - clear overflow flag (1: Clear) 1 WORD
04: INPUT REGISTER
Parameter Description Length Type
diStatusAll DI - DI mode - status (0: OFF, 1: ON) 1 WORD
diCounterOverflowFlagAll DI - Counter mode - overflow flag (0: Normal, 1:
Overflow)
1 WORD
diModeAll DI - mode (0: DI, 1: Counter) 1 WORD
