Moxa Technologies ioThinx 4510 Series User Manual

ioThinx 4510 Series Appendix
A-9
45MR-6810 (-T), 8 TCs Registers
01: COIL STATUS
Parameter Description Length Type
tcResetMinValue TC - reset minimum value (1: Reset) 8 BOOL
tcResetMaxValue TC - reset maximum value (1: Reset) 8 BOOL
03: HOLDING REGISTER
Parameter Description Length Type
tcResetMinValueAll TC - reset minimum value (1: Reset) 1 WORD
tcResetMaxValueAll TC - reset maximum value (1: Reset) 1 WORD
04: INPUT REGISTER
Parameter Description Length Type
tcValueScaled TC - scaled value 16 REAL
tcValueScaledMin TC - minimum scaled value 16 REAL
tcValueScaledMax TC - maximum scaled value 16 REAL
tcType TC - Type (0: J Type, 1: K Type, 2: T Type, 3: E
Type, 4: R Type, 5: S Type, 6: B Type, 7: N
Type, 14: ±78.126 mV, 15: ±39.062 mV, 16:
±19.532 mV)
8 WORD
tcStatus TC - Status (0: normal, 1:burnout) 8 WORD
45MR-7210(-T), System and Field Power Input Registers
Parameters Description Length Type
spStatus SP - system power Status 1 WORD
spLowerLimitValue SP - system power lower limit value 2 REAL
spUpperLimitValue SP - system power upper limit value 2 REAL
fpStatus FP - Field Power Status 1 WORD
SNMP Rules
All OIDs of this device begin with .1.3.6.1.4.1.8691.10.4510. The data can be read or written by a network
management software with the following OIDs. Download the latest version of the MIB file from
www.moxa.com for additional information.
OID Type
.1.3.6.1.4.1.8691.10.4510.1 systemInfo
.1.3.6.1.4.1.8691.10.4510.2 systemPower
.1.3.6.1.4.1.8691.10.4510.3 fieldPower
.1.3.6.1.4.1.8691.10.4510.11 di
.1.3.6.1.4.1.8691.10.4510.12 do
.1.3.6.1.4.1.8691.10.4510.13 relay
.1.3.6.1.4.1.8691.10.4510.21 ai
.1.3.6.1.4.1.8691.10.4510.22 ao
.1.3.6.1.4.1.8691.10.4510.23 rtd
.1.3.6.1.4.1.8691.10.4510.24 tc
.1.3.6.1.4.1.8691.10.4510.41 internalRegister
.1.3.6.1.4.1.8691.10.4510.91 event
.1.3.6.1.4.1.8691.10.4510.92 eventTriggerType
