Moxa Technologies ioThinx 4510 Series User Manual

ioThinx 4510 Series Appendix
A-6
45MR-2606 (-T), 8 DIs, 8 DOs Registers
01: COIL STATUS
Parameter Description Length Type
doStatus DO - status (0: OFF, 1: ON) 8 BOOL
diCounterStatus DI - Counter mode - status (0: Pause, 1: Run) 2 BOOL
diCounterOverflowFlagClear DI - Counter mode - clear overflow flag (1:
Clear)
2 BOOL
doPulseStatus DO - Pulse mode - status (0: Stop, 1: Start) 2 BOOL
02: INPUT STATUS?
Parameter Description Length Type
diStatus DI - DI mode - status (0: OFF, 1: ON) 8 BOOL
diMode DI - mode (0: DI, 1: Counter) 8 BOOL
doMode DO - mode (0: DO, 1: Pulse) 8 BOOL
diCounterOverflowFlag DI - Counter mode - overflow flag (0: Normal,
1: Overflow)
2 BOOL
03: HOLDING REGISTER
Parameter Description Length Type
diCounterValue DI - Counter mode - value 4 DWORD
doStatusAll DO - status (0: OFF, 1: ON) 1 WORD
doPulseCount DO - Pulse mode - count 4 DWORD
doPulseOnWidth DO - Pulse mode - ON width (unit: 500 us) 2 WORD
doPulseOffWidth DO - Pulse mode - OFF width (unit: 500 us) 2 WORD
doPulseStatusAll DO - Pulse mode - status (0: Stop, 1: Start) 1 WORD
diCounterStatusAll DI - Counter mode - status (0: Pause, 1: Run) 1 WORD
diCounterOverflowFlagClearAll DI - Counter mode - clear overflow flag (1:
Clear)
1 WORD
04: INPUT REGISTER
Parameter Description Length Type
diStatusAll DI - DI mode - status (0: OFF, 1: ON) 1 WORD
diCounterOverflowFlagAll DI - Counter mode - overflow flag (0: Normal, 1:
Overflow)
1 WORD
diModeAll DI - mode (0: DI, 1: Counter) 1 WORD
doModeAll DO - mode (0: DO, 1: Pulse) 1 WORD
