ioThinx 4510 Series Appendix
A-4
45MR-1601 (-T), 16 DIs Registers
01: COIL STATUS
Parameter Description Length Type
diCounterStatus DI - Counter mode - status (0: Pause, 1: Run) 4 BOOL
diCounterOverflowFlagClear DI - Counter mode - clear overflow flag (1: Clear) 4 BOOL
02: INPUT STATUS?
Parameter Description Length Type
diStatus DI - DI mode - status (0: OFF, 1: ON) 16 BOOL
diMode DI - mode (0: DI, 1: Counter) 16 BOOL
diCounterOverflowFlag DI - Counter mode - overflow flag (0: Normal, 1:
Overflow)
4 BOOL
03: HOLDING REGISTER
Parameter Description Length Type
diCounterValue DI - Counter mode - value 8 DWORD
diCounterStatusAll DI - Counter mode - status (0: Pause, 1: Run) 1 WORD
diCounterOverflowFlagClearAll DI - Counter mode - clear overflow flag (1: Clear) 1 WORD
04: INPUT REGISTER
Parameter Description Length Type
diStatusAll DI - DI mode - status (0: OFF, 1: ON) 1 WORD
diCounterOverflowFlagAll DI - Counter mode - overflow flag (0: Normal, 1:
Overflow)
1 WORD
diModeAll DI - mode (0: DI, 1: Counter) 1 WORD
45MR-2404 (-T), 4 Relays Registers
01: COIL STATUS
Parameter Description Length Type
relayStatus Relay - Relay mode - status (0: OFF, 1: ON) 4 BOOL
relayCurrentCountReset Relay - reset current count (1: Reset) 4 BOOL
03: HOLDING REGISTER
Parameter Description Length Type
relayStatusAll Relay - Relay mode - status (0: OFF, 1: ON) 1 WORD
04: INPUT REGISTER
Parameter Description Length Type
relayTotalCount Relay - total count 8 DWORD
relayCurrentCount Relay - current count 8 DWORD
