Moxa Technologies ioThinx 4510 Series User Manual

ioThinx 4510 Series Appendix
A-5
45MR-2600 (-T), 16 DOs Registers
01: COIL STATUS
Parameter Description Length Type
doStatus DO - status (0: OFF, 1: ON) 16 BOOL
doPulseStatus DO - Pulse mode - status (0: Stop, 1: Start) 4 BOOL
02: INPUT STATUS?
Parameter Description Length Type
doMode DO - mode (0: DO, 1: Pulse) 16 BOOL
03: HOLDING REGISTER
Parameter Description Length Type
doStatusAll DO - status (0: OFF, 1: ON) 1 WORD
doPulseCount DO - Pulse mode - count 8 DWORD
doPulseOnWidth DO - Pulse mode - ON width (unit: 500 us) 4 WORD
doPulseOffWidth DO - Pulse mode - OFF width (unit: 500 us) 4 WORD
doPulseStatusAll DO - Pulse mode - status (0: Stop, 1: Start) 1 WORD
04: INPUT REGISTER
Parameter Description Length Type
doModeAll DO - mode (0: DO, 1: Pulse) 1 WORD
45MR-2601 (-T), 16 DOs Registers
01: COIL STATUS
Parameter Description Length Type
doStatus DO - status (0: OFF, 1: ON) 16 BOOL
doPulseStatus DO - Pulse mode - status (0: Stop, 1: Start) 4 BOOL
02: INPUT STATUS?
Parameter Description Length Type
doMode DO - mode (0: DO, 1: Pulse) 16 BOOL
03: HOLDING REGISTER
Parameter Description Length Type
doStatusAll DO - status (0: OFF, 1: ON) 1 WORD
doPulseCount DO - Pulse mode - count 8 DWORD
doPulseOnWidth DO - Pulse mode - ON width (unit: 500 us) 4 WORD
doPulseOffWidth DO - Pulse mode - OFF width (unit: 500 us) 4 WORD
doPulseStatusAll DO - Pulse mode - status (0: Stop, 1: Start) 1 WORD
04: INPUT REGISTER
Parameter Description Length Type
doModeAll DO - mode (0: DO, 1: Pulse) 1 WORD
