ioThinx 4510 Series Appendix
A-8
45MR-4420 (-T), 4 AOs Registers
03: HOLDING REGISTER
Parameter Description Length Type
aoValueRaw AO - raw value 4 WORD
aoValueScaled AO - scaled value 8 REAL
04: INPUT REGISTER
Parameter Description Length Type
aoMode AO - mode (0: disable, 1: 0-10 V, 2: 0-20 mA,
3: 4-20 mA, 4: ±10 V)
4 WORD
45MR-6600 (-T), 6 RTDs Registers
01: COIL STATUS
Parameter Description Length Type
rtdResetMinValue RTD - reset minimum value (1: Reset) 6 BOOL
rtdResetMaxValue RTD - reset maximum value (1: Reset) 6 BOOL
03: HOLDING REGISTER
Parameter Description Length Type
rtdResetMinValueAll RTD - reset minimum value (1: Reset) 1 WORD
rtdResetMaxValueAll RTD - reset maximum value (1: Reset) 1 WORD
04: INPUT REGISTER
Parameter Description Length Type
rtdValueScaled RTD - scaled value 12 REAL
rtdValueScaledMin RTD - minimum scaled value 12 REAL
rtdValueScaledMax RTD - maximum scaled value 12 REAL
rtdType RTD - Type (0: PT50, 1: PT100, 2: PT200, 3:
PT500, 4: PT1000; 14: 310 Ohm, 15: 620 Ohm,
16: 1250 Ohm, 17: 2200 Ohm; 20: JPT100, 21:
JPT200, 22: JPT500, 23: JPT1000; 30: NI100,
31: NI200, 32: NI500, 33: NI1000, 34: NI120)
6 WORD
rtdStatus RTD - Status (0: normal, 1:burnout) 6 WORD
