Moxy MT 26 - Page 635

SHOP MANUAL MT26/31 - 12.2004SHOP MANUAL MT26/31 - 12.2004
DRIVE LINE
CH 3 PAGE 10
SHOP MANUAL MT26/31 - 12.2004SHOP MANUAL MT26/31 - 12.2004
181 mm
2
,5
m
m
183,5 mm
Pinion basic dimensions
