MSA Ultima X Series Installation & Maintenance Instructions

Table D-8. Gas Type Descriptions
GAS TYPE DESCRIPTION GAS TYPE DESCRIPTION
CO Carbon Monoxide Performance verified to ANSI/ISA-92.00.01
by FM Approvals
O
2
Oxygen
COMB Combustible-pellistor
XiIR Infrared Combustible
H
2
S Hydrogen Sulfide Performance verified to ANSI/ISA-92.00.01
by FM Approvals
Cl Chlorine
Cl
2
Chlorine Dioxide
NH
3
Ammonia
Table D-9. Alarm Control Actions
Bit0 Alarm Enable 1 = enabled, 0 = disabled
Bit1 Alarm Direction 1 = increasing, 0 = decreasing
Bit2 Alarm Latch Status 1 = latching , 0 = non-latching
Bit3-7 Unused
Table D-10. Gas Table Values
TABLE DESCRIPTION
1 Methane
2 Propane
3 Ethane
4 n-Butane
5 n-Pentane
6 n-Hexane
7 Cyclopentane
8 Ethylene
21 Acetylene
47 5000 PPM CO
2
48 5% CO
2
49 2% CO
2
50 Custom
250 Unused
D-30
