Page #45 background imageLoading...
Page #45 background image
2-9
These calibration kits contain zero caps to use in place of
zero calibration gas. These caps can only be used when the
ambient air does not contain the gas the monitor is detect-
ing. If there is any doubt, use zero gas when zeroing the
Ultima X Monitor; otherwise, improper calibration could
occur.
Span Gas Values
The Ultima X Series Gas Monitor is factory-shipped with a preset span
gas value (TABLE 2-2). This span gas value can be changed via the
Ultima Controller or a HART controller; otherwise, the span gas must
correspond to preset concentrations. See Section 3 of the
Controller/Calibrator Manual (P/N 813379) to change the span gas
value. See Appendix D for the equivalent HART command
The span gas value of Ultima X Gas Monitor catalytic combustible
models are pre-set to one of the broad categories shown in TABLE 2-2.
Specific span gas values for all combustible models are listed under
each category given in TABLE 2-3.
Always calibrate for the least sensitive gas or vapor (higher
number category) expected to be measured (TABLE 2-3);
otherwise, instrument readings may be incorrect.
Table 2-2. Factory-set Span Values
GAS TYPE RANGE SPAN GAS RP CAL WARM-UP
PRESET CYLINDER KIT TIME
VALUES P/N
CARBON 0-100 PPM 60 PPM 710882 40 15 minutes
MONOXIDE 0-500 PPM 300 PPM 10027938
0-1000 PPM 400 PPM 10028048
SULFUR 0-25 PPM 10 PPM 10028070 40 15 minutes
DIOXIDE 0-100 PPM 10 PPM 808978
HYDROGEN 0-10 PPM 5 PPM 710414 40 15 minutes
SULFIDE 0-50 PPM 40 PPM 10028062
0-100 PPM 40 PPM 10028062
0-500 PPM 250 PPM 10089547
NITRIC OXIDE 0-100 PPM 50 PPM 10028074 40 15 minutes
NITROGEN 0-10 PPM 5 PPM 710332 41 41 30 minutes
DIOXIDE
"
WARNING
"
WARNING
