MSA Ultima X Series Installation & Maintenance Instructions

2-10
GAS TYPE RANGE SPAN GAS RP CAL WARM-UP
PRESET CYLINDER KIT TIME
VALUES P/N
CHLORINE 0-5 PPM 2 PPM 710331 41 30 minutes
0-10 PPM 2 PPM 30 minutes
0-20 PPM 10 PPM 10028066 30 minutes
HYDROGEN 0-50 PPM 10 PPM 10028072 41 30 minutes
CYANIDE
HYDROGEN 0-10 PPM 8 PPM 10028070 41 30 minutes
FLUORIDE
(7)
CHLORINE 0-3 PPM 1 PPM 710331 41 30 minutes
DIOXIDE
(4)
OXYGEN 0-10% 5% 493580 40 15 minutes
0-25% 20.8% 10028028
(2)
15 minutes
NATURAL GAS
(3)
0-100% LEL 25% LEL
(1)
10028034 40 15 minutes
PETROLEUM 0-100% LEL 40% LEL
(1)
10028034 40 15 minutes
VAPORS
(3)
(GASOLINE)
GENERAL 0-100% LEL 55% LEL
(1)
10028034 40 15 minutes
SOLVENTS
(3)
NON- 0-100% LEL 29% LEL
(1)
10028034 40 - - -
METHANE IR
METHANE IR 0-100% LEL 50% LEL
(5)
10028032 40 - - -
PHOSPHINE 2.0 PPM 0.5 PPM 710533 41 24 hours
ARSINE 2.0 PPM 1.0 PPM 710533 41 24 hours
SILANE 25 PPM 5 PPM 10014897 41 4 hours
DIBORANE 50 PPM 15 PPM 10014897 41 30 minutes
FLUORINE 5.0 PPM 4.0 PPM 710331 41 30 minutes
BROMINE 5.0 PPM 2.5 PPM 710331 41 30 minutes
AMMONIA 100 PPM 25 PPM 10028076 40 30 minutes
0-1000 PPM 300 PPM 10044014 40 30 minutes
HYDROGEN 0-1000 PPM 500 PPM 10022386 40 30 minutes
ETHYLENE
(6)
0-10 PPM 4.0 PPM 10028070 40 24 hours
OXIDE
CARBON 0-5000 PPM 2000 PPM 479266 40 - - -
DIOXIDE IR 0-2% 1.5% 807386
0-5% 2.5% 479265
HYDROGEN
CHLORIDE 0-50 PPM 40 PPM 10028078 41 30 minutes
NOTES:
1
Calibrated with Propane (.6% gas by volume)
2
Not required for standard calibration procedure
3
For combustible gas, it is good practice to calibrate unit with gas to be detected
4
ClO
2
is calibrated with Cl
2
or use ClO
2
Calibrator Kit (P/N 710420)
5
Methane IR is calibrated with 50% LEL Methane
6
ETO is calibrated with SO
2
.
7
Hydrogen Fluoride (HF) is calibrated with Sulfur Dioxide (SO
2
).
10 ppm SO
2
equals 8 ppm HF.
