9-5

Maintenance and Troubleshooting

Maintenance

Replacing the drum cartridge

When the time to replace the drum cartridge approaches, the “Drum Near End”

message appears on the display. Replace with a new drum cartridge.

Open the front and side covers.

Remove the used drum cartridge from the main unit.

Turn the lever (B3) to the left. Slide the lever (B4) rightward.
