Item name Contents Product No.
Screen transfer
cable
Screen data transfer caable for GTWIN and GT series. Mini-DIN
5-pin straight type
AFC8503S
Front panel protective sheet for GT01. 10 in set. (sold
separately)
AIGT080
Front panel protective sheet for GT11. 10 in set. (sold
separately)
AIGT280
Front panel protective sheet for GT10 (for replacement). 10 in
set. * 1 sheet included with the main unit when shipped.
AIGT180
Front panel
protective sheet
Front panel protective sheet for GT30 (for replacement). 10 in
set. * 1 sheet included with the main unit when shipped.
AIGT380
Waterproof packing for GT01 ( for replacement). 10 in set.
* 1 sheet included with the main unit when shipped.
AIGT081
Waterproof packing for GT10/GT11 ( for replacement). 10 in
set. * 1 sheet included with the main unit when shipped.
AIGT181
Waterproof
packing
Waterproof packing for GT30 ( for replacement). 10 in set.
* 1 sheet included with the main unit when shipped.
AIGT381
Replacement
backlight
This is the replacement backlight for the GT30
color/monochrome liquid crystal display.
AIGT382
Attachment fittings for GT01/GT11. 5 set (4 pcs./set) AIGT083
Attachment fittings for GT10. 5 set (4 pcs./set) AIGT183
Attachment
fittings
Attachment fittings for GT30. 5 set (2 pcs./set) AIGT383
COM port connector for GT01/GT11. 5 set AIGT084
Connector
COM port connector for GT10/GT30. 5 set AIGT184
Note:
• Connecting to the COM. port of the FP0
Because connecting the unit to the COM. port of the FPΣ/FP0 requires a loose-wire connection, this
cable is not available.
• The AIGT8142 is a cable for directly connecting to the 5 V type GT01 and the FP series TOOL port.
(Power can be supplied from the FP series.)
• The AIGT8162, AIGT8165 and AIGT8160 is the cables for connecting the GT01 (24V DC, RS232C),
GT11 and the TOOL port of our PLCs.
• The AIGT8192 is a cable for connecting the GT30 and the TOOL port of our PLCs.
Types of manuals
Manual name Contents
Manual
number
Manual included
in GTWIN
Terminal GTWIN
Operational Guide
Book
Note1)
Explains basic screen creation
methods.
ARCT1F357E No
GT Multi-purpose
Serial Communications
Manual
Explains about protocols and
handling when controlling the GT
Series using communicating from
an external device such as PC
board.
ARCT1F356E No
GT series Technical
Manual
Note2)
Explains about the hardware
specifications and handling
procedures.
ARCT1F398E Yes
Note1) Only covers basic operation. Please use the help function for detailed operation procedures.
Note2) Contains a GTWIN installation guide.
