1-3
1.1.3 Functions
Item GT01 specifications
Displayable fonts
Fixed fonts: 1/4 width (8 x 8), half width (16 x 8), full width (16 x 16)
Half width and full width characters can be displayed at same width,
doubled width, or quadrupled width
True Type fonts and Windows fonts
Character types Alphanumeric characters
Graphics
Straight lines, continuous straight lines, squares, circles, ovals, arcs, elliptic
arcs, fan shapes, elliptic fan shapes, beveled squares, bitmaps
Number of screens
Approx. 160 screens
Screen numbers that can be set: Base screens No. 00 to FF
* Number of screens that can be registered varies depending on registered
contents.
Part functions Messages, lamps, switches, data, bar graphs, keyboard, line chart
Contrast adjustment Contrast can be adjusted using touch panel operation.
Automatic
communication settings
Setting for communication between dedicated software and PLC set
automatically by connecting cable.
Debugging functions
Through function (PLC can be debugged from personal computer by
connecting computer to TOOL port and PLC to COM. port.)
Screen creation
Dedicated software is used.
Applicable OS: Windows 95/98/Me/2000/NT/XP
Password function
Screen data transfer or capture cannot be executed without a password
(screen data protection function).
Note) Clock functions are not available.
1.1.4 Touch Key
Item GT01 specifications
Touch key Analog touch key
Touch key operation 0.5 N or less
Touch key life Min. 10
6
Note1) The GT01 touch-switches operate using analog resistance membrane. Do not press two or more
points on the screen at the same time. Doing so might operate a switch located between those
points if one exists.
Note2) This touch-panel is designed to be operated by touching. Please realize that the positional
accuracy of the switches is based on the size of a finger.
1.1.5 Memory
Screen data and GTWIN Configuration Settings data
Item GT01 specifications
Memory type F-ROM
Memory chapacity 384 kbytes
