NAiS GT Series User Manual

1-8
1.3 GT30 Specifications
1.3.1 General Specifications
Item GT30 specifications
Rated voltage 24 V DC
Operating voltage
range
21.6 to 26.4 V DC
Power consumption 10 W or less
Ambient
temperature
0 to +50 °C (25 V DC max. if installed horizonally)
Ambient humidity 20 to 85% RH (at 25 °C, non-condensing)
Storage
temperature
-20 to +60 °C
Storage humidity 10 to 85% RH (at 25 °C, non-condensing)
Vibration resistance
10 to 55 Hz (1-minute cycle)
Amplitude: 0.75 mm, 10 min on 3 axes
Shock resistance 98 m/s
2
or more, 4 times on 3 axes
Noise immunity
1,000 V[p-p] min., pulse width 50 ns, 1µs between power supply terminals
(based on noise simulator)
Static noise
resistance
5,000 V min. (panel display)
Protective
construction
IP65 (in initial status)
Dustproof and drip-proof from front panel only (packing used on panel contact
surface) * When reattaching, replace waterproof packing.
Weight Approx. 440 g
1.3.2 Display
GT30 specifications
Item
AIGT3100B AIGT3300B
Display STN monochrome LCD STN color LCD
Resolution 320 (W) x 240 (H) dots
Display color 2 colors (balck/white) 16 colors
Displayable area 118.18 (W) x 89.38 (H) mm
LCD life Average 50,000 hours (at 25 °C room temperature)
Backlight CFL *Average backlight service life: 50,000 hours (25 °C)
