4.1.14 Cautions Regarding Direct Connection of GT01 (5V DC type) to the FP
Series TOOL Port
When directly connecting a GT01 to an FP Series TOOL port, a limit will apply to the number of units that
can be expanded due to the capacity of the FP Series power supply. Please proceed in accordance with
the information given below.
FP Series type Limitations when connecting a GT01
FP0 Maximum of two expansion units *
FPΣ Maximum of six expansion units *
FP2
FP2SH
FP10SH
The method for calculating the number fo units that can be expanded is
provided in the control unit hardware manual. Follow that formula and keep
the GT01’s power consumption noghigher than 200 mA when calculating.
FP-M Maximum of three expansion units *
FP-e There are no particular restrictions.
* Expansion is possible with the number of units given above, regardless of the type of unit.
* Please perform connections with the power turned off.
