W415-2034 / A / 10.18.19

ﬁ nishing

Ensure the door opens freely and closes sealed.

note:

IMPORTANT: Once latches are engaged, test to make sure that the door is sealed

FIXED SIDE - SEE-THRU ONLY

G. Remove the screws securing the door to the appliance.

H. Tilt the top of the door forward, then lift it up and out of the bottom door retainer.

I. When re-installing the door, life onto the bottom door retainer, tilt the top towards the appliance

and secure with the previously removed screws.

Under normal conditions, there is no reason to remove the ﬁ xed side of the ﬁ rebox glass door.

Servicing can be completed from the access side.

note:

LV38-1 Illustrated
